ER1VG
1 Amp Super Fast
Recovery
Silicon Rectifier
1400 Volts
Features
For Surface Mount Applications
Extremely Low Thermal Resistance
High Temp Soldering: 250
C for 10 Seconds At Terminals
Super Fast Recovery Times For High Efficiency
Gull Wing Lead Bend To Prevent Arcing
Perfect For Ballast, Television And Monitor Applications
Maximum Ratings
Operating Temperature: -50
C to +150
C
Storage Temperature: -50
C to +150
C
Maximum Thermal Resistance; 15
C/W Junction To Lead
MCC
Part
Number
Device
Marking
Maximum
Recurrent
Peak Reverse
Voltage
Maximum
RMS
Voltage
Maximum
DC
Blocking
Voltage
ER1VG ER1V 1400V 980V 1400V
Electrical Characteristics @ 25
C Unless Otherwise Specified
Average Forward
Current
I
F(AV)
1.0A T
J
= 55
C
Peak Forward Surge
Current
I
FSM
30A 8.3ms, half sine
Maximum
Instantaneous
Forward Voltage
V
F
2.2V I
FM
= 1.0A;
T
J
= 25
C*
Maximum DC
Reverse Current At
Rated DC Blocking
Voltage
I
R
5
A
30
A
T
J
= 25
C
T
J
= 125
C
Maximum Reverse
Recovery Time
T
rr
100ns I
F
=0.5A, I
R
=1.0A,
I
rr
=0.25A
Typical Junction
Capacitance
C
J
45pF Measured at
1.0MHz, V
R
=4.0V
*Pulse test: Pulse width 200
sec, Duty cycle 2%
www.
mccsemi
.com
DO-215AA
(SMBG)
(Round Lead)
DIMENSIONS
INCHES
MM
DIM MIN MAX MIN MAX NOTE
A .075 .116 1.90 2.95
B .078 .087 1.98 2.21
C .002 .008 .05 .20
D --- .02 --- .51
E .015 .03 .38 .76
F .065 .084 1.65 2.13
G .245 .276 6.22 7.00
H .160 .180 4.06 4.57
J .130 .151 3.30 3.83
0.070"
0.190"
0.125"
SUGGESTED SOLDER
PAD LAYOUT
G
H
J
E
F
A
B
D
C
Cathode Band
omponents
21201 Itasca Street Chatsworth
!"#
$
% !"#
