CMM0618-BD
VNP@s@QXNP@gh@Qw@mmic@a"'OEOE^~
CELERITEK INC.
ADVANCED PRODUCT SPECIFICATIONS (
1
)
PRODUCT DESCRIPTION: 6-18GHz 1W MMIC Amplifier
PART NUMBER: CMM0618-BD
PRODUCT APPLICATION:
BM NUMBER: tbd
PROJECT ENGINEER: Carlo Poledrelli
REVISION: 02
MASK NUMBER: M400
DATE: 10/29/04
VERSION NUMBER:
Main Features
2-stage design ideal to be used in balanced configuration
Input/output DC block integrated on chip
30dBm typical Psat
10.5dB nominal Gain
Bias: 6V, 750mA
Chip size: 2.815x1.980mm
2
Room temperature electrical specifications at Vdd=6.5V, Idq=775mA. (
2
)
PARAMETER
SYMBOL
MIN
TYP
MAX
UNITS
Operating frequency band
F
6.0
-
18.0
GHz
Output power at 1dB compression
P1dB
28.0
29.0
-
dBm
Saturated output power
Psat
29.0
30.0
-
dBm
Psat peak-to-peak variation over frequency
P1dB
-
-
2.0
dBm
Linear gain
Glin
8.5
-
12.5
dB
Glin peak-to-peak variation over frequency
Glin
-
-
3.0
dB
Output third order intercept point @ 10GHz
OIP3
-
36.0
-
dBm
Quiescent current
Idq
700
775
850
mA
Thermal resistance
Rth
tbd
C/W
Stability
Unconditionally stable
(
1
)
These specifications are subject to change.
(
2
)
Based on raw data taken using Celeritek' s connectorized fixture.
Electrical specifications over operating temperature: -35
75C.
PARAMETER
SYMBOL
MIN
TYP
MAX
UNITS
P1dB variation from room temperature value
P1dB
-
-
0.5
dBm
Glin variation from room temperature value
Glin
-
-
0.7
dB
Absolute Maximum Ratings (
3
)
RATING
PARAMETER
SYMBOL
MIN
MAX
UNITS
Drain voltage supply
Vdd
5.0
8.0
V
Drain current
Ids
-
1.0
A
Dissipated power
Pdiss
-
8.0
W
Input power
Pin
-
25.0
dBm
Storage temperature
Tstg
-50
150
C
Channel temperature
Tch
-
175
C
Operating backside temperature
Tb
-40
(
4
)
C
(
3
)
Operation outside any of these limits can cause permanent damage.
(
4
)
Calculate maximum operating temperature using the following formula: Tmax=175-(Pdiss [W] x Rth [
C/W]) [C].
