Features
VHF-TV
wideband, 2-250 MHz
high isolation, 30 dB typ.
good input port matching VSWR, 1.20 typ.
good output port matching VSWR, 1.10 typ.
small surface mount package
Applications
Operating Temperature
-40C to 85C
Storage Temperature
-55C to 100C
Power Input (as a splitter)
0.5W max.
Internal Dissipation
0.5W max.
L
Typ. Min.
M
Typ. Min.
U
Typ. Min.
FREQ.
RANGE
(MHz)
PHASE
UNBALANCE
(Degrees)
L
Max.
U
Max.
M
Max.
ISOLATION
(dB)
INSERTION LOSS (dB)
ABOVE 7.8 dB
L
Typ. Max.
M
Typ. Max.
U
Typ. Max.
AMPLITUDE
UNBALANCE
(dB)
L
Max.
U
Max.
M
Max.
f
L
-f
U
2-250
35
17
30
20
27
20
0.2
0.6
0.2
1.0
0.6
1.5
2
6
9
0.3
0.4
0.6
L= 2-20 MHz
M=20-125 MHz U=125-250 MHz
CASE STYLE: CJ725
PRICE: $26.95 ea. QTY (10-49)
Frequency
(MHz)
Insertion Loss
(dB)
Amplitude
Unbalance
(dB)
Isolation
(dB)
VSWR
S
Phase
Unbal.
(deg.)
VSWR
OUT
Adjacent
Opposite
SUM PORT
1
PORT 1
8
PORT 2
7
PORT 3
6
PORT 4
5
PORT 5
4
PORT 6
3
GROUND
2
Demo Board MCL P/N: TB-84
Suggested PCB Layout (PL-089)
AD6PS-1
INSERTION LOSS
7.7
7.9
8.1
8.3
8.5
8.7
8.9
0
50
100
150
200
250
FREQUENCY (MHz)
I
N
SER
T
I
O
N
L
O
SS (
d
B)
S-1(dB)
S-3(dB)
S-5(dB)
AD6PS-1
ISOLATION
0
10
20
30
40
50
0
50
100
150
200
250
FREQUENCY (MHz)
IS
O
L
A
T
IO
N (
d
B
)
1-2(dB)
1-4(dB)
AD6PS-1
VSWR
1.0
1.1
1.2
1.3
1.4
1.5
0
50
100
150
200
250
FREQUENCY (MHz)
VSWR
#S-VSWR
#1-VSWR
#3-VSWR
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
See our web site for RoHS Compliance methodologies and
qualifications.
Outline Dimensions ( )
inch
mm
Outline Drawing
A
B
C
D
E
F
G
.345
.400
.385
.435
.310
.215
.100
8.76
10.16
9.78
11.05
7.87
5.46
2.54
H
J
K
L
M
N
P
wt
.015
.025
.035
.075
.120
.060
.420 grams
0.38
0.64
0.89
1.91
3.05
1.52
10.67
0.45
electrical schematic
S-1
S-3
S-5
2.00
8.07
8.07
8.09
0.02
44.32
21.86
0.17
1.12
1.43
3.00
8.03
8.03
8.05
0.02
46.13
23.38
0.15
1.10
1.33
4.00
8.01
8.02
8.03
0.02
46.77
24.50
0.14
1.09
1.28
5.00
8.01
8.01
8.02
0.01
46.81
25.38
0.22
1.09
1.25
10.00
8.00
7.99
8.01
0.02
45.82
27.85
0.32
1.08
1.17
20.00
8.00
8.01
8.03
0.03
44.12
29.38
0.52
1.08
1.13
30.00
8.03
8.03
8.05
0.02
42.21
29.73
0.80
1.09
1.12
40.00
8.04
8.05
8.07
0.03
40.48
29.69
0.98
1.10
1.12
50.00
8.07
8.07
8.10
0.03
39.00
29.54
1.28
1.11
1.11
80.00
8.12
8.11
8.13
0.03
36.01
28.87
2.03
1.15
1.10
140.00
8.30
8.26
8.28
0.04
33.66
27.80
3.30
1.19
1.09
170.00
8.31
8.26
8.28
0.06
33.93
27.65
3.95
1.18
1.10
200.00
8.45
8.37
8.40
0.08
35.49
27.95
4.50
1.14
1.12
230.00
8.58
8.47
8.50
0.11
38.19
28.94
4.94
1.13
1.15
250.00
8.72
8.58
8.59
0.17
37.43
30.14
5.29
1.18
1.17
6 Way-0 50
2 to 250 MHz
Power Splitter/Combiner
REV. G
M98898
ED-7967/1
AD6PS-1
HY/TD/CP
051213
Surface Mount
AD6PS-1+
AD6PS-1
