Mini-Circuits
Mini-Circuits ISO 9001 & ISO 14001 Certified
Typical Performance Data
Maximum Ratings
Pin Connections
Features
PCS/DCS
communication systems
SUM PORT
2
PORT 1
8
PORT 2
5
GROUND
1,3,4,6,7
low insertion loss, 0.7 dB typ.
high isolation, 30 dB typ.
excellent repeatability
low profile
Applications
Operating Temperature
-40C to 85C
Storage Temperature
-65C to 150C
Power Input (as a splitter)
1.5W max.
Internal Dissipation
0.75W max.
Frequency
(MHz)
Insertion Loss
(dB)
S-1
Amplitude
Unbalance
(dB)
Isolation
(dB)
VSWR
S
S-2
VSWR
1
VSWR
2
Phase
Unbalance
(deg.)
CASE STYLE: XX211-1
PRICE: $1.24 ea. QTY (25)
Demo Board MCL P/N: TB-37
Suggested PCB Layout (PL-053)
BP2P
INSERTION LOSS
3.5
3.6
3.7
3.8
3.9
4.0
1710
1780
1850
1920
1990
FREQUENCY (MHz)
INSERTION LOSS (dB)
S-1(dB)
S-2(dB)
BP2P
ISOLATION
15
20
25
30
35
40
1710
1780
1850
1920
1990
FREQUENCY (MHz)
ISOLATION (dB)
BP2P
VSWR
1.0
1.1
1.2
1.3
1.4
1.5
1710
1780
1850
1920
1990
FREQUENCY (MHz)
VSWR
#S-VSWR
#1-VSWR
#2-VSWR
electrical schematic
2 Way-0 50
1710 to 1990 MHz
Power Splitter/Combiner
Surface Mount
BP2P
REV. D
M105667
BP2P
JS/TD/CP/AM
060621
Outline Drawing
inch
mm
Outline Dimensions ( )
A
B
C
D
E
F
G
.163
.210
.077
.250
.220
.050
.017
4.14
5.33
1.96
6.35
5.59
1.27
0.43
H
J
K
M
N
P
wt
.009
.025
.030
.050
.030
.270 grams
0.23
0.64
0.76
1.27
0.76
6.86
0.10
Electrical Specifications
FREQ.
RANGE
(MHz)
ISOLATION
(dB)
INSERTION LOSS (dB)
ABOVE 3.0 dB
PHASE
UNBALANCE
(Degrees)
AMPLITUDE
UNBALANCE
(dB)
Typ.
Min.
Typ.
Max.
Max.
Max.
1710-1990
30
18
0.5
1.0
3.0
0.2
1710.00
3.68
3.70
0.03
23.45
0.21
1.12
1.18
1.12
1730.00
3.67
3.70
0.03
24.36
0.22
1.14
1.18
1.13
1750.00
3.66
3.69
0.03
25.30
0.22
1.17
1.19
1.13
1770.00
3.66
3.69
0.03
26.25
0.23
1.19
1.19
1.14
1790.00
3.66
3.68
0.02
27.22
0.23
1.21
1.20
1.14
1810.00
3.66
3.68
0.02
28.20
0.24
1.23
1.20
1.14
1830.00
3.65
3.68
0.02
29.13
0.26
1.25
1.21
1.15
1850.00
3.65
3.67
0.02
29.91
0.28
1.27
1.21
1.15
1870.00
3.65
3.67
0.02
30.49
0.29
1.29
1.22
1.16
1890.00
3.66
3.68
0.02
30.80
0.29
1.31
1.22
1.16
1910.00
3.66
3.68
0.02
30.71
0.31
1.33
1.23
1.17
1930.00
3.66
3.68
0.02
30.30
0.31
1.35
1.23
1.17
1950.00
3.66
3.68
0.02
29.68
0.33
1.37
1.24
1.18
1970.00
3.67
3.68
0.02
28.97
0.36
1.39
1.24
1.18
1990.00
3.67
3.69
0.02
28.23
0.37
1.41
1.25
1.19
PCB Land Pattern
Suggested Layout,
Tolerance to be within
.002
