50
High Power 0.50 to 1000 MHz
RF Instrument Amplifier
Coaxial
TIA-1000-1R8
CASE STYLE: AP175
Outline Dimensions ( )
inch
mm
Maximum Ratings
Features
Operating Temperature
0C to 55C
Storage Temperature
-40C to 70C
Outline Drawing
RF Instrument Amplifier Electrical Specifications
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers NORTH AMERICA 800-654-7949 417-335-5935 Fax 417-335-5945 EUROPE 44-1252-832600 Fax 44-1252-837010
Mini-Circuits
Mini-Circuits ISO 9001 & ISO 14001 Certified
REV. OR
M98211
TIA-1000-1R8
051208
Page 1 of 2
instrument model with built-in power supply, 110V/220V operation
high power output at 3.5dB compression, 37dBm typ.
high gain, 38 dB typ.
high reverse isolation, 80 dB typ.
100% burn-in at +25C, 48 hrs
thermally self-protected, LED indicator
protected by US Patent 5,101,171 and 6,943,629
MODEL
NO.
FREQUENCY
(MHz)
GAIN
(dB)
MAXIMUM
POWER
(dBm)
DYNAMIC
RANGE
VSWR
(:1)
AC
POWER
f
L
f
U
Min.
Flatness
Max.
Output
(1 dB Compr.)
Input
(no dam-
age)
NF
(dB)
Typ.
IP3
(dBm)
Typ.
In
Out
Volt
(V)
Freq.
Hz
VA
Max.
Typ.
Min.
TIA-1000-1R8
0.50
1000
35
2.0
+35
+32
+7
8*
+45
1.9
2.5
110
50/60
140
Applications
testing
laboratory use
* Noise Figure above 400MHz, At low frequency, NF increases to 16 dB typ.
1. Gain and maximum output power specified at 25C5C, over temperature, specifications degrade approximately 1dB, gain flatness 2.5 dB maximum.
2. VSWR specified at 340-1000 MHz
3. Open load is not recommended, potentially can cause damage. With no load derate max input power by 20 dB
Connectors Model
Price
Qty.
BNC
TIA-1000-1R8 $1,495.00 ea. (1-9)
Add-2 to model for 220V operation
A
B
C
D
wt
9.8
5.0
6.7
0.2 grams
248.92 127.00 170.18
5.08
3500
Keep area adjacent to fan and louvers clear to permit air flow to pass.
Caution: Do not insert anything especially conductors or fingers into case
opening. Physical injury, shock or death may accur.
TIA-1000-1R8
Typical Performance Data/Curves
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers NORTH AMERICA 800-654-7949 417-335-5935 Fax 417-335-5945 EUROPE 44-1252-832600 Fax 44-1252-837010
Mini-Circuits
Mini-Circuits ISO 9001 & ISO 14001 Certified
Page 2 of 2
TIA-1000-1R8
GAIN
35.0
37.0
39.0
41.0
43.0
45.0
0
200
400
600
800
1000
FREQUENCY (MHz)
G
A
I
N
(
d
B
)
at 110V
TIA-1000-1R8
DIRECTIVITY
20.0
30.0
40.0
50.0
60.0
0
200
400
600
800
1000
FREQUENCY (MHz)
D
I
R
E
C
T
I
V
I
T
Y
(
d
B
)
at 110V
TIA-1000-1R8
VSWR
1.0
1.5
2.0
2.5
3.0
0
200
400
600
800
1000
FREQUENCY (MHz)
V
S
W
R
IN
OUT
TIA-1000-1R8
OUTPUT POWER AT 1-dB COMPRESSION
30
32
34
36
38
40
0
200
400
600
800
1000
FREQUENCY (MHz)
O
U
T
P
U
T
P
O
W
E
R
(
d
B
m
)
TIA-1000-1R8
NOISE FIGURE
6.0
8.0
10.0
12.0
14.0
16.0
18.0
0
200
400
600
800
1000
FREQUENCY (MHz)
N
O
I
S
E
F
I
G
U
R
E
(
d
B
)
at 110V
FREQUENCY
(MHz)
GAIN
(dB)
DIRECTIVITY
(dB)
VSWR
(:1)
NOISE
FIGURE
(dB)
POUT at
1 dB COMPR.
(dBm)
110V
110V
IN
OUT
110V
110V
0.50
40.65
56.72
1.42
2.89
36.10
12.60
40.48
58.36
1.20
1.36
17.34
36.62
99.50
40.98
50.05
1.23
2.26
14.13
36.19
207.60
40.33
51.07
1.27
2.61
10.29
34.61
332.20
39.43
47.81
1.25
1.67
8.38
33.50
500.00
41.26
41.27
1.03
1.29
7.60
33.68
600.90
41.12
46.09
1.10
1.30
7.43
34.12
693.40
40.22
37.38
1.35
1.86
7.22
34.10
816.50
39.40
40.92
1.46
1.27
7.20
34.08
1000.00
39.47
38.45
1.30
1.48
7.30
33.50
