6 Way-0 50
700 to 1000 MHz
Power Splitter/Combiner
Coaxial
ZC6PD-960W
CASE STYLE: AB185
ZC6PD-960W
INSERTION LOSS
7.5
7.7
7.9
8.1
8.3
8.5
700
760
820
880
940
1000
FREQUENCY (MHz)
I
N
SER
T
I
O
N
LO
SS (
d
B)
S-1(dB)
S-3(dB)
S-5(dB)
ZC6PD-960W
ISOLATION
10
20
30
40
50
60
700
760
820
880
940
1000
FREQUENCY (MHz)
IS
O
L
A
T
IO
N (
d
B
)
1-2(dB)
1-3(dB)
1-6(dB)
ZC6PD-960W
VSWR
1.0
1.1
1.2
1.3
1.4
1.5
700
760
820
880
940
1000
FREQUENCY (MHz)
VSWR
#S VSWR
#1 VSWR
#3 VSWR
Typical Performance Data
Outline Dimensions ( )
inch
mm
Maximum Ratings
Features
UHF
cellular
instrumentation
low insertion loss, 0.4 dB typ.
high isolation, 28 dB typ.
rugged, shielded case
up to 10W power output as splitter
Applications
Operating Temperature
-55C to 100C
Storage Temperature
-55C to 100C
Power Input (as a splitter)
10W max.
Internal Dissipation
0.875W max.
Outline Drawing
Splitter Electrical Specifications
FREQ.
RANGE
(MHz)
f
L
-f
U
700-1000
28
15
0.4
1.0
--
0.6
1.3
1.5
1.2
1.5
INTERNET http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers
NORTH AMERICA 800-654-7949 417-335-5935 Fax 417-335-5945 EUROPE 44-1252-832600 Fax 44-1252-837010
Mini-Circuits
Mini-Circuits ISO 9001 & ISO 14001 Certified
REV. OR
M96283
ZC6PD-960W
HY/TD/CP
060119
VSWR
(:1)
OUT
Typ. Max.
S
Typ. Max.
PHASE
UNBALANCE
(Degrees)
Max.
INSERTION LOSS (dB)
ABOVE 7.8 dB
AMPLITUDE
UNBALANCE
(dB)
ISOLATION
(dB)
Typ. Max.
Typ. Min.
Max.
Frequency
(MHz)
Insertion Loss
(dB)
Amplitude
Unbalance
(dB)
Isolation
(dB)
VSWR
S
Phase
Unbal.
(deg.)
VSWR
3
1-2
A
B
C
D
E
F
4.76
3.00
.53
.150
4.610
1.500
120.90
76.20
13.46
3.81 117.09
38.10
G
H
J
K
L
wt
.125
.50
.25
1.13
.500
grams
3.18
12.70
6.35
28.70
12.70
183
700.00
8.04
8.04
7.85
0.21
22.53
20.27
25.29
2.51
1.04
1.05
1.06
720.00
8.02
8.01
7.84
0.19
24.03
21.27
25.61
2.35
1.03
1.06
1.07
750.00
8.09
8.08
7.92
0.18
26.76
22.97
26.38
2.46
1.11
1.07
1.08
780.00
8.09
8.08
7.95
0.15
30.06
24.62
27.14
2.22
1.18
1.08
1.09
805.00
8.01
7.98
7.87
0.14
33.76
26.10
27.90
2.38
1.22
1.09
1.10
820.00
8.03
8.00
7.91
0.14
36.88
27.12
28.45
2.37
1.25
1.10
1.11
835.00
8.16
8.13
8.03
0.13
41.45
28.24
29.12
2.47
1.26
1.11
1.12
850.00
8.25
8.23
8.15
0.12
48.78
29.47
29.82
2.35
1.27
1.12
1.13
865.00
8.15
8.11
8.08
0.11
46.78
30.74
30.43
2.25
1.27
1.13
1.14
880.00
8.05
8.01
7.99
0.08
40.30
32.33
31.07
2.36
1.26
1.14
1.15
895.00
8.07
8.01
8.01
0.08
36.33
34.25
31.75
2.46
1.25
1.14
1.15
910.00
8.09
8.03
8.03
0.07
33.44
37.01
32.42
2.55
1.24
1.15
1.16
930.00
8.14
8.09
8.10
0.06
30.64
42.09
33.16
2.52
1.21
1.16
1.17
960.00
8.10
8.05
8.11
0.06
27.31
39.90
33.43
2.49
1.15
1.17
1.18
1000.00
8.04
7.99
8.11
0.13
23.78
30.76
32.19
2.64
1.13
1.17
1.18
S-1
S-2
S-3
1-3
1-6
VSWR
1
Connectors
Model
Price
Qty.
SMA
ZC6PD-960W-S
$119.95
(1-9)
electrical schematic
Coaxial Connections
