50
High Power 20W 20 to 1000 MHz
Amplifi er
Coaxial
ZHL-20W-13
CASE STYLE: CP641
Outline Dimensions ( )
inch
mm
Maximum Ratings
Features
Operating Temperature
-20C to 65C
Storage Temperature
-55C to 100C
DC Voltage
+28V Max.
Outline Drawing
Amplifi er Electrical Specifi cations
INTERNET http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers
NORTH AMERICA 800-654-7949 417-335-5935 Fax 417-335-5945 EUROPE 44-1252-832600 Fax 44-1252-837010
Mini-Circuits
Mini-Circuits ISO 9001 & ISO 14001 Certified
REV. OR
M106317
ZHL-20W-13
060815
Page 1 of 2
Rugged- can withstand Open/Short at Output under full Output Power condition
Protected against overheat- shuts off automatically
Over voltage protection, shuts off above 29V
Excellent Gain Flatness, 1.2 dB typ.
Class A Amplifi er
Usable over 15 to 1100 MHz
Patent pending
MODEL
NO.
FREQUENCY
(MHz)
GAIN
(dB)
MAXIMUM
POWER
(dBm)
DYNAMIC
RANGE
VSWR
(:1)
Typ.
DC
POWER
f
L
f
U
Min.
Typ.
Max.
Flatness
Max.
Output
(1 dB compr.)
Output
(3 dB compr.)
Input
(no
damage)
NF
(dB)
Typ.
IP3
(dBm)
Typ.
In
Out
Volt
(V)
Nom.
Current
(A)
Max.
Min.
Typ.
Min.
Typ.
ZHL-20W-13
20
1000
46
50
55
1.8
+39
+41
+40
+43
0
3.5
+50
1.7
2.5
24
2.8
ZHL-20W-13X*
20
1000
46
50
55
1.8
+39
+41
+40
+43
0
3.5
+50
1.7
2.5
24
2.8
*Heat sink and fan not included
Open load is not recommended, potentially can cause damage.
Applications
VHF/UHF Transmitters
Defense, Amateur Radio, FM, TV 4B
Connectors Model
Price
Qty.
SMA ZHL-20W-13
$1395.00 (1-9)
SMA ZHL-20W-13X
$1320.00 (1-9)
A
B
C
D
E
F
G
H
J
4.75
4.375
4.11
1.540
2.00
3.36
.144
4.24
1.12
120.65 111.13 104.39
39.12
50.80
85.34
3.66 107.70
28.45
K
L
M
N
P
Q
R
S
T
wt
.58
.125
2.38
1.50
1.00
.50
.34
.19
.23 grams
14.73
3.18
60.45
38.10
25.40
12.70
8.64
4.83
5.84
850
Pin Connection
IN
IN
OUT OUT
DC 1
DC 2
To order without heat sink and fan, add suffi x X to model number. Alternative heat sinking
and heat removal must be provided by the user to limit maximum base-plate temperature to
85C, in order to ensure proper performance. For reference, this requires thermal resistance
of user's external heat sink to be 0.30C/W Max.
ZHL-20W-13
Typical Performance Data/Curves
INTERNET http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers
NORTH AMERICA 800-654-7949 417-335-5935 Fax 417-335-5945 EUROPE 44-1252-832600 Fax 44-1252-837010
Mini-Circuits
Mini-Circuits ISO 9001 & ISO 14001 Certified
Page 2 of 2
ZHL-20W-13
GAIN
48
49
50
51
52
53
0
200
400
600
800
1000
FREQUENCY (MHz)
GA
IN
(d
B
)
21V
24V
27V
ZHL-20W-13
OUTPUT POWER at 1dB COMPRESSION
39
40
41
42
43
44
0
200
400
600
800
1000
FREQUENCY (MHz)
O
U
TPUT PO
W
E
R (
d
Bm
)
ZHL-20W-13
VSWR
1.0
2.0
3.0
4.0
5.0
6.0
0
200
400
600
800
1000
FREQUENCY (MHz)
VSW
R (
:
1)
IN
OUT
ZHL-20W-13
IP3
45
47
49
51
53
55
0
200
400
600
800
1000
FREQUENCY (MHz)
IP
3
(d
B
m
)
ZHL-20W-13
IP3
45
47
49
51
53
55
0
200
400
600
800
1000
FREQUENCY (MHz)
IP
3
(d
B
m
)
FREQUENCY
(MHz)
GAIN
(dB)
VSWR
(:1)
POUT at
1 dB COMPR.
(dBm)
IP3
(dBm)
NOISE
FIGURE
(dB)
21V
24V
27V
IN
OUT
24V
24V
24V
20.00
50.22
49.66
49.18
1.48
1.30
41.07
51.89
3.44
50.00
50.51
49.94
49.46
1.48
1.33
41.72
52.61
3.42
100.00
50.63
50.03
49.54
1.46
1.21
42.03
52.89
3.47
150.00
50.78
50.16
49.66
1.42
1.05
42.52
52.99
3.43
200.00
50.65
50.01
49.49
1.37
1.16
42.54
52.87
3.39
300.00
50.82
50.16
49.61
1.37
1.65
41.64
52.11
3.41
400.00
50.99
50.33
49.75
1.56
2.51
41.58
51.60
3.36
500.00
51.58
50.92
50.31
1.55
2.29
41.31
51.38
3.36
600.00
52.01
51.27
50.65
1.43
5.28
41.61
50.88
3.49
700.00
51.30
50.51
49.90
1.49
3.30
41.92
50.22
3.48
800.00
50.19
49.47
48.88
1.80
4.40
41.65
49.74
3.61
850.00
50.02
49.35
48.77
1.95
5.40
41.53
49.45
3.69
900.00
50.36
49.74
49.16
1.95
5.39
41.15
48.70
3.77
950.00
50.73
50.16
49.60
2.22
3.65
40.75
48.85
3.81
1000.00
50.51
50.01
49.51
2.15
3.66
41.47
49.08
3.78
