50
Medium High Power 10 to 1000 MHz
Amplifi er
Coaxial
ZHL-2-8
BNC version shown
CASE STYLE: T34
Outline Dimensions ( )
inch
mm
Maximum Ratings
Features
Operating Temperature
-20C to 65C
Storage Temperature
-55C to 100C
DC Voltage
+25V Max.
Outline Drawing
Amplifi er Electrical Specifi cations
INTERNET http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers
NORTH AMERICA 800-654-7949 417-335-5935 Fax 417-335-5945 EUROPE 44-1252-832600 Fax 44-1252-837010
Mini-Circuits
Mini-Circuits ISO 9001 & ISO 14001 Certified
REV. OR
M98142
ZHL-2-8
060906
Page 1 of 2
wideband, 10 to 1000 MHz
high IP3, +38 dBm typ.
medium high power, 29 dBm min.
MODEL
NO.
FREQUENCY
(MHz)
GAIN
(dB)
MAXIMUM
POWER
(dBm)
DYNAMIC
RANGE
VSWR
(:1)
Max.
DC
POWER
f
L
f
U
Min.
Flatness
Max.
Output
(1 dB Compr.
min.)
Input
(no damage)
NF
(dB)
Typ.
IP3
(dBm)
Typ.
In
Out
Volt
(V)
Nom.
Current
(A)
Max.
ZHL-2-8
10
1000
27
1.0
+29
+5
10.0
+38
2.0
2.0
24
0.6
Applications
test equipment
cellular
instrumentation
laboratory
VHF/UHF
Open load is not recommended, potentially can cause damage.
With no load derate max input power by 20 dB
Connectors Model
Price
Qty.
BNC ZHL-2-8
$525.00
(1-9)
SMA
ZHL-2-8-S $535.00 (1-9)
A
B
C
D
E
F
G
H
J
4.75
2.00
2.12
.19
4.375
.23
1.540
.144
.58
120.65
50.80
53.85
4.83 111.13
5.84
39.12
3.66
14.73
K
L
M
N
P
Q
R
S
T
wt
.34
.50
1.50
1.00
.12
.38
4.00
.30
2.60
grams
8.64
12.70
38.10
25.40
3.05
9.65 101.60
7.62
66.04
440.0
ZHL-2-8
Typical Performance Data/Curves
INTERNET http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers
NORTH AMERICA 800-654-7949 417-335-5935 Fax 417-335-5945 EUROPE 44-1252-832600 Fax 44-1252-837010
Mini-Circuits
Mini-Circuits ISO 9001 & ISO 14001 Certified
Page 2 of 2
FREQUENCY
(MHz)
GAIN
(dB)
DIRECTIVITY
(dB)
VSWR
(:1)
NOISE
FIGURE
(dB)
POUT at
1 dB COMPR.
(dBm)
23V
24V
24.5V
23V
24V
24.5V
IN
OUT
24V
24V
ZHL-2-8
VSWR
1.0
1.5
2.0
2.5
3.0
0
200
400
600
800
1000
FREQUENCY (MHz)
VSW
R
IN
OUT
ZHL-2-8
DIRECTIVITY
20
24
28
32
36
40
44
0
200
400
600
800
1000
FREQUENCY (MHz)
DI
RECTI
VI
TY (
d
B)
23V
24V
24.5V
ZHL-2-8
GAIN
25
27
29
31
33
35
0
200
400
600
800
1000
FREQUENCY (MHz)
GA
IN
(d
B
)
23V
24V
24.5V
ZHL-2-8
OUTPUT POWER AT 1-dB COMPRESSION
25
27
29
31
33
35
0
200
400
600
800
1000
FREQUENCY (MHz)
O
U
TPUT PO
W
E
R (
d
Bm
)
ZHL-2-8
NOISE FIGURE
5.0
5.4
5.8
6.2
6.6
7.0
0
200
400
600
800
1000
FREQUENCY (MHz)
NOI
SE FI
GURE (
d
B)
at 24V
10.00
28.91 28.90 28.90 32.50
32.50
33.90 1.52
1.77
6.17
30.73
22.60
29.36 29.36 29.36 35.40
32.20
31.70 1.31
1.61
5.73
31.05
66.80
29.45 29.44 29.44 34.90
28.00
34.70 1.26
1.58
5.26
31.27
197.60
29.47 29.46 29.47
31.20
35.30
33.00
1.26 1.63
5.22
31.10
390.80
29.34 29.33 29.34
36.40
30.90
32.60
1.27 1.44
5.27
30.40
492.30
29.38 29.37 29.37
30.50
34.80
32.50
1.28 1.21
5.32
30.02
619.20
29.39 29.38 29.38
28.50
28.70
30.80
1.25 1.02
5.38
29.65
746.20
28.95 28.94 28.94
27.60
27.60
27.90
1.28 1.05
5.51
29.56
873.10
29.05 29.03 29.03
26.30
24.60
25.90
1.50 1.18
5.74
29.69
1000.00
29.06 29.05 29.05
21.70
23.10 22.20
1.26 1.82
6.09
29.32
