50
Medium High Power 50 to 1000 MHz
Low Noise Amplifier
High IP3
ZHL-3010+
ZHL-3010
Outline Dimensions ( )
inch
mm
Maximum Ratings
Features
Operating Temperature
-20C to 65C
Storage Temperature
-55C to 100C
DC Voltage
+13V Max.
Outline Drawing
Electrical Specifications
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers NORTH AMERICA 800-654-7949 417-335-5935 Fax 417-335-5945 EUROPE 44-1252-832600 Fax 44-1252-837010
Mini-Circuits
Mini-Circuits ISO 9001 & ISO 14001 Certified
REV. A
M98898
ZHL-3010
060703
Page 1 of 2
MODEL
NO.
FREQUENCY
(MHz)
GAIN
(dB)
MAXIMUM
POWER
(dBm)
DYNAMIC
RANGE
VSWR
(:1)
Max.
DC
POWER
f
L
f
U
Min.
Flatness
Max.
Output
(1 dB
Compr.
min.)
Input
(no damage)
NF
(dB)
Typ.
IP3
(dBm)
Typ.
In
Out
Volt
(V)
Nom.
Current
(A)
Max.
ZHL-3010
(+)
50
1000
30
1.0
+26
-3
5.5
+46
2.5
2.0
12
1.0
Applications
Open load is not recommended, potentially can cause damage.
With no load derate max input power by 20 dB
CASE STYLE: S32
Connectors
Model
Price
Qty.
SMA
ZHL-3010(+)
$179.95
(1-9)
A
B
C
D
E
F
G
H
J
3.75
2.00
1.8
.19 3.375
.19 1.625
.144
.50
95.25 50.80 45.72
4.83 85.73
4.83 41.28
3.66 12.70
K
L
M
N
P
Q
R
S
T
wt
.40
.50
1.30
.10
.38
3.00
.30
2.60
.80 grams
10.16 12.70 33.02
2.54
9.65 76.20
7.62 66.04 20.32
220.0
wideband, 50 to 1000 MHz
low noise, 5.5 dB typ.
high IP3, +46 dBm typ.
very high IP2, 68-83 dBm typ.
protected by US Patent, 6,943,629
cellular
VHF/UHF
laboratory
test equipment
instrumentation
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
Typical Performance Data/Curves
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers NORTH AMERICA 800-654-7949 417-335-5935 Fax 417-335-5945 EUROPE 44-1252-832600 Fax 44-1252-837010
Mini-Circuits
Mini-Circuits ISO 9001 & ISO 14001 Certified
Page 2 of 2
ZHL-3010
GAIN
35
36
37
38
39
40
50
240
430
620
810
1000
FREQUENCY (MHz)
G
A
I
N
(
d
B
)
at 12V
ZHL-3010
DIRECTIVITY
12
14
16
18
20
22
50
240
430
620
810
1000
FREQUENCY (MHz)
D
I
R
E
C
T
I
V
I
T
Y
(
d
B
)
at 12V
ZHL-3010
VSWR
1.0
1.5
2.0
2.5
3.0
50
240
430
620
810
1000
FREQUENCY (MHz)
V
S
W
R
IN
OUT
ZHL-3010
OUTPUT POWER AT 1-dB COMPRESSION
20
23
26
29
32
35
50
240
430
620
810
1000
FREQUENCY (MHz)
O
U
T
P
U
T
P
O
W
E
R
(
d
B
m
)
ZHL-3010
NOISE FIGURE
5.0
5.2
5.4
5.6
5.8
6.0
50
240
430
620
810
1000
FREQUENCY (MHz)
N
O
I
S
E
F
I
G
U
R
E
(
d
B
)
at 12V
FREQUENCY
(MHz)
GAIN
(dB)
DIRECTIVITY
(dB)
VSWR
(:1)
NOISE
FIGURE
(dB)
POUT at
1 dB COMPR.
(dBm)
12V
12V
IN
OUT
12V
12V
50.00
36.37
16.10
1.78
1.28
5.14
29.62
155.60
36.23
15.10
2.12
1.77
5.19
30.12
261.10
36.00
15.80
2.19
1.81
5.40
30.67
366.70
36.09
16.50
2.04
1.44
5.44
31.55
472.20
36.21
16.40
1.94
1.07
5.46
30.87
577.80
36.00
15.30
1.91
1.15
5.40
30.76
683.30
35.30
18.20
1.74
1.18
5.30
30.08
788.90
35.60
18.60
1.88
1.01
5.24
30.18
894.40
35.48
17.40
2.08
1.27
5.33
29.93
1000.00
35.29
20.20
2.04
1.56
5.43
28.74
