50
Medium High Power 0.05 to 130 MHz
Amplifier
Coaxial
ZHL-32A
BNC version shown
CASE STYLE: S32
Outline Dimensions ( )
inch
mm
Maximum Ratings
Features
Operating Temperature
-20C to 65C
Storage Temperature
-55C to 100C
DC Voltage
+25V Max.
Outline Drawing
Amplifier Electrical Specifications
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers NORTH AMERICA 800-654-7949 417-335-5935 Fax 417-335-5945 EUROPE 44-1252-832600 Fax 44-1252-837010
Mini-Circuits
Mini-Circuits ISO 9001 & ISO 14001 Certified
REV. A
M103461
ZHL-32A
060210
Page 1 of 2
high IP3, +38 dBm typ.
medium high power, 29 dBm min.
MODEL
NO.
FREQUENCY
(MHz)
GAIN
(dB)
MAXIMUM
POWER
(dBm)
DYNAMIC
RANGE
VSWR
(:1)
Max.
DC
POWER
f
L
f
U
Min.
Flatness
Max.
Output
(1 dB Compr.
min.)
Input
(no damage)
NF
(dB)
Typ.
IP3
(dBm)
Typ.
In
Out
Volt
(V)
Nom.
Current
(A)
Max.
ZHL-32A
0.05
130
25
1.0
+29
+10
10.0
+38
2.0
2.0
24
0.6
Applications
HF/VHF
communication systems
laboratory
instrumentations
Open load is not recommended, potentially can cause damage.
With no load derate max input power by 20 dB
Connectors
Model
Price
Qty.
BNC
ZHL-32A
$229.00
(1-9)
SMA
ZHL-32A-S
$239.00
(1-9)
A
B
C
D
E
F
G
H
J
3.75
2.00
1.8
.19 3.375
.19 1.625
.144
.50
95.25 50.80 45.72
4.83 85.73
4.83 41.28
3.66 12.70
K
L
M
N
P
Q
R
S
T
wt
.40
.50
1.30
.10
.38
3.00
.30
2.60
.80 grams
10.16 12.70 33.02
2.54
9.65 76.20
7.62 66.04 20.32 220.0
ZHL-32A
Typical Performance Data/Curves
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers NORTH AMERICA 800-654-7949 417-335-5935 Fax 417-335-5945 EUROPE 44-1252-832600 Fax 44-1252-837010
Mini-Circuits
Mini-Circuits ISO 9001 & ISO 14001 Certified
Page 2 of 2
FREQUENCY
(MHz)
GAIN
(dB)
DIRECTIVITY
(dB)
VSWR
(:1)
NOISE
FIGURE
(dB)
POUT at
1 dB COMPR.
(dBm)
23V
24V
24.5V
23V
24V
24.5V
IN
OUT
24V
24V
ZHL-32A
VSWR
1.0
1.2
1.4
1.6
1.8
2.0
0
26
52
78
104
130
FREQUENCY (MHz)
V
S
W
R
IN
OUT
ZHL-32A
DIRECTIVITY
12.0
12.6
13.2
13.8
14.4
15.0
0
26
52
78
104
130
FREQUENCY (MHz)
D
I
R
E
C
T
I
V
I
T
Y
(
d
B
)
23V
24V
24.5V
ZHL-32A
GAIN
26.0
26.8
27.6
28.4
29.2
30.0
0
26
52
78
104
130
FREQUENCY (MHz)
G
A
I
N
(
d
B
)
23V
24V
24.5V
ZHL-32A
OUTPUT POWER AT 1-dB COMPRESSION
25
27
29
31
33
35
0
26
52
78
104
130
FREQUENCY (MHz)
O
U
T
P
U
T
P
O
W
E
R
(
d
B
m
)
ZHL-32A
NOISE FIGURE
0
2
4
6
8
10
15
38
61
84
107
130
FREQUENCY (MHz)
N
O
I
S
E
F
I
G
U
R
E
(
d
B
)
at 24V
0.05
26.65
26.67
26.69
15.10
15.10
15.10
1.02
2.00
32.21
0.14
27.27
27.30
27.31
13.80
13.80
13.80
1.03
1.65
32.68
0.68
27.41
27.44
27.45
13.50
13.50
13.40
1.04
1.58
32.83
3.20
27.57
27.60
27.63
13.10
13.10
13.20
1.08
1.62
32.99
15.30
27.45
27.48
27.49
13.30
13.20
13.20
1.20
1.61
5.85
32.76
46.70
27.12
27.16
27.18
13.50
13.50
13.40
1.38
1.52
6.00
31.88
56.70
27.18
27.21
27.24
13.40
13.50
13.40
1.39
1.56
6.04
31.83
66.70
27.35
27.38
27.40
13.20
13.30
13.30
1.36
1.56
6.04
31.43
73.40
27.55
27.59
27.60
13.00
13.10
13.10
1.33
1.57
6.02
31.30
80.00
27.76
27.81
27.83
13.00
13.00
12.90
1.30
1.56
5.99
31.33
90.00
28.00
28.04
28.06
12.90
12.70
12.80
1.28
1.50
6.00
30.98
100.00
27.97
28.03
28.05
12.90
12.90
13.00
1.29
1.39
6.08
30.47
110.00
27.75
27.80
27.83
13.20
13.10
13.20
1.32
1.29
6.19
30.06
120.00
27.32
27.37
27.40
13.60
13.60
13.50
1.36
1.19
6.31
30.17
130.00
26.64
26.71
26.72
14.20
14.20
14.20
1.43
1.15
6.45
29.82
