50
Medium Power 10 to 2500 MHz
Amplifier
Coaxial
ZKL-2R5
CASE STYLE: BY493
Outline Dimensions ( )
inch
mm
Maximum Ratings
Features
Operating Temperature
-40C to 75C
Storage Temperature
-55C to 100C
DC Voltage
+13V Max.
Outline Drawing
Amplifier Electrical Specifications
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers NORTH AMERICA 800-654-7949 417-335-5935 Fax 417-335-5945 EUROPE 44-1252-832600 Fax 44-1252-837010
Mini-Circuits
Mini-Circuits ISO 9001 & ISO 14001 Certified
REV. OR
M98088
ZKL-2R5
051229
Page 1 of 2
wideband, 10 to 2500 MHz
high IP3, +31 dBm typ.
low noise, 5 dB typ.
rugged, shielded case
protected by US Patent, 6,943,629
MODEL
NO.
FREQUENCY
(MHz)
GAIN
(dB)
MAXIMUM
POWER
(dBm)
DYNAMIC
RANGE
VSWR
(:1)
Typ.
DC
POWER
f
L
f
U
Typ.
Min.
Flatness
Max.
Output
(1 dB Compr.)
Input
(no damage)
NF
(dB)
Typ.
IP3
(dBm)
Typ.
In
Out
Volt
(V)
Nom.
Current
(mA)
Max.
L
U
ZKL-2R5
10
2500
30
26
1.5
+13
+11
+13
5.0
+31
1.4
1.4
12
120
Applications
communication systems
cellular
PCS
GSM/ISM
Open load is not recommended, potentially can cause damage.
With no load derate max input power by 20 dB
Connectors
Model
Price
Qty.
SMA
ZKL-2R5
$149.95
(1-9)
L= low range (f
L
to f
U
/2)
U= upper range (f
U
/2 to f
U
)
A
B
C
D
E
F
G
H
J
1.38
1.00
.75
.125
.35
.52
.27
.78
.68
35.05
25.40
19.05
3.18
8.89
13.21
6.86
19.81
17.27
K
L
M
N
P
Q
R
wt
.125
1.50 1.281 1.000
.19
.11
.35
grams
3.18
38.10
32.54
25.40
4.83
2.79
8.89
40
ZKL-2R5
Typical Performance Data/Curves
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers NORTH AMERICA 800-654-7949 417-335-5935 Fax 417-335-5945 EUROPE 44-1252-832600 Fax 44-1252-837010
Mini-Circuits
Mini-Circuits ISO 9001 & ISO 14001 Certified
Page 2 of 2
FREQUENCY
(MHz)
GAIN
(dB)
DIRECTIVITY
(dB)
VSWR
(:1)
NOISE
FIGURE
(dB)
POUT at
1 dB COMPR.
(dBm)
9V
12V
13V
9V
12V
13V
IN
OUT
12V
12V
ZKL-2R5
VSWR
1.0
1.2
1.4
1.6
1.8
2.0
2.2
0
500
1000
1500
2000
2500
FREQUENCY (MHz)
V
S
W
R
IN
OUT
ZKL-2R5
DIRECTIVITY
9
10
11
12
13
14
15
0
500
1000
1500
2000
2500
FREQUENCY (MHz)
D
I
R
E
C
T
I
V
I
T
Y
(
d
B
)
9V
12V
13V
ZKL-2R5
GAIN
26
27
28
29
30
31
32
33
0
500
1000
1500
2000
2500
FREQUENCY (MHz)
G
A
I
N
(
d
B
)
9V
12V
13V
ZKL-2R5
OUTPUT POWER AT 1-dB COMPRESSION
17.0
17.6
18.2
18.8
19.4
20.0
0
500
1000
1500
2000
2500
FREQUENCY (MHz)
O
U
T
P
U
T
P
O
W
E
R
(
d
B
m
)
ZKL-2R5
NOISE FIGURE
4.0
4.4
4.8
5.2
5.6
6.0
0
500
1000
1500
2000
2500
FREQUENCY (MHz)
N
O
I
S
E
F
I
G
U
R
E
(
d
B
)
at 12V
10.00
29.24
30.29
30.35
11.67
11.80
11.57
1.32
1.34
5.36
18.24
210.00
29.61
30.88
30.99
10.71
10.37
10.45
1.30
1.24
4.66
18.61
410.00
29.61
30.86
30.99
10.77
10.30
10.31
1.32
1.30
4.76
18.77
610.00
29.55
30.76
30.86
10.55
10.36
10.35
1.35
1.40
4.82
18.72
810.00
29.52
30.66
30.76
10.51
10.29
10.20
1.40
1.48
4.83
18.76
910.00
29.49
30.59
30.69
10.47
10.32
10.33
1.43
1.51
4.86
18.65
1110.00
29.33
30.38
30.47
10.43
10.34
10.36
1.44
1.55
4.82
18.69
1310.00
29.24
30.28
30.37
10.37
10.19
10.21
1.44
1.52
4.80
18.74
1510.00
29.12
30.12
30.24
10.27
9.93
9.86
1.42
1.45
4.82
18.58
1710.00
28.94
30.00
30.09
10.20
9.74
9.69
1.39
1.33
4.94
18.35
1810.00
28.81
29.88
29.95
10.28
9.76
9.71
1.37
1.27
4.99
18.37
2010.00
28.31
29.44
29.55
10.85
10.11
10.03
1.33
1.12
5.03
18.15
2160.00
28.01
29.08
29.17
11.26
10.57
10.48
1.35
1.07
5.03
18.17
2310.00
27.41
28.51
28.59
11.89
11.24
11.09
1.38
1.13
4.98
17.72
2500.00
26.71
27.76
27.82
12.76
12.08
12.05
1.44
1.25
5.03
17.45
