FREQ.
RANGE
(MHz)
ISOLATION
(dB)
INSERTION LOSS (dB)
ABOVE 3.0 dB
PHASE
UNBALANCE
(Degrees)
AMPLITUDE
UNBALANCE
(dB)
f
L
-f
U
Max.
Max.
Typ. Min
Typ. Max.
1000-2500
20
14
1.2
2.2
10.0
1.2
1400-1800
18
16
0.9
1.4
6.0
0.6
1800-2000
19
16
0.9
1.4
6.0
0.6
A
B
C
D
E
F
G
.74
.90
.54
.50
.04
.16
.29
18.80
22.86
13.72
12.70
1.02
4.06
7.37
H
J
K
L
M
N
wt
.37
--
.122
.496
.106
.122 grams
9.40
--
3.10
12.60
2.69
3.10
20.0
ZX10-2-25+
ZX10-2-25
2 Way-0 50 1000 to 2500 MHz
Power Splitter/Combiner
Coaxial
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers NORTH AMERICA 800-654-7949 417-335-5935 Fax 417-335-5945 EUROPE 44-1252-832600 Fax 44-1252-837010
Mini-Circuits
Mini-Circuits ISO 9001 & ISO 14001 Certified
Typical Performance Data
Maximum Ratings
Outline Drawing
Outline Dimensions ( )
inch
mm
electrical schematic
REV. E
M98898
ZX10-2-25
ED-10145/3
HY/RS/CP
060829
Features
excellent amplitude unbalance
very good phase unbalance
small size
low cost
protected under U.S. Patent 6,790,049 & 6,963,255
Applications
PCN/PCS
VSAT
ISM
GPS
defense
communications
Coaxial Connections
CASE STYLE: FL905
Connectors Model
Price
Qty.
SMA
ZX10-2-25-S(+)
$26.95
(1-24)
ZX10-2-25
INSERTION LOSS
3.0
3.4
3.8
4.2
4.6
5.0
1000
1300
1600
1900
2200
2500
FREQUENCY (MHz)
INSERTION
LOSS
(dB)
S-1
S-2
ZX10-2-25
ISOLATION
10
15
20
25
30
35
40
1000
1300
1600
1900
2200
2500
FREQUENCY (MHz)
ISOLATION
(dB)
ZX10-2-25
VSWR
1.0
1.2
1.4
1.6
1.8
2.0
1000
1300
1600
1900
2200
2500
FREQUENCY (MHz)
V
S
W
R
#S-VSWR
#1-VSWR
#2-VSWR
Frequency
(MHz)
Insertion Loss
(dB)
Amplitude
Unbalance
(dB)
Isolation
(dB)
Phase
Unbalance
(deg.)
VSWR
S
VSWR
1
VSWR
2
S-1
S-2
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
1000.00
4.13
3.70
0.43
21.64
2.82
1.70
1.63
1.52
1100.00
4.08
3.70
0.38
20.77
2.58
1.65
1.55
1.47
1200.00
4.01
3.70
0.31
20.10
2.27
1.61
1.48
1.42
1300.00
3.96
3.71
0.25
19.63
2.23
1.56
1.42
1.37
1400.00
3.93
3.73
0.21
19.33
2.05
1.52
1.36
1.32
1500.00
3.93
3.75
0.18
19.19
2.07
1.48
1.31
1.27
1600.00
3.93
3.81
0.12
19.22
2.10
1.43
1.26
1.23
1800.00
3.90
3.87
0.30
19.75
2.27
1.33
1.16
1.17
1900.00
3.90
3.90
0.01
20.29
2.59
1.28
1.12
1.15
2000.00
3.91
3.95
0.05
20.99
3.08
1.23
1.08
1.14
2100.00
3.93
4.03
0.10
21.68
3.65
1.22
1.04
1.16
2200.00
3.94
4.12
0.18
22.06
4.43
1.23
1.03
1.19
2300.00
3.96
4.20
0.24
21.62
5.16
1.30
1.06
1.26
2400.00
4.02
4.30
0.29
20.20
5.94
1.42
1.11
1.34
2500.00
4.12
4.44
0.32
18.17
7.12
1.60
1.16
1.43
Splitter Electrical Specifications (T
AMB
=25C)
Operating Temperature
-40C to 85C
Storage Temperature
-55C to 100C
Power Input (as a splitter)
1.0W max.
Internal Dissipation (as a combiner) 0.125W max.
SUM PORT
3
PORT 1
1
PORT 2
2
PDF
ZIP
