Power Splitter/Combiner
Coaxial
ZX10-4-24+
ZX10-4-24
ZX10-4-24
INSERTION LOSS
6.0
6.2
6.4
6.6
6.8
7.0
7.2
1650 1750 1850 1950 2050 2150 2250 2350
FREQUENCY(MHz)
INSERTION
LOSS
(dB)
S-1(dB)
S-3(dB)
at RF level of -10 dBm
ZX10-4-24
VSWR
1.0
1.1
1.2
1.3
1.4
1.5
1650
1750
1850
1950
2050
2150
2250
2350
FREQUENCY(MHz)
VSWR
#S-VSWR
#1-VSWR
#3-VSWR
at RF level of -10 dBm
ZX10-4-24
ISOLATION
0
10
20
30
40
50
60
1650
1750
1850
1950
2050
2150
2250
2350
FREQUENCY(MHz)
ISOLATION
(dB)
ISO 1-2
ISO 2-3
ISO 3-4
at RF level of -10 dBm
Maximum Ratings
Features
Applications
Outline Drawing
Splitter Electrical Specifications (T
AMB
=25C)
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers NORTH AMERICA 800-654-7949 417-335-5935 Fax 417-335-5945 EUROPE 44-1252-832600 Fax 44-1252-837010
Mini-Circuits
Mini-Circuits ISO 9001 & ISO 14001 Certified
REV. A
M98898
ZX10-4-24
ED-10988/5
AD/RC/CP
060125
Freq.
(MHz)
Insertion Loss
(dB)
Amp.
Unbal.
(dB)
Isolation
(dB)
S-1
S-2
S-3
1-2
3-4
VSWR
S
Phase
Unbal.
(deg.)
VSWR
2
VSWR
3
VSWR
1
2-3
S-4
VSWR
4
Typical Performance Data
FREQ.
RANGE
(MHz)
ISOLATION
(dB)
INSERTION LOSS
(dB) ABOVE 6 dB
PHASE
UNBALANCE
(Deg.)
AMPLITUDE
UNBALANCE
(dB)
INPUT
VSWR
(:1)
OUTPUT
VSWR
(:1)
f
L
-f
U
Typ.
Min.
Typ.
Max.
Max.
Max.
Typ.
Typ.
1675-2350
20
17
0.9
1.1
5.0
0.7
1.18
1.3
1775-2200
25
20
0.9
1.1
5.0
0.7
1.18
1.3
electrical schematic
CASE STYLE: GR1026
4 Way-0 50
1675 to 2350 MHz
Operating Temperature
-40C to 85C
Storage Temperature
-55C to 100C
Power Input (as a splitter)
2.5W max.*
Power Input (as a combiner)
0.125W max.
PCS/DCS
antenna arrays
signal distribution
test bench
low insertion loss, 0.9 dB typ.
high isolation, 20 dB typ.
rigid unibody construction
gold plated connectors; nickel plated body
low cost
small size
protected by US patent 6,790,049
*maximum VSWR at output 1.2:1
Outline Dimensions ( )
inch
mm
A
B
C
D
E
F
G
H
2.04
.60
.75
.50
.10
.17
.25
.25
51.82 15.24 19.05 12.70
2.54
4.32
6.35
6.35
J
K
L
M
N
wt.
.50
.11 1.820
.106
.12
grams
12.70
2.79 46.23
2.69
3.05
60.0
Connectors Model
Price
Qty.
SMA
ZX10-4-24-S(+)
$38.95 ea. (1-24)
1675.00
6.39 6.69
6.34 6.28
0.41
21.22 25.68 21.32
0.58
1.12
1.14
1.19
1.13
1.18
1700.00
6.39 6.70
6.34 6.28
0.42
22.15 26.12 22.32
0.45
1.11
1.14
1.19
1.12
1.18
1750.00
6.39 6.71
6.35 6.28
0.44
24.28 27.06 24.59
0.43
1.09
1.14
1.20
1.13
1.18
1800.00
6.40 6.73
6.36 6.28
0.45
27.02 28.12 27.60
0.39
1.08
1.15
1.20
1.13
1.18
1850.00
6.41 6.74
6.37 6.27
0.47
30.96 29.32 32.08
0.63
1.07
1.16
1.20
1.13
1.18
1900.00
6.44 6.75
6.39 6.28
0.47
37.87 30.73 40.30
0.89
1.07
1.16
1.21
1.13
1.19
1950.00
6.45 6.76
6.41 6.27
0.48
45.62 32.44 39.41
1.17
1.07
1.17
1.22
1.14
1.20
2000.00
6.49 6.76
6.43 6.28
0.49
34.59 34.61 32.00
1.51
1.08
1.20
1.23
1.15
1.21
2050.00
6.51 6.77
6.45 6.28
0.49
29.72 37.55 28.05
1.82
1.09
1.20
1.24
1.15
1.22
2100.00
6.55 6.77
6.47 6.29
0.48
26.72 42.00 25.45
1.97
1.09
1.21
1.25
1.16
1.23
2150.00
6.59 6.76
6.50 6.29
0.47
24.64 48.00 23.57
2.21
1.09
1.24
1.26
1.19
1.24
2200.00
6.63 6.76
6.52 6.29
0.46
23.01 43.74 22.06
2.45
1.08
1.26
1.28
1.20
1.26
2250.00
6.68 6.74
6.55 6.30
0.44
21.68 38.14 20.85
2.76
1.07
1.28
1.28
1.22
1.27
2300.00
6.72 6.73
6.56 6.30
0.43
20.57 34.39 19.84
2.93
1.06
1.29
1.30
1.23
1.29
2350.00
6.78 6.72
6.60 6.30
0.48
19.56 31.63 18.93
2.96
1.05
1.31
1.31
1.25
1.30
Coaxial Connections
SUM PORT
S
PORT 1
1
PORT 2
2
PORT 3
3
PORT 4
4
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
