1
MRF6401 PHOTOMASTER
MOTOROLA RF DEVICE DATA
The RF Line
NPN Silicon
RF Power Transistor
Figure 1. 1600 2000 MHz Broadband Application Amplifier Schematic
C1
1.5 pF, ATC Chip Capacitor 100A
C2
3.9 pF, ATC Chip Capacitor 100A
C3
56 pF, ATC Chip Capacitor 100A
C4, C6, C7, C9
15 nF, Chip Capacitor 0805
C5
47 pF, ATC Chip Capacitor 100A
C8
4.7
F, 35 V, Capacitor
C10
10
F, 16 V, Capacitor
C11
100 pF, ATC Chip Capacitor 100A
Q1
Transistor, BCV62
R2
470
, Chip Resistor 0805
R3
4.7 k
, Chip Resistor 0805
R4
8.2 k
, Chip Resistor 0805
R5
5 k
, SMD Potentiometer
R6
680
, Chip Resistor 0805
R7, R8
7.5
, Chip Resistor 0805
TL1 to TL11
Strip Lines; See Photomaster
TP1
Strip Taper; See Photomaster
R4
R5
R6
R2
R3
C9
R7
R8
+
C4
C3
C10
TL10
TL4
TL1
TL2
TL3
TL4
TP1
C1
DUT
TL5
TL7
TL9
C2
TL8
TL6
C5
C6
TL11
C7
C8
VCC
RF
OUTPUT
RF
INPUT
Q1
Order this document
by MRF6401PHT/D
MOTOROLA
SEMICONDUCTOR TECHNICAL DATA
MRF6401
PHOTOMASTER
CASE 305C02, STYLE 1
SOE200PILL
Motorola, Inc. 1995
MRF6401 PHOTOMASTER
4
MOTOROLA RF DEVICE DATA
