M3500-2032 (2000-3200 MH
Z
)
21
1L. M3500-2032 VCO T
ECHNICAL
S
PECIFICATIONS
2L. P
ERFORMANCE
C
URVES FOR
M3500-2032
A
BSOLUTE
M
AXIMUM
/ M
INIMUM
R
ATINGS
G
UARANTEED
P
ERFORMANCE
(0-70 C)
T
YPICAL
P
ERFORMANCE
(0-70 C)
PARAMETER
RATING
Maximum Supply Voltage
+15.0V
Tuning Voltage Min/Max
0/20V
PARAMETER
DATA
Nominal Supply Voltage
+12V
Power Output (50
)
+10 dBm
Typical Current
45mA
Tuning Voltage
2.0-14.0 V
FM(Phase)Noise:
10 kHz Offset
<- 82 dBc/Hz
100 kHz Offset
<-100 dBc/Hz
1 MHz Offset
<-118 dBc/Hz
Frequency Pushing
3.5 MHz/V for 12 1V
Frequency Pulling (12dB Return Loss)
6 MHz peak-peak
Harmonic Spurious (Average)
-15 dBc
Tuning Port Bandwidth:
@ Tuning Voltage = 2.0V
16.1 MHz
@ Tuning Voltage = 8.0V
29.8 MHz
@ Tuning Voltage = 13.4V
36.4 MHz
PARAMETER
DATA
Power Dissipation
600 mW max
(50 mA @ +12V)
Frequency Tuning Range
2000 to 3200 MHz min
Power Output (50
)
8 dBm min
2000-3200 MH
Z
T
YPICAL
O
UTPUT
F
REQUENCY
/ M
ODULATION
S
ENSITIVITY
V
ERSUS
T
UNING
V
OLTAGE
2000-3200 MH
Z
VCO T
YPICAL
O
UTPUT
P
OWER
V
ERSUS
T
UNING
V
OLTAGE
MICRONETICS / 26 HAMPSHIRE DRIVE / HUDSON, NH 03051 / TEL: 603-883-2900 / FAX: 603-882-8987 / CUSTOMER HOTLINE: 1-800-963-3382 / WEB: WWW.MWIRELESS.COM
