1996
DATA SHEET
MOS FIELD EFFECT TRANSISTOR
2SK2158
N-CHANNEL MOS FET
FOR HIGH-SPEED SWITCHING
Document No. D11234EJ1V0DS00 (1st edition)
Date Published June 1996 P
Printed in Japan
The 2SK2158 is an N-channel vertical type MOS FET featur-
ing an operating voltage as low as 1.5 V. Because it can be
driven on a low voltage and it is not necessary to consider
driving current, the 2SK2158 is suitable for use in low-voltage
portable systems such as headphone stereo sets and camcorders.
FEATURES
Capable of drive gate with 1.5 V
Because of high input impedance, there is no need to
consider driving current.
Bias resistance can be omitted, enabling reduction in total
number of parts.
ABSOLUTE MAXIMUM RATINGS (T
A
= 25 C)
PARAMETER
SYMBOL
TEST CONDITIONS
RATINGS
UNIT
Drain to Source Voltage
V
DSS
V
GS
= 0
50
V
Gate to Source Voltage
V
GSS
V
DS
= 0
7.0
V
Drain Current (DC)
I
D(DC)
0.1
A
Drain Current (pulse)
I
D(pulse)
PW
10 ms,
0.2
A
Duty Cycle
50 %
Total Power Dissipation
P
T
200
mW
Channel Temperature
T
ch
150
C
Storage Temperature
T
stg
55 to +150
C
2.8
0.2
1.5
3
2
0.95
1
Marking
Marking: G23
3
1
2
Gate protection
diode
Internal
diode
EQUIVALENT CIRCUIT
0.65
+0.1
0.15
0.4
+0.1
0.05
0.4
+0.1
0.05
0.16
+0.1
0.06
0 to 0.1
2.9
0.2
0.95
0.3
1.1 to 1.4
PIN CONNECTION
1. Source (S)
2. Gate (G)
3. Drain (D)
PACKAGE DIMENSIONS
(in millimeters)
2SK2158
2
ELECTRICAL CHARACTERISTICS (T
A
= 25 C)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN.
TYP.
MAX.
UNIT
Drain Cut-off Current
I
DSS
V
DS
= 50 V, V
GS
= 0
1.0
A
Gate Leakage Current
I
GSS
V
GS
=
7.0 V, V
DS
= 0
3.0
A
Gate Cut-off Voltage
V
GS(off)
V
DS
= 3 V, I
D
= 1.0
A
0.5
0.7
1.1
V
Forward Transfer Admittance
| y
fs
|
V
DS
= 3 V, I
D
= 10 mA
20
mS
Drain to Source On-state Resistance
R
DS(on)1
V
GS
= 1.5 V, I
D
= 1.0 mA
32
50
Drain to Source On-state Resistance
R
DS(on)2
V
GS
= 2.5 V, I
D
= 10 mA
16
20
Drain to Source On-state Resistance
R
DS(on)3
V
GS
= 4.0 V, I
D
= 10 mA
12
15
Input Capacitance
C
iss
V
DS
= 3 V, V
GS
= 0
6
pF
Output Capacitance
C
oss
f = 1.0 MHz
8
pF
Reverse Transfer Capacitance
C
rss
1
pF
Turn-On Delay Time
t
d(on)
V
DD
= 3 V, I
D
= 20 mA
9
ns
Rise Time
t
r
V
GS(on)
= 3 V, R
G
= 10
48
ns
Turn-Off Delay Time
t
d(off)
R
L
= 150
21
ns
Fall Time
t
f
31
ns
2SK2158
3
TYPICAL CHARACTERISTICS (T
A
= 25 C)
T
A
- Ambient Temperature - C
dT - Derating Factor - %
100
80
60
40
20
0
30
60
90
120
150
DERATING FACTOR OF FORWARD BIAS
SAFE OPERATING AREA
V
DS
- Drain to Source Voltage - V
I
D
- Drain Current - mA
200
160
120
80
40
0
1
2
3
4
5
DRAIN CURRENT vs.
DRAIN TO SOURCE VOLTAGE
7 V
3.5 V
3.0 V
2.5 V
2.0 V
1.5 V
V
GS
= 1.0 V
V
GS
- Gate to Source Voltage - V
I
D
- Drain Current - mA
100
10
1
0.1
0.01
0.001
0
1
2
TRANSFER CHARACTERISITICS
I
D
- Drain Current - mA
|y
fs
| - Forward Transfer Admittance - S
1 000
100
10
1
0.1
1
10
100
1 000
FORWARD TRANSFER ADMITTANCE vs.
DRAIN CURRENT
V
DS
= 3 V
T
A
= 75 C
25 C
25 C
T
A
= 25 C
25 C
75 C
I
D
- Drain Current - mA
R
DS(on)
- Drain to Source On-state Resistance -
70
60
50
40
30
20
10
0
0.1
1
10
100
DRAIN TO SOURCE ON-STATE RESISTANCE
vs. DRAIN CURRENT
V
GS
= 1.5 V
V
GS
= 1.5 V
T
A
= 75 C
25 C
25 C
I
D
- Drain Current - mA
R
DS(on)
- Drain to Source On-state Resistance -
70
60
50
40
30
20
10
0
1
10
100
1 000
DRAIN TO SOURCE ON-STATE RESISTANCE
vs. DRAIN CURRENT
V
GS
= 2.5 V
T
A
= 75 C
25 C
25 C
V
DS
= 3 V
2SK2158
4
I
D
- Drain Current - mA
R
DS(on)
- Drain to Source On-state Resistance -
70
60
50
40
30
20
10
0
1
10
100
1 000
DRAIN TO SOURCE ON-STATE RESISTANCE
vs. DRAIN CURRENT
V
GS
= 4.0 V
V
GS
- Gate to Source Voltage - V
R
DS(on)
- Drain to Source On-state Resistance -
50
40
30
20
10
0
2
4
6
DRAIN TO SOURCE ON-STATE RESISTANCE
vs. GATE TO SOURCE VOLTAGE
I
D
= 10 mA
I
D
= 100 mA
V
DS
- Drain to Source Voltage - V
C
iss
, C
oss
, C
rss
- Capacitance - pF
10
5
2
1
0.5
0.2
0.1
1
2
5
10
20
50
100
CAPACITANCE vs.
DRAIN TO SOURCE VOLTAGE
C
iss
C
oss
I
D
- Drain Current - mA
t
d(on)
, t
r
, t
d(off)
, t
f
- Switching Time - ns
100
50
20
10
5
2
1
10
20
50
100
200
500
1 000
SWITCHING CHARACTERISTICS
V
GS
= 0
f = 1 MHz
C
rss
V
SD
- Source to Drain Voltage - V
I
SD
- Source to Drain Current - A
1
0.1
0.01
0.001
0.4
0.8
1.2
1.6
2
SOURCE TO DRAIN DIODE
FORWARD VOLTAGE
t
r
t
f
t
d(on)
t
d(off)
V
DD
= 3 V
V
GS(on)
= 3 V
R
G
= 10
V
GS
= 4.0 V
T
A
= 75 C
25 C
25 C
2SK2158
5
