Rev. 1.2 March 11, 2002
n
Surface Mountable.
n
Small Size Flat Ceramic Package (7.6 x 12.7 x 3 mm).
n
Operating Speed :
OD-S589A (155 Mbps : STM-1/OC3)
OD-S589B (622 Mbps : STM-4/OC12)
n
High Sensitivity.
n
Differential Outputs.
n
Internal Supply Bypass Capacitor
n
Wide Operating Temperature Range :
-
40 to + 85C..
n
Detachable Pigtail Interface.
n
Single Supply Voltage from 3.0 to 3.5V.
n
Subscriber Loop.
n
Telecommunications.
n
Data Communications.
n
Local Area Networks.
Values
Parameter
Symbol Unit
Min.
Typ.
Max.
Notes
Optical Input Power
Pin
mW
-
2
-
Supply Voltage
V
DD
V
-
+ 5.5
-
Operating Temperature
Top
C
-
40
-
+ 85
Storage Temperature
Tstg
C
-
40
-
+ 85
Lead Soldering Temperature
Tsol
C
-
+230
(30sec)
-
reflow soldering
FEATURES
ABSOLUTE MAXIMUM RATINGS
(Ta=+25C,unless noted)
APPLICATION
OD-S589A/-S589B
SMT-InGaAs PIN-Amp Module
Sales Department, Fiber Optic Devices Division
Optical Network Operations Unit, NEC Networks
NEC Corporation
1753 Shimonumabe,Nakahara-ku,Kawasaki,Kanagawa 211-8666,Japan
Tel:+81-44-435-5412 Fax:+81-44-435-5109
http://networks.nec.co.jp/on/dd/en/
Copyright 2002 NEC Corporation
NEC Electronics (Europe) GmbH
Sales and marketing of semiconductors across Europe
Oberratherstr. 4, 40472 Dusseldorf, Germany
Tel:+49-211-6503-979 FAX:+49-211-6503-358
USA&CANADA
NEC FiberOptech, Inc.
10050 North Wolfe Road, Suite SW1-290 Cupertino, CA 95014,USA
Tel: +1-408-863-2000 Fax: +1-408-863-2019
OD-S589A
OD-S589B
Parameter
Conditions
Unit
Min.
Typ
Min.
Min.
Typ
Min.
BER = 10
-10
dBm
-
-
36
-
35
-
-
31
-
30
Sensitivity
-
40
85
C
-
-
32
-
-
-
-
Optical Overload
dBm
-
3
0
-
-
3
0
-
Band Width
3dB down
MHz
100
150
-
500
600
-
Trans Impedance
k
-
44
-
-
21
-
Operating Voltage
V
+ 3.0
+ 3.3
+ 3.5
+ 3.0
+ 3.3
+ 3.5
Responsivity
A/W
-
0.9
-
-
0.9
-
OPTICAL / ELECTRICAL CHARACTERISTICS
(Ta=+25C, unless noted)
DIMENSIONS
(Unit:mm)
DATA SUBJECT TO CHANGE WITHOUT NOTICE
7.62
0.2
0.2
2.9
12.7
0.2
2.54
7.62
0.
13
1.27
