OUTLINE DRAWING
Maximum Ratings
Approx Net Weight:0.30g
Rating
Symbol
EA60QC04-F Unit
Repetitive Peak Reverse Voltage
V
RRM
40 V
Non-repetitive Peak Reverse Voltage
V
RSM
45 V
P.C.Board
mounted *
2.0
Ta=21
C
Average Rectified
Output Current
-
I
O
6.0 Tc=118
C
50Hz Full Sine Wave
Resistive Load
A
RMS Forward Current
I
F(RMS)
6.66 A
Surge Forward Current
I
FSM
45
50Hz Full Sine Wave,1cycle,
Non-repetitive
A
Operating JunctionTemperature Range
Tjw
- 40 to + 150
C
Storage Temperature Range
Tstg
- 40 to + 150
C
Electrical
Thermal Characteristics
Characteristics Symbol
Conditions
Min Typ
Max
Unit
Peak Reverse Current
I
RM
Tj=25
C,V
RM
=V
RRM
per Arm
- - 3.0 mA
Peak Forward Voltage
V
FM
Tj=25
C,I
FM
= 3A per Arm
- - 0.55 V
Junction to Ambient Rth(j-a) P.C.Board mounted *
-
-
80
C/W
Thermal
Resistance
Junction to Case
Rth(j-c)
-
-
-
5
C/W
* Print Land = 20x20 mm
SBD
Type :
EA
EA
EA
EA60QC04
60QC04
60QC04
60QC04----F
F
F
F
FEATURES
* TO-252AA Case, Surface Mount Device
* Dual Diodes Cathode Common
* Low Forward Voltage drop
* Low Power Loss
* High Surge Capability
* 30 Volts thru 100 Volts Types Available
* Packaged in 16mm Tape and Reel
