54FCT574
Octal D-Type Flip-Flop with TRI-STATE
Outputs
General Description
The 'FCT574 is an octal flip-flop with a buffered common
Clock (CP) and a buffered common Output Enable (OE). The
information presented to the D inputs is stored in the
flip-flops on the LOW-to-HIGH Clock (CP) transition.
The device is functionally identical to the 'FCT374 except for
the pinouts.
Features
n
Inputs and outputs on opposite sides of package
allowing easy interface with microprocessors
n
Useful as input or output port for microprocessors
n
Functionally identical to 'FCT374
n
TRI-STATE outputs for bus-oriented applications
n
Output sink capability of 32 mA, source capability of
12 mA
n
TTL input and output level compatible
n
CMOS power consumption
n
Standard Microcircuit Drawing (SMD) 5962-8951301
Ordering Code
Military
Package Number
Package Description
54FCT574DMQB
J20A
20-Lead Ceramic Dual-In-Line
54FCT574FMQB
W20A
20-Lead Cerpack
54FCT574LMQB
E20A
20-Lead Ceramic Leadless Chip Carrier, Type C
Connection Diagrams
Pin Descriptions
Pin
Description
Names
D
0
D
7
Data Inputs
CP
Clock Pulse Input
(Active Rising Edge)
OE
TRI-STATE Output Enable
Input (Active LOW)
O
0
O
7
TRI-STATE Outputs
TRI-STATE
is a registered trademark of National Semiconductor Corporation.
Pin Assignment for DIP and Flatpak
DS100966-1
Pin Assignment
for LCC
DS100966-2
October 1999
54FCT574
Octal
D-T
ype
Flip-Flop
with
TRI-ST
A
T
E
Outputs
1999 National Semiconductor Corporation
DS100966
www.national.com
Functional Description
The 'FCT574 consists of eight edge-triggered flip-flops with
individual D-type inputs and TRI-STATE true outputs. The
buffered clock and buffered Output Enable are common to all
flip-flops. The eight flip-flops will store the state of their indi-
vidual D inputs that meet the setup and hold times require-
ments on the LOW-to-HIGH Clock (CP) transition. With the
Output Enable (OE) LOW, the contents of the eight flip-flops
are available at the outputs. When OE is HIGH, the outputs
are in a high impedance state. Operation of the OE input
does not affect the state of the flip-flops.
Function Table
Inputs
Internal Outputs
Function
OE
CP
D
Q
O
H
H or L
L
NC
Z
Hold
Inputs
Internal Outputs
Function
OE
CP
D
Q
O
H
H or L
H
NC
Z
Hold
H
N
L
L
Z
Load
H
N
H
H
Z
Load
L
N
L
L
L
Data Available
L
N
H
H
H
Data Available
L
H or L
L
NC
NC
No Change in Data
L
H or L
H
NC
NC
No Change in Data
H = HIGH Voltage Level
L = LOW Voltage Level
X = Immaterial
Z = High Impedance
N = LOW-to-HIGH Transition
NC = No Change
Logic Diagram
DS100966-3
Please note that this diagram is provided only for the understanding of logic operations and should not be used to estimate propagation delays.
54FCT574
www.national.com
2
Absolute Maximum Ratings
(Note 1)
If Military/Aerospace specified devices are required,
please contact the National Semiconductor Sales Office/
Distributors for availability and specifications.
Storage Temperature
-65C to +150C
Ambient Temperature under Bias
-55C to +125C
Junction Temperature under Bias
Ceramic
-55C to +175C
V
CC
Pin Potential to Ground Pin
-0.5V to +7.0V
Input Voltage (Note 2)
-0.5V to +7.0V
Input Current (Note 2)
-30 mA to +5.0 mA
Voltage Applied to Any Output in
the Disabled or Power-Off State
-0.5V to 5.5V
in the HIGH State
-0.5V to V
CC
Current Applied to Output
in LOW State (Max)
twice the rated I
OL
(mA)
DC Latchup Source Current
-500 mA
Recommended Operating
Conditions
Free Air Ambient Temperature
Military
-55C to +125C
Supply Voltage
Military
+4.5V to +5.5V
Note 1: Absolute maximum ratings are values beyond which the device may
be damaged or have its useful life impaired. Functional operation under these
conditions is not implied.
Note 2: Either voltage limit or current limit is sufficient to protect inputs.
DC Electrical Characteristics
Symbol
Parameter
FCT574
Units
V
CC
Conditions
Min
Max
V
IH
Input HIGH Voltage
2.0
V
Recognized HIGH Signal
V
IL
Input LOW Voltage
0.8
V
Recognized LOW Signal
V
CD
Input Clamp Diode Voltage
-1.2
V
Min
I
IN
= -18 mA
V
OH
Output HIGH
Voltage
54FCT
4.3
V
Min
I
OH
= -300 A
54FCT
2.4
V
Min
I
OH
= -12 mA
V
OL
Output LOW Voltage
54FCT
0.2
V
Min
I
OL
= 300 A
54FCT
0.5
V
Min
I
OL
= 32mA
I
IH
Input HIGH Current
5
A
Max
V
IN
= 2.7V (Note 3)
5
V
IN
= V
CC
I
IL
Input LOW Current
-5
A
Max
V
IN
= 0.5V (Note 3)
-5
V
IN
= 0.0V
I
OZH
Output Leakage Current
10
A
0 - 5.5V
V
OUT
= 2.7V; OE = 2.0V
I
OZL
Output Leakage Current
-10
A
0 - 5.5V
V
OUT
= 0.5V; OE = 2.0V
I
OS
Output Short-Circuit Current
-60
mA
Max
V
OUT
= 0.0V
I
CCQ
Power Supply Current
1.5
mA
Max
V
IN
= 0.2V or V
IN
= 5.3V, f
I
=
0MHz
I
CC
Power Supply Current
2.0
mA
Max
V
IN
= 3.4V
I
CCT
Additional
I
CC
/Input
6.0
mA
Max
V
I
= V
CC
- 2.1V or V
IN
= GND, f
CP
= 10MHz, Outputs open, OE =
GND, one bit toggling at f
I
= 5MHz,
50% duty cycle
5.5
mA
Max
V
I
= 5.3V or V
CC
= 0.2V, f
CP
=
10MHz, Outputs open, OE = GND,
one bit toggling at f
I
= 5MHz, 50%
duty cycle
I
CCD
Dynamic I
CC
No Load
0.40
mA/
MHz
Max
Outputs Open, OE = GND, One bit
toggling, 50% duty cycle, V
IN
=
5.3V or V
IN
= 0.2V
Note 3: Guaranteed, but not tested.
54FCT574
www.national.com
3
AC Electrical Characteristics
54FCT
Fig.
No.
T
A
= -55C to +125C
Symbol
Parameter
V
CC
= 4.5V to 5.5V
Units
C
L
= 50 pF
Min
Max
t
PLH
Propagation Delay
2.0
11.0
ns
Figure 4
t
PHL
CP to O
n
2.0
11.0
t
PZH
Output Enable Time
1.5
14.0
ns
Figure 6
t
PZL
1.5
14.0
t
PHZ
Output Disable Time
1.5
8.0
ns
Figure 6
t
PLZ
1.5
8.0
AC Operating Requirements
54FCT
T
A
= -55C to +125C
Fig.
Symbol
Parameter
V
CC
= 4.5V to 5.5V
Units
No.
C
L
= 50 pF
Min
Max
t
s
(H)
Setup Time, HIGH
3.5
ns
Figure 7
t
s
(L)
or LOW D
n
to CP
3.5
t
h
(H)
Hold Time, HIGH
2.0
ns
Figure 7
t
h
(L)
or LOW D
n
to CP
2.0
t
w
(H)
Pulse Width, CP,
7.0
ns
Figure 5
t
w
(L)
HIGH or LOW
7.0
Capacitance
Symbol
Parameter
Typ
Units
Conditions
T
A
= 25C
C
IN
Input Capacitance
5.0
pF
V
CC
= 0V
C
OUT
(Note 4)
Output Capacitance
9.0
pF
V
CC
= 5.0V
Note 4: C
OUT
is measured at frequency f = 1 MHz, per MIL-STD-883B, Method 3012.
54FCT574
www.national.com
4
AC Loading
DS100966-4
*Includes jig and probe capacitance
FIGURE 1. Standard AC Test Load
DS100966-6
FIGURE 2. V
M
= 1.5V
Input Pulse Requirements
Amplitude
Rep. Rate
t
w
t
r
t
f
3.0V
1 MHz
500 ns
2.5 ns
2.5 ns
FIGURE 3. Test Input Signal Requirements
DS100966-8
FIGURE 4. Propagation Delay Waveforms for
Inverting and Non-Inverting Functions
DS100966-5
FIGURE 5. Propagation Delay,
Pulse Width Waveforms
DS100966-7
FIGURE 6. TRI-STATE Output HIGH
and LOW Enable and Disable Times
DS100966-9
FIGURE 7. Setup Time, Hold Time
and Recovery Time Waveforms
54FCT574
www.national.com
5
Physical Dimensions
inches (millimeters) unless otherwise noted
20-Terminal Ceramic Chip Carrier (L)
NS Package Number E20A
20-Lead Ceramic Dual-In-Line Package (D)
NS Package Number J20A
54FCT574
www.national.com
6
Physical Dimensions
inches (millimeters) unless otherwise noted (Continued)
LIFE SUPPORT POLICY
NATIONAL'S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE SUPPORT
DEVICES OR SYSTEMS WITHOUT THE EXPRESS WRITTEN APPROVAL OF THE PRESIDENT AND GENERAL
COUNSEL OF NATIONAL SEMICONDUCTOR CORPORATION. As used herein:
1. Life support devices or systems are devices or
systems which, (a) are intended for surgical implant
into the body, or (b) support or sustain life, and
whose failure to perform when properly used in
accordance with instructions for use provided in the
labeling, can be reasonably expected to result in a
significant injury to the user.
2. A critical component is any component of a life
support device or system whose failure to perform
can be reasonably expected to cause the failure of
the life support device or system, or to affect its
safety or effectiveness.
National Semiconductor
Corporation
Americas
Tel: 1-800-272-9959
Fax: 1-800-737-7018
Email: support@nsc.com
National Semiconductor
Europe
Fax: +49 (0) 1 80-530 85 86
Email: europe.support@nsc.com
Deutsch Tel: +49 (0) 1 80-530 85 85
English
Tel: +49 (0) 1 80-532 78 32
Franais Tel: +49 (0) 1 80-532 93 58
Italiano
Tel: +49 (0) 1 80-534 16 80
National Semiconductor
Asia Pacific Customer
Response Group
Tel: 65-2544466
Fax: 65-2504466
Email: sea.support@nsc.com
National Semiconductor
Japan Ltd.
Tel: 81-3-5639-7560
Fax: 81-3-5639-7507
www.national.com
20-Lead Ceramic Flatpak (F)
NS Package Number W20A
54FCT574
Octal
D-T
ype
Flip-Flop
with
TRI-ST
A
T
E
Outputs
National does not assume any responsibility for use of any circuitry described, no circuit patent licenses are implied and National reserves the right at any time without notice to change said circuitry and specifications.
