DS90C363/DS90CF364
+3.3V Programmable LVDS Transmitter 18-Bit Flat Panel
Display (FPD) Link-- 65 MHz,
+3.3V LVDS Receiver
18-Bit Flat Panel Display (FPD) Link-- 65 MHz
General Description
The DS90C363 transmitter converts 21 bits of CMOS/TTL
data into three LVDS (Low Voltage Differential Signaling)
data streams. A phase-locked transmit clock is transmitted in
parallel with the data streams over a fourth LVDS link. Every
cycle of the transmit clock 21 bits of input data are sampled
and transmitted. The DS90CF364 receiver converts the
LVDS data streams back into 21 bits of CMOS/TTL data. At
a transmit clock frequency of 65 MHz, 18 bits of RGB data
and 3 bits of LCD timing and control data (FPLINE,
FPFRAME, DRDY) are transmitted at a rate of 455 Mbps per
LVDS data channel. Using a 65 MHz clock, the data through-
puts is 170 Mbytes/sec. The Transmitter is offered with pro-
grammable edge data strobes for convenient interface with a
variety of graphics controllers. The Transmitter can be pro-
grammed for Rising edge strobe or Falling edge strobe
through a dedicated pin. A Rising edge Transmitter will inter-
operate with a Falling edge Receiver (DS90CF364) without
any translation logic.
This chipset is an ideal means to solve EMI and cable size
problems associated with wide, high speed TTL interfaces.
Features
n
20 to 65 MHz shift clock support
n
Programmable Transmitter (DS90C363) strobe select
(Rising or Falling edge strobe)
n
Single 3.3V supply
n
Chipset (Tx + Rx) power consumption
<
250 mW (typ)
n
Power-down mode (
<
0.5 mW total)
n
Single pixel per clock XGA (1024x768) ready
n
Supports VGA, SVGA, XGA and higher addressability.
n
Up to 170 Megabyte/sec bandwidth
n
Up to 1.3 Gbps throughput
n
Narrow bus reduces cable size and cost
n
290 mV swing LVDS devices for low EMI
n
PLL requires no external components
n
Low profile 48-lead TSSOP package
n
Falling edge data strobe Receiver
n
Compatible with TIA/EIA-644 LVDS standard
n
ESD rating
>
7 kV
n
Operating Temperature: -40C to +85C
Block Diagrams
TRI-STATE
is a registered trademark of National Semiconductor Corporation.
Application
DS012886-14
September 1999
DS90C363/DS90CF364
+3.3V
Programmable
L
VDS
18-Bit-Color
Flat
Panel
Display
(FPD)
Link
--
6
5
MHz
1999 National Semiconductor Corporation
DS012886
www.national.com
Block Diagrams
(Continued)
DS90C363
DS012886-1
Order Number DS90C363MTD
See NS Package Number MTD48
DS90CF364
DS012886-24
Order Number DS90CF364MTD
See NS Package Number MTD48
www.national.com
2
Absolute Maximum Ratings
(Note 1)
If Military/Aerospace specified devices are required,
please contact the National Semiconductor Sales Office/
Distributors for availability and specifications.
Supply Voltage (V
CC
)
-0.3V to +4V
CMOS/TTL Input Voltage
-0.3V to (V
CC
+ 0.3V)
CMOS/TTL Output Voltage
-0.3V to (V
CC
+ 0.3V)
LVDS Receiver Input Voltage
-0.3V to (V
CC
+ 0.3V)
LVDS Driver Output Voltage
-0.3V to (V
CC
+ 0.3V)
LVDS Output Short Circuit
Duration
Continuous
Junction Temperature
+150C
Storage Temperature
-65C to +150C
Lead Temperature
(Soldering, 4 sec)
+260C
Maximum Package Power Dissipation Capacity 25C
MTD48 (TSSOP) Package:
DS90C363
1.98 W
DS90CF364
1.89 W
Package Derating:
DS90C363
16 mW/C above +25C
DS90CF364
15 mW/C above +25C
ESD Rating
(HBM, 1.5 k
, 100 pF)
>
7 kV
Recommended Operating
Conditions
Min
Nom
Max
Units
Supply Voltage (V
CC
)
3.0
3.3
3.6
V
Operating Free Air
Temperature (T
A
)
-40
+25
+85
C
Receiver Input Range
0
2.4
V
Supply Noise Voltage (V
CC
)
100
mV
PP
Electrical Characteristics
Over recommended operating supply and temperature ranges unless otherwise specified.
Symbol
Parameter
Conditions
Min
Typ
Max
Units
CMOS/TTL DC SPECIFICATIONS
V
IH
High Level Input Voltage
2.0
V
CC
V
V
IL
Low Level Input Voltage
GND
0.8
V
V
OH
High Level Output Voltage
I
OH
= -0.4 mA
2.7
3.3
V
V
OL
Low Level Output Voltage
I
OL
= 2 mA
0.06
0.3
V
V
CL
Input Clamp Voltage
I
CL
= -18 mA
-0.79
-1.5
V
I
IN
Input Current
V
IN
= V
CC
, GND, 2.5V or 0.4V
5.1
10
A
I
OS
Output Short Circuit Current
V
OUT
= 0V
-60
-120
mA
LVDS DC SPECIFICATIONS
V
OD
Differential Output Voltage
R
L
= 100
250
345
450
mV
V
OD
Change in V
OD
between
35
mV
complimentary output states
V
OS
Offset Voltage (Note 4)
1.125
1.25
1.375
V
V
OS
Change in V
OS
between
35
mV
complimentary output states
I
OS
Output Short Circuit Current
V
OUT
= 0V, R
L
= 100
-3.5
-5
mA
I
OZ
Output TRI-STATE
Current
PWR DWN = 0V,
1
10
A
V
OUT
= 0V or V
CC
V
TH
Differential Input High Threshold
V
CM
= +1.2V
+100
mV
V
TL
Differential Input Low Threshold
-100
mV
I
IN
Input Current
V
IN
= +2.4V, V
CC
= 3.6V
10
A
V
IN
= 0V, V
CC
= 3.6V
10
A
TRANSMITTER SUPPLY CURRENT
ICCTW
Transmitter Supply Current, Worst
Case
R
L
= 100
,
C
L
= 5 pF, Worst
Case Pattern
(Figures
1, 3 ), T
A
= -40C to
+85C
f = 32.5 MHz
31
45
mA
f = 37.5 MHz
32
50
mA
f = 65 MHz
42
55
mA
ICCTG
Transmitter Supply Current, 16
Grayscale
R
L
= 100
,
C
L
= 5 pF, 16
Grayscale Pattern
(Figures 2, 3 ), T
A
=
-40C to +85C
f = 32.5 MHz
23
35
mA
f = 37.5 MHz
28
40
mA
f = 65 MHz
31
45
mA
www.national.com
3
Electrical Characteristics
(Continued)
Over recommended operating supply and temperature ranges unless otherwise specified.
Symbol
Parameter
Conditions
Min
Typ
Max
Units
TRANSMITTER SUPPLY CURRENT
ICCTZ
Transmitter Supply Current
PWR DWN = Low
10
55
A
Power Down
Driver Outputs in TRI-STATE
under
Power Down Mode
RECEIVER SUPPLY CURRENT
ICCRW
Receiver Supply Current, Worst
Case
C
L
= 8 pF, Worst
Case Pattern
(Figures
1, 4 ), T
A
= -40C to
+85C
f = 32.5 MHz
49
65
mA
f = 37.5 MHz
53
70
mA
f = 65 MHz
78
105
mA
ICCRG
Receiver Supply Current, 16
Grayscale
C
L
= 8 pF, 16
Grayscale Pattern
(Figures 2, 4 ), T
A
=
-40C to +85C
f = 32.5 MHz
28
45
mA
f = 37.5 MHz
30
47
mA
f = 65 MHz
43
60
mA
ICCRZ
Receiver Supply Current
PWR DWN = Low
10
55
A
Power Down
Receiver Outputs Stay Low during
Power Down Mode
Note 1: "Absolute Maximum Ratings" are those values beyond which the safety of the device cannot be guaranteed. They are not meant to imply that the device
should be operated at these limits. The tables of "Electrical Characteristics" specify conditions for device operation.
Note 2: Typical values are given for V
CC
= 3.3V and T
A
= +25C.
Note 3: Current into device pins is defined as positive. Current out of device pins is defined as negative. Voltages are referenced to ground unless otherwise speci-
fied (except V
OD
and
V
OD
).
Note 4: V
OS
previously referred as V
CM
.
www.national.com
4
Transmitter Switching Characteristics
Over recommended operating supply and -40C to +85C ranges unless otherwise specified
Symbol
Parameter
Min
Typ
Max
Units
LLHT
LVDS Low-to-High Transition Time
(Figure 3 )
0.75
1.5
ns
LHLT
LVDS High-to-Low Transition Time
(Figure 3 )
0.75
1.5
ns
TCIT
TxCLK IN Transition Time
(Figure 5 )
5
ns
TCCS
TxOUT Channel-to-Channel Skew
(Figure 6 )
250
ps
TPPos0
Transmitter Output Pulse Position for Bit 0
(Figure 17 )
f = 65 MHz
-0.4
0
0.3
ns
TPPos1
Transmitter Output Pulse Position for Bit 1
1.8
2.2
2.5
ns
TPPos2
Transmitter Output Pulse Position for Bit 2
4.0
4.4
4.7
ns
TPPos3
Transmitter Output Pulse Position for Bit 3
6.2
6.6
6.9
ns
TPPos4
Transmitter Output Pulse Position for Bit 4
8.4
8.8
9.1
ns
TPPos5
Transmitter Output Pulse Position for Bit 5
10.6
11.0
11.3
ns
TPPos6
Transmitter Output Pulse Position for Bit 6
12.8
13.2
13.5
ns
TCIP
TxCLK IN Period
(Figure 7)
15
T
50
ns
TCIH
TxCLK IN High Time
(Figure 7)
0.35T
0.5T
0.65T
ns
TCIL
TxCLK IN Low Time
(Figure 7)
0.35T
0.5T
0.65T
ns
TSTC
TxIN Setup to TxCLK IN
(Figure 7 )
f = 65 MHz
2.5
ns
THTC
TxIN Hold to TxCLK IN
(Figure 7 )
0
ns
TCCD
TxCLK IN to TxCLK OUT Delay 25C, V
CC
= 3.3V
(Figure 9 )
3.0
3.7
5.5
ns
TPLLS
Transmitter Phase Lock Loop Set
(Figure 11 )
10
ms
TPDD
Transmitter Power Down Delay
(Figure 15 )
100
ns
www.national.com
5
