LMV101/102/105/110
Fixed-Gain Amplifiers
General Description
The LMV101/102/105/110 fixed-gain amplifier family inte-
grates a rail-to-rail op amp, two internal gain-setting resistors
and a V
+
/2 bias circuit into one ultra tiny package, SC70-5 or
SOT23-5. Fixed inverting gains of -1, -2, -5, and -10 are
available.
The core op amp in this series is an LMV321, which provides
rail-to-rail output swing, excellent speed-power ratio, 1MHz
bandwidth, and 1V/s of slew rate with low supply current.
The LMV101/102/105/110 family reduces external compo-
nent count. It is the most cost effective solution for applica-
tions where low voltage operation, low power consumption,
space savings, and reliable performance are needed. It en-
ables the design of small portable electronic devices, and al-
lows the designer to place the device closer to the signal
source to reduce noise pickup and increase signal integrity.
Features
(For 5V Supply, Typical Unless Otherwise Noted)
n
Fixed inverting gain available
-1,-2,-5,-10
n
DC gain accuracy
@
2.7V supply
-- LMV101/102/105
2% (typ)
-- LMV110
6% (typ)
n
Space saving packages
SC70-5 & SOT23-5
n
Industrial temperature range
-40C to +85C
n
Low supply current
130A
n
Rail-to-Rail output swing
n
Guaranteed 2.7V and 5V performance
Applications
n
General purpose portable devices
n
Mobile communications
n
Battery powered electronics
n
Active filters
n
Microphone preamplifiers
Typical Application
Phase Inverting AC Amplifier
DS101234-10
V
OUT
= 0.5V
CC
-V
IN
(R
2
/R
1
)
August 2000
LMV101/102/105/1
10
Fixed-Gain
Amplifiers
2000 National Semiconductor Corporation
DS101234
www.national.com
Absolute Maximum Ratings
(Note 1)
If Military/Aerospace specified devices are required,
please contact the National Semiconductor Sales Office/
Distributors for availability and specifications.
ESD Tolerance (Note 2)
Machine Model
200V
Human Body Model
1500V
Supply Voltage (V
+
- V
-
)
5.5V
Output Short Circuit to V
+
(Note 3)
Output Short Circuit to V
-
(Note 4)
Mounting Temperature
Infrared or Convection (20 sec)
235C
Storage Temperature Range
-65C to 150C
Junction Temperature (T
J
, max)
(Note 5)
150C
Operating Ratings
(Note 1)
Supply Voltage
2.7V to 5.0V
Temperature Range
-40C
T
J
85C
Thermal resistance (
JA
)
5-pin SC70-5
478C/W
5-pin SOT23-5
265C/W
2.7V Electrical Characteristics
Unless otherwise specified, all limits guaranteed for T
J
= 25C, V
+
= 2.7V, V
-
= 0V, V
O
= V
+
/2 and R
L
>
1M
. Boldface lim-
its apply at the temperature extremes.
Symbol
Parameter
Conditions
Typ
(Note 6)
Max
(Note 7)
Units
V
O
Output Swing
R
L
= 10k
to 1.35V
V
+
-0.01
V
+
-0.1
V
min
0.08
0.18
V
max
I
S
Supply Current
80
170
A
max
DC Gain Accuracy
LMV101, Gain = -1
2
5
%
LMV102, Gain = -2
2
5
%
LMV105, Gain = -5
2
6
%
LMV110, Gain = -10
6
12
%
GBW
-3dB Bandwidth
LMV101, Gain = -1,
R
L
= 2k
, C
L
= 100pF
1.6
MHz
LMV102, Gain = -2,
R
L
= 2k
, C
L
= 100pF
1.8
MHz
LMV105, Gain = -5,
R
L
= 2k
, C
L
= 100pF
0.8
MHz
LMV110, Gain = -10,
R
L
= 2k
, C
L
= 100pF
0.2
MHz
5V Electrical Characteristics
Unless otherwise specified, all limits guaranteed for T
J
= 25C, V
+
= 5V, V
-
= 0V, V
O
= V
+
/2 and R
L
>
1M
. Boldface limits
apply at the temperature extremes.
Symbol
Parameter
Conditions
Typ
(Note 6)
Max
(Note 7)
Units
V
O
Output Swing
R
L
= 2k
to 2.5V
V
+
-0.04
V
+
-0.3
V
+
-0.4
V
min
0.14
0.3
0.4
V
max
R
L
= 10k
to 2.5V
V
+
-0.01
V
+
-0.1
V
+
-0.2
V
min
0.1
0.18
0.28
V
max
I
O
Output Current
Sourcing, V
O
= 0V
60
5
mA
min
Sinking, V
O
= 5V
160
10
mA
min
LMV101/102/105/1
10
www.national.com
2
5V Electrical Characteristics
(Continued)
Unless otherwise specified, all limits guaranteed for T
J
= 25C, V
+
= 5V, V
-
= 0V, V
O
= V
+
/2 and R
L
>
1M
. Boldface limits
apply at the temperature extremes.
Symbol
Parameter
Conditions
Typ
(Note 6)
Max
(Note 7)
Units
I
S
Supply Current
130
250
350
A
max
DC Gain Accuracy
LMV101, Gain = -1
3.5
5
%
LMV102, Gain = -2
3.5
5
%
LMV105, Gain = -5
3.5
6
%
LMV110, Gain = -10
9.0
12
%
SR
Slew Rate
(Note 8)
1
V/s
GBW
-3dB Bandwidth
LMV101, Gain = -1,
R
L
= 2k
, C
L
= 100pF
1.6
MHz
LMV102, Gain = -2,
R
L
= 2k
, C
L
= 100pF
1.8
MHz
LMV105, Gain = -5,
R
L
= 2k
, C
L
= 100pF
0.8
MHz
LMV110, Gain = -10,
R
L
= 2k
, C
L
= 100pF
0.2
MHz
Note 1: Absolute Maximum Ratings indicate limits beyond which damage to the device may occur. Operating Ratings indicate conditions for which the device is in-
tended to be functional, but specific performance is not guaranteed. For guaranteed specifications and the test conditions, see the Electrical Characteristics.
Note 2: Human body model, 1.5k
in series with 100pF. Machine model, 0
in series with 100pF.
Note 3: Shorting circuit output to V
+
will adversely affect reliability.
Note 4: Shorting circuit output to V
-
will adversely affect reliability.
Note 5: The maximum power dissipation is a function of T
J(max)
,
JA
, and T
A
. The maximum allowable power dissipation at any ambient temperature is
P
D
= (T
J(max)
T
A
)/
JA
. All numbers apply for packages soldered directly into a PC board.
Note 6: Typical Values represent the most likely parametric norm.
Note 7: All limits are guaranteed by testing or statistical analysis.
Note 8: Number specified is the slower of the positive and negative slew rates.
Typical Performance Characteristics
(Unless otherwise specified, V
S
= +5V, single supply, T
A
=
25C.)
Supply Current vs.
Supply Voltage
DS101234-22
Sourcing Current
vs. Output Voltage
DS101234-23
LMV101/102/105/1
10
www.national.com
3
Typical Performance Characteristics
(Unless otherwise specified, V
S
= +5V, single supply, T
A
=
25C.) (Continued)
Sourcing Current vs.
Output Voltage
DS101234-24
Sinking Current vs.
Output Voltage
DS101234-25
Sinking Current vs.
Output Voltage
DS101234-26
Output Voltage Swing vs.
Supply Voltage
DS101234-21
LMV101 Close Loop
Frequency Response
DS101234-27
LMV101 Close Loop
Frequency Response
DS101234-28
LMV101/102/105/1
10
www.national.com
4
Typical Performance Characteristics
(Unless otherwise specified, V
S
= +5V, single supply, T
A
=
25C.) (Continued)
LMV102 Close Loop
Frequency Response
DS101234-29
LMV102 Close Loop
Frequency Response
DS101234-30
LMV105 Close Loop
Frequency Response
DS101234-31
LMV105 Close Loop
Frequency Response
DS101234-32
LMV110 Close Loop
Frequency Response
DS101234-33
LMV110 Close Loop
Frequency Response
DS101234-34
LMV101/102/105/1
10
www.national.com
5
