NTE2365
Silicon NPN Transistor
High Voltage Horizontal Deflection Output
Features:
D
High Speed: t
f
= 100ns typ
D
High Reliability
D
High Breakdown Voltage: V
CBO
= 1500V
Absolute Maximum Ratings: (T
A
= +25
C unless otherwise specified)
Collector to Base Voltage, V
CBO
1500V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Collector to Emitter Voltage, V
CEO
800V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emitter to Base Voltage, V
EBO
6V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Collector Current, I
C
Continuous
12A
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Peak
30A
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Collector Dissipation, P
C
180W
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Junction Temperature, T
J
+150
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage Temperature Range, T
stg
55
to +150
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Characteristics: (T
A
= +25
C unless otherwise specified)
Parameter
Symbol
Test Conditions
Min
Typ
Max Unit
Collector Cutoff Current
I
CBO
V
CB
= 800V, I
E
= 0
10
A
I
CES
V
CE
= 1500V, R
BE
= 0
1.0
mA
Collector Sustaining Voltage
V
CEO(sus)
I
C
= 100mA, I
B
= 0
800
V
Emitter Cutoff Current
I
EBO
V
EB
= 4V, I
C
= 0
1.0
mA
CollectorEmitter Saturation Voltage
V
CE(sat)
I
C
= 10A, I
B
= 2.5A
5
V
BaseEmitter Saturation Voltage
V
BE(sat)
I
C
= 10A, I
B
= 2.5A
1.5
V
DC Current Gain
h
FE(1)
V
CE
= 5V, I
C
= 1A
8
30
h
FE(2)
V
CE
= 5V, I
C
= 10A
4
8
Storage Time
t
stg
I
C
= 8A, I
B1
= 1.6A, I
B2
= 3.2A
3.0
s
Fall Time
t
f
0.2
s
