NTE605A
Silicon Varistor
Temperature Compensating Diode
Features:
D
High Reliability Planar Chip and Glass Sealing
D
Low I
R
D
Large P
D
Absolute Maximum Ratings: (T
A
= +25
C unless otherwise specified)
Maximum Forward Current, I
FM
100mA
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reverse Voltage, V
R
6V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Dissipation, P
D
150mW
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Junction Temperature, T
J
+150
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage Temperature Range, T
stg
55
to +150
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Characteristics: (T
A
= +25
C unless otherwise specified)
Parameter
Symbol
Test Conditions
Min
Typ
Max
Unit
Reverse Current
I
R
V
R
= 6V
1
A
Forward Voltage
V
F
I
F
= 1.5mA
0.77
V
I
F
= 3mA
1.26
1.36
V
Forward Voltage Change with Respect to Temperature
V
F
/
T
I
F
= 3mA
4.6
mV/
C
.076 (1.94) Dia Max
Colored Band Indicates Cathode
.022 (0.56)
Dia Max
.177
(4.5)
Max
.944
(24.0)
.944
(24.0)
