NTE974
Integrated Circuit
PhaseFrequency Detector
Description:
The NTE974 consists of two digital phase detectors, a charge pump, and an amplifier. In combination
with a voltage controlled multivibrator, it is useful in a broad range of phaselocked loop applications.
The circuit accepts MTTL waveforms at the R and V inputs and generates an error voltage that is pro-
portional to the frequency and/or phase difference of the input signals. Phase detector #1 is intended
for use in systems requiring zero frequency and phase difference at lock. Phase detector #2 is used
if quadrature lock is desired. Phase detector #2 can also be used to indicate that the main loop, utiliz-
ing phase detector #1, is out of lock.
Absolute Maximum Ratings:
Supply Operating Voltage Range
4.75 to 5.25V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Supply Voltage, V
CC
+7.0V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input Voltage, V
I
+5.5V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Output Voltage, V
O
+5.5V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating Temperature Range, T
opr
0
to +75
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage Temperature Range, T
stg
55
to +125
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum Junction Temperature, T
J
+150
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermal Resistance, JunctiontoCase, R
thJC
0.07
C/mW
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermal Resistance, JunctiontoAmbient, R
thJA
0.15
C/mW
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Characteristics: (T
A
= +25
C unless otherwise spcified)
Parameter
Symbol
Pin
Test Conditions
Min
Typ
Max
Unit
Input
Forward Current
I
IL
1, 3
V
IL
= 0.4V, V
CCH
= 5.25V
4.8
mA
11
1.6
mA
Leakage Current
I
IH
1, 3
V
IH
= 5.5V, V
CCH
= 5.25V
120
A
4
V
CCH
= 5.25V
5.0
A
11
V
IH
= 5.5V, V
CCH
= 5.25V
40
A
I
IHH
1, 3, 11 V
IHH
= 5.5V, V
CCH
= 5.25V
1.0
mA
Clamp Voltage
V
IC
1, 3
I
IC
= 10 mA, V
CCL
= 4.75V
1.5
V
Note 1. The outputs of the device must be tested by sequencing through the indicated input states
according to the truth table. All input, power supply, and ground voltages must be maintained
between tests unless otherwise noted.
Note 2. Input Loading Factor: R, V = 3
Output Loading Factor (Pin8) = 10
Total Power Dissipation = 85mW Typ/Pkg
Propagation Delay Time = 9ns Typ (thru phase detector)
Electrical Characteristics (Cont'd): (T
A
= +25
C unless otherwise spcified)
Parameter
Symbol
Pin
Test Conditions
Min
Typ
Max
Unit
Output (Note 1)
Ouput Voltage
V
OH
6, 12
I
OH1
= 1.6mA, V
ILT
= 1.1V, V
CCL
= 4.75V
2.5
V
V
OL
6
I
OL
= 20mA, V
IHT
= 1.8V, V
CCL
= 4.75V
0.4
V
V
OH
12
I
OH1
= 1.6mA, V
IHT
= 1.8V, V
CCL
= 4.75V
2.5
V
V
OH
6
I
OH1
= 1.6mA, V
ILT
= 1.1V, V
IHT
= 1.8V, V
CCL
= 4.75V
2.5
V
V
OL
12
I
OL
= 20mA, V
ILT
= 1.1V, V
IHT
= 1.8V, V
CCL
= 4.75V
0.4
V
V
OH
2
I
OH1
= 1.6mA, V
ILT
= 1.1V, V
CCL
= 4.75V
2.5
V
V
OL
13
I
OL
= 20mA, V
ILT
= 1.1V, V
CCL
= 4.75V
0.4
V
V
OH
2
I
OH1
= 1.6mA, V
ILT
= 1.1V, V
IHT
= 1.8V, V
CCL
= 4.75V
2.5
V
V
OL
13
I
OL
= 20mA, V
ILT
= 1.1V, V
IHT
= 1.8V, V
CCL
= 4.75V
0.4
V
V
OH
2, 13
I
OH1
= 1.6mA, V
ILT
= 1.1V, V
CCL
= 4.75V
2.5
V
V
OH
2, 13
I
OH1
= 1.6mA, V
ILT
= 1.1V, V
IHT
= 1.8V, V
CCL
= 4.75V
2.5
V
V
OL
2
I
OL
= 20mA, V
ILT
= 1.1V, V
CCL
= 4.75V
0.4
V
V
OH
13
I
OH1
= 1.6mA, V
ILT
= 1.1V, V
CCL
= 4.75V
2.5
V
V
OL
2
I
OL
= 20mA, V
ILT
= 1.1V, V
IHT
= 1.8V, V
CCL
= 4.75V
0.4
V
V
OH
13
I
OH1
= 1.6mA, V
ILT
= 1.1V, V
IHT
= 1.8V, V
CCL
= 4.75V
2.5
V
V
OL
2
I
OL
= 20mA, V
ILT
= 1.1V, V
CCL
= 4.75V
2.5
V
V
OH
13
I
OH1
= 1.6mA, V
ILT
= 1.1V, V
CCL
= 4.75V
2.5
V
V
OL
2
I
OL
= 20mA, V
ILT
= 1.1V, V
IHT
= 1.8V, V
CCL
= 4.75V
2.5
V
V
OH
13
I
OH1
= 1.6mA, V
ILT
= 1.1V, V
IHT
= 1.8V, V
CCL
= 4.75V
2.5
V
V
OH
2, 13
I
OH1
= 1.6mA, V
ILT
= 1.1V, V
CCL
= 4.75V
2.5
V
Short Circuit
I
OS
2
V
IHT
= 1.8V
20
65
mA
Current
6, 12
V
CC
= 5V
20
65
mA
13
V
IHT
= 1.8V, V
CC
= 5V
20
65
mA
CollectorEmitter
I
OLK
2, 13
V
IHT
= 1.8V, V
CC
= 5V
250
A
Voltage
6, 12
V
CC
= 5V
250
A
Output Voltage
V
EH
10
I
OH2
= 1.0mA, V
ILT
= 1.1V, V
CCL
= 4.75V
1.5
V
Output Current
I
O
8
I
A
= 0.002mA, V
CCH
= 5.25V
0.8
mA
Leakage Current
I
OLK
8
V
CCH
= 5.25V
120
A
10
V
IH
= 2.5V, V
out
= 1.5V, V
CCH
= 5.25V
5.0
A
Power Requirements (Total Device)
Power Supply
Drain
I
CC
14
V
CC
= 5V
40
mA
Note 1. The outputs of the device must be tested by sequencing through the indicated input states
according to the truth table. All input, power supply, and ground voltages must be maintained
between tests unless otherwise noted.
Note 2. Input Loading Factor: R, V = 3
Output Loading Factor (Pin8) = 10
Total Power Dissipation = 85mW Typ/Pkg
Propagation Delay Time = 9ns Typ (thru phase detector)
