February 2001
O
K
I
O
P
T
I
C
A
L
C
O
M
P
O
N
E
N
T
S
D
ATA
S
HEET
Preliminary
OF3603N-F5
Avalanche Photo Diode
Preamp Module
Oki Semiconductor
1
Oki Semiconductor
OF3603N-F5
Preliminary
Avalanche Photo Diode Preamp Module
DESCRIPTION
Oki Semiconductor's OF3603N-F5 surface-mount type APD Preamp module is an avalanche photo diode
coupled to a single-mode fiber pigtail. The OF3603N-F5 is designed for STM16/OC48 optical systems.
FEATURES
APPLICATION
Avalanche photo diode
Surface mount APD-preamp module
Coupled to a single mode fiber with a pigtail
STM16/OC48 optical systems
Optical access networks
2
Oki Semiconductor
I
I
ABSOLUTE MAXIMUM RATINGS
(Ta=25C, unless otherwise specified)
ELECTRICAL CHARACTERISTICS
(Condition: Ta=25C, VCC=+3.3V)
Absolute Maximum Ratings
Parameter
Ratings
Unit
Supply Voltage
6
V
Optical Input Power
0
dBm
Forward Current (I
F
)
5
mA
Reverse Current (I
R
)
0.5
mA
Operating Temperature (Ta)
-40 to 85
C
Storage Temperature
-40 to 85
C
Lead Soldering Temperature (10 sec)
260
C
Electrical Characteristics
Parameter
Conditions
Min
Typ
Max
Unit
TIA Supply Voltage
-
+3.0
+3.3
+3.6
V
TIA Supply Current
-
-
41
-
mA
Reverse breakdown Voltage (V
BR
)
I
D
= 100 nA
-
70
-
V
Temperature Efficiency of V
BR
-40 to 85
C
0.15
-
0.22
Dark Current
V
R
= V
BR
x 0.9
-
5
-
nA
Bandwidth
f
3 dB
1300
-
-
MHz
Responsivity
Differential,
measured with -30 dBm signal.
M = 10
200
250
-
kV/W
Sensitivity
BER < 10
-10
(Note1)
-30.0
-33.0
-
dBm
Input Power before clipping
-
-
-24
-
dBm
Maximum Differential Output Voltage
-
450
520
-
mVp-p
Optical Overload
AC Input (Note 2)
-6.0
-
-
dBm
Low Frequency Cut-off
f
3 dB
-
65
-
kHz
Note 1:
Data rate: 2.5 Gbps; data sequence: PRBS 2
23
-1.
Note 2:
If using a resistance outside the module of 1 k to 5 k
in serial, you can get -6 dBm @ 25C.
3
Oki Semiconductor
I
I
PACKAGE DIMENSIONS
(Units: mm)
Connector and Fiber Specifications
Connector
SC-PC
Fiber
1.31
m Single Mode Fiber
Code Diameter : 0.9 mm
Color : Dark Blue
Bending Radius : 20 mm (min)
Heat-resistant
Length : 575 to 625 mm
Pin Configuration
Pin No.
Description
Pin No.
Description
01
Vcc
05
OUTP (+)
02
GND
06
NC
03
GND
07
APD-Vias
04
OUTN (-)
08
GND
#8
1.0
R1
2.5
11.2
#5
1.75
2.54x3
0.46
0.25
1.8
1.0
7.62
#1
#4
5.6
0.17
Max 3mm
(TOP VIEW)
4
Oki Semiconductor
I
I
