Oki Semiconductor
OL3902W
Preliminary
Planer Lightwave Circuit Module
DESCRIPTION
Oki Semiconductor's OL3902W bidirectional PLC module is a high reliability hybrid-integrated Planer
Lightwave Circuit Module using a plastic package. The OL3902W is designed for 1.3
m and 1.5 m bidi-
rectional transmission. The PLC module consists of a spot-size converted laser diode (SSC-LD), a photo
diode (PD), a monitor PD, a preamplifier, a fiber pigtail, and a PLC platform that is a silicon terrace on
which the active optical devices are assembled.
FEATURES
APPLICATION
Hybrid-integrated planer lightwave circuit
- spot-size converted laser diode (SSC-LD)
- photo diode
- monitor photo diode
- preamplifier
- fiber pigtail
- PLC platform
1.3-m and 1.5-m bidirectional transmission
Plastic package
Optical systems
Bidirectional transmission
2
Oki Semiconductor
I
I
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
ONU Transmitter: 155 Mbit/sec upstream direction
ONU Receiver: 155 Mbit/sec downstream direction
(Ta= -20 to 70
C
, unless otherwise specified)
Absolute Maximum Ratings
Parameter
Ratings
Unit
Operating Temperature (Ta)
-20 to
70
C
Storage Temperature
-40 to
85
C
Lead Soldering Temperature (10 sec)
260
C
Electrical Characteristics
Parameter
Conditions
Min
Typ
Max
Unit
Transmitter
Bit rate
155.52
Mbps
Fiber Output Power
Pf
CW
-2
4
dBm
Threshold Current
Ith
-
34
mA
Center Wavelength
c
Pf = 3 dBm, RMS
1270
1350
nm
Spectral Width
Dl
Pf =
3
dBm, RMS (
)
5.8
nm
LD Forward Voltage
Vop
Pf =
3
dBm
1.45
V
LD Forward Current
Iop
Pf =
3
dBm
80
mA
Rise and Fall times
tr, tf
Pf =
3
dBm
1
ns
Monitor Current
Im
P =
3
dBm
100
400
A
Monitor Dark Current
Id
Pf =
3
dBm, Ta = 25C
15
nA
Tracking Error
Er
Im = const.
@ Pf = 3 dBm (25C)
-1
1
dB
Receiver
Power Supply Voltage
Vcc
-
3.0
3.3
3.6
V
Responsivity
Re
Pin = -21 dBm,
Vcc = 3.3 V
34
40
kV / W
Output Bias Voltage
Vb
Pin = 0 mW,
Vcc = 3.3+/- 0.01 V,
Tc = 25C,
2.3
2.35
2.4
V
Transimpedance
Zt
-
96
Rise and Fall times
tr, tf
10% - 90%
1
2
ns
Return Loss
Rl
= 1480 to 1580
nm
20
dB
3
Oki Semiconductor
I
I
PACKAGE DIMENSIONS
(Units: mm)
Connector and Fiber Specifications
Connector
FC-PC, SC-PC, MUJ-PC, etc.
Fiber
1.31
m Single Mode Fiber
Code Diameter : 0.9 mm
Color : Yellow
Bending Radius : 20 mm (min)
Heat-resistant
Length : Options
3.5
23.7
2.54
0.46
GND
12.16
10.16
8.2
PD Cathode
PD Anode
GND
LD Cathode
LD Anode
Monitor PD Anode
Monitor PD Cathode
NC
GND
Vout
Vcc
TOP VIEW
GND
GND
