s
Suitable for handling low signals in
computer peripherals, telecommunica-
tions and security equipment
s
Capable of switching loads up to 2 A
s
Conforms to FCC part 68 1500 V surge
withstand
s
Reliable bifurcated crossbar contacts
s
Fully-sealed construction
Low Signal Relay
G5V-2
Ordering Information
Specifications
s
CONTACT DATA
Load
Resistive load (p.f. = 1)
Rated load
0.50 A at 125 VAC
2 A at 30 VDC
Contact material
Ag (Au clad)
Carry current
2 A
Max. operating voltage
125 VAC
125 VDC
Max. operating current
2 A
Max. switching capacity
62.50 VA
60W
Min. permissible load
10
A, 10 mVDC
To Order: Select the part number and add the desired coil voltage rating (e.g., G5V-2-
DC12).
Type
Contact form
Construction
Part number
Standard
DPDT
Fully-sealed
G5V-2
High-sensitivity
G5V-2-H
Ultra-sensitive
G5V-2-H1
2
G5V-2
G5V-2
Rated
Rated
Coil
Coil inductance
Pick-up
Dropout
Maximum
Power
voltage
current
resistance
(Ref. value) (H)
voltage
voltage
voltage
consumption
(VDC)
(mA)
(
)
Armature OFF
Armature ON
% of rated voltage
(mW)
3
120
25
0.04
0.07
75% max.
5% min.
120% max. Approx. 360
5
72
70
0.12
0.19
at 70
C
6
60
100
0.18
0.29
(158
F)
9
40
225
0.40
0.62
12
30
400
0.75
1.18
24
15
1,600
3.16
4.81
48
7.5
6,400
--
--
110% max.
at 70
C
(158
F)
Note:
1. The rated current and coil resistance are measured at a coil temperature of 23
C (73
F) with a tolerance of
10%.
2. The operating characteristics are measured at a coil temperature of 23
C (73
F).
High-sensitivity type
Ultra-sensitive type
s
COIL DATA
Standard type
Rated
Rated
Coil
Coil inductance
Pick-up
Dropout
Maximum
Power
voltage
current
resistance
(Ref. value) (H)
voltage
voltage
voltage
consumption
(VDC)
(mA)
(
)
Armature OFF
Armature ON
% of rated voltage
(mW)
3
166.70
18
0.04
0.05
75% max.
5% min.
120% max. Approx. 500
5
100
50
0.09
0.11
at 65
C
6
83.30
72
0.16
0.19
(149
F)
9
55.60
162
0.31
0.49
12
41.70
288
0.47
0.74
24
20.80
1,152
1.98
2.68
48
12
4,000
--
--
110% max. Approx. 580
at 60
C
(140
F)
Rated
Rated
Coil
Coil inductance
Pick-up
Dropout
Maximum
Power
voltage
current
resistance
(Ref. value) (H)
voltage
voltage
voltage
consumption
(VDC)
(mA)
(
)
Armature OFF
Armature ON
% of rated voltage
(mW)
3
50
60
0.18
0.26
75% max.
5% min.
150% max. Approx. 150
5
30
166.70
0.46
0.71
at 70
C
6
25
240
0.70
0.97
(158
F)
9
16.70
540
1.67
2.33
12
12.50
960
2.90
3.99
24
8.30
2,880
6.72
9.27
Approx. 200
48
6.25
7,680
20.10
26.70
Approx. 300
3
G5V-2
G5V-2
Contact resistance
50 m
max. G5V-2, G5V-2-H, 100 m
max. G5V-2-H1
Operate time
7 ms max. (mean value: approx. 3.5 ms)
Release time
3 ms max. (mean value: approx. 0.8 ms)
Bounce time
Operate
Mean value: approx. 0.5 ms
Release
Mean value: approx. 3.5 ms
Operating frequency
Mechanical
36,000 operations/hour
Electrical
1,800 operations/hour (under rated load)
Insulation resistance
1,000 M
min (at 500 VDC)
Dielectric strength
1,000 VAC, 50/60 Hz for 1 minute between coil and contacts
1,000 VAC, 50/60 Hz for 1 minute between contacts of different poles
750 VAC, 50/60 Hz for 1 minute between contacts of same poles
(500 VAC, 50/60 Hz for 1 minute between contacts of same poles for
ultra-sensitive type)
Surge withstand voltage
1,500 V 10 X 160
s (conforms to part 68 of FCC rules)
Vibration
Mechanical durability
10 to 55 Hz, 1.50 mm (0.59 in) double amplitude
Malfunction durability
Shock
Mechanical durability
1,000 m/s
2
(approx. 100 G)
Malfunction durability
200 m/s
2
(approx. 20 G)
Ambient temperature
Operating/storage
-25
to 70
C (-13
to 158
F)
Humidity
35% to 85% RH
Service life
Mechanical
15 million operations min. (at operating frequency of 36,000 operations/hour)
Electrical
See "Characteristic Data"
Weight
6 g (0.21 oz)
s
CHARACTERISTICS
s
CHARACTERISTIC DATA
Maximum switching capacity
Electrical service life
Ambient temperature vs.
maximum voltage
Rated operating current (A)
Rated operating voltage (V)
Ser
vice lif
e (x10
3
oper
ations)
Rated operating current (A)
Maximum voltage (%)
Ambient temperature [
C (
F)]
---- 48 VDC coil voltage (standard type)
All other types and voltages
Note:
Data shown are of initial value.
4
G5V-2
G5V-2
Dimensions
Unit: mm (inch)
Fully-sealed
Terminal arrangement/Internal
Mounting holes
(bottom view)
(bottom view)
Type
Contact form
Coil rating
Contact ratings
G5V-2
DPDT
3 to 48 VDC
0.6 A, 125 VAC
G5V-2-H
3 to 24 VDC
0.6 A,110 VDC
2.0 A, 30 VDC
G5V-2-H1
3 to 48 VDC
0.6 A, 125 VAC
0.6 A, 110 VDC
1.0 A, 24 VDC
s
APPROVALS
UL (File No. E41515)/CSA (File No. LR24825)
Note:
1. and indicate mounting orientation marks.
2. A tolerance of
0.10 (0.004) applies to the above dimensions.
123456
123456
123456
s
RELAYS
Note:
1. The rated values approved by each of the safety standards may be different from the performance characteristics individually
defined in this catalog.
2. In the interest of product improvement, specifications are subject to change.
3. Complies with UL1950 Basic Insulation at 125 V (pollution degree 1 for internal spacings, pollution degree 2 for external
spacings).
OMRON ELECTRONICS, INC.
OMRON CANADA, INC.
One East Commerce Drive
885 Milner Avenue
Schaumburg, IL 60173
Scarborough, Ontario M1B 5V8
1-800-55-OMRON
416-286-6465
Cat. No. GC RLY7
01/00
Specifications subject to change without notice.
Printed in the U.S.A.
