LB 5433, LV 5433, LT 5433
Hyper 5 mm (T1 ) LED, Non Diffused
Hyper-Bright LED
LV 5433 abgekndigt nach PD_078_02 - wird durch
LV 543C ersetzt werden
LV 5433 obsolete acc. to PD_078_02 - will be
replaced by LV 543C
2003-08-05
1
Besondere Merkmale
Gehusetyp: klares 5 mm (T1 ) Gehuse
Besonderheit des Bauteils: enge
Abstrahlcharakteristik
Wellenlnge: 470 nm (blau), 505 nm (verde),
528 nm (true green)
Abstrahlwinkel: 40
Technologie: InGaN
optischer Wirkungsgrad: 2 lm/W (blau),
6 lm/W (verde), 8 lm/W (true green)
Gruppierungsparameter: Lichtstrke,
Wellenlnge
Ltmethode: Wellenlten (TTW)
Verpackung: Schttgut, gegurtet lieferbar
ESD-Festigkeit: ESD-sicher bis 2 kV nach
EOS/ESD-5.1-1993
Anwendungen
Informationsanzeigen im Auenbereich
optischer Indikator
Hinterleuchtung (Tasten, Displays,
Werbebeleuchtung, Allgemeinbeleuchtung)
Innenbeleuchtung im Automobilbereich
(z.B. Instrumentenbeleuchtung, u. .)
Ersatz von Kleinst-Glhlampen
Signal- und Symbolleuchten
Markierungsbeleuchtung (z.B. Stufen,
Fluchtwege, u..)
Features
package: clear 5 mm (T1 ) package
feature of the device: narrow viewing angle
wavelength: 470 nm (blue), 505 nm (verde),
528 nm (true green)
viewing angle: 40
technology: InGaN
optical efficiency: 2 lm/W (blue),
6 lm/W (verde), 8 lm/W (true green)
grouping parameter: luminous intensity,
wavelength
soldering methods: TTW soldering
packing: bulk, available taped on reel
ESD-withstand voltage: up to 2 kV acc. to
EOS/ESD-5.1-1993
Applications
outdoor displays
optical indicators
backlighting (keys, displays, illuminated
advertising, general lighting)
interior automotive lighting (e.g. dashboard
backlighting, etc.)
substitution of micro incandescent lamps
signal and symbol luminaire
marker lights (e.g. steps, exit ways, etc.)
2003-08-05
2
LB 5433, LV 5433, LT 5433
s
LV 5433 abgekndigt nach PD_078_02 - wird durch LV 543C ersetzt werden
LV 5433 obsolete acc. to PD_078_02 - will be replaced by LV 543C
Letzte Bestellung / Last Order: 30.09.2003
Letzte Lieferung / Last Delivery: 31.03.2004
Anm.: -35 gesamter Farbbereich, Lieferung in Einzelgruppen (siehe Seite 5)
Die Standardlieferform von Serientypen beinhaltet eine untere bzw. eine obere Familiengruppe
oder mindestens zwei Einzelgruppen.
In einer Verpackungseinheit / Gurt ist immer nur eine Helligkeitsgruppe enthalten.
Die technologiebedingte Helligkeits-Streuung der heutigen LED-Herstellprozesse ber einen
lngeren Fertigungszeitraum (Halbleitermaterial - Chipherstellung - Montageprozess) erlaubt
keine Zusage einer einzelnen Helligkeitsgruppe. Daher mssen mindestens zwei
Helligkeitsgruppen vorgesehen werden!
Note: -35 Total color tolerance range, delivery in single groups (please see page 5)
The standard shipping format for serial types includes a lower or upper family group or at least
two individual groups.
No packing unit / tape ever contains more than one luminous intensity group.
Luminosity variations caused by the technology used in current LED manufacturing processes
over a protracted manufacturing period (semiconductor material - chip fabrication - assembly
process) mean that it is not possible to assign LEDs to a single luminous intensity group. For this
reason at least two luminous intensity groups must be provided!
Typ
Type
Emissions-
farbe
Color of
Emission
Gehusefarbe
Color of
Package
Lichtstrke
Luminous
Intensity
I
F
= 20 mA
I
V
(mcd)
Lichtstrom
Luminous
Flux
I
F
= 20 mA
V
(mlm)
Bestellnummer
Ordering Code
LB 5433-QU-35
blue
colorless clear
71 ... 710
210 (typ.)
Q62703Q4843
s
LV 5433-TBW-35 verde
colorless clear
280 ... 2800
750 (typ.)
Q62703Q4850
LT 5433-TBW-35
true green
colorless clear
280 ... 2800
750 (typ.)
Q62703Q4857
LB 5433, LV 5433, LT 5433
2003-08-05
3
Grenzwerte
Maximum Ratings
Bezeichnung
Parameter
Symbol
Symbol
Wert
Value
Einheit
Unit
LB
LV, LT
Betriebstemperatur
Operating temperature range
T
op
55 ... + 100
C
Lagertemperatur
Storage temperature range
T
stg
55 ... + 100
C
Sperrschichttemperatur
Junction temperature
T
j
+ 100
C
Durchlassstrom
Forward current
I
F
20
mA
Stostrom
Surge current
t
10
s,
D
= 0.005
I
FM
200
250
mA
Sperrspannung
1)
Reverse voltage
V
R
5
V
Leistungsaufnahme
Power consumption
T
A
25 C
P
tot
80
mW
Wrmewiderstand
2)
Thermal resistance
Sperrschicht/Umgebung
Junction/ambient
Sperrschicht/Ltpad
Junction/solder point
Montage auf PC-Board FR 4 (Padgre
16 mm
2
)
mounted on PC board FR 4 (pad size
16 mm
2
)
Minimale Beinchenlnge
Minimum lead length
R
th JA
R
th JS
400
180
K/W
K/W
1)
fr kurzzeitigen Betrieb geeignet / suitable for short term application
2)
R
th
erhht sich um 13 K/W pro mm Beinchenlnge.
Each additional 1 mm of lead length increases R
th
by 13 K/W.
2003-08-05
4
LB 5433, LV 5433, LT 5433
Kennwerte (
T
A
= 25 C)
Characteristics
Bezeichnung
Parameter
Symbol
Symbol
Werte
Values
Einheit
Unit
LB
LV
LT
Wellenlnge des emittierten Lichtes
(typ.)
Wavelength at peak emission
I
F
= 20 mA
peak
465
503
523
nm
Dominantwellenlnge
1)
(typ.)
Dominant wavelength
I
F
= 20 mA
dom
470
6
505
7
528
9
nm
Spektrale Bandbreite bei 50 %
I
rel max
(typ.)
Spectral bandwidth at 50 %
I
rel max
I
F
= 20 mA
25
30
33
nm
Abstrahlwinkel bei 50 %
I
V
(Vollwinkel)
(typ.)
Viewing angle at 50 %
I
V
2
40
40
40
Grad
deg.
Durchlassspannung
2)
(min.)
Forward voltage
(typ.)
I
F
= 20 mA
(max.)
V
F
V
F
V
F
2.9
3.5
3.9
2.9
3.3
3.9
2.9
3.3
3.9
V
V
V
Sperrstrom
(typ.)
Reverse current
(max.)
V
R
= 5 V
I
R
I
R
0.01
10
0.01
10
0.01
10
A
A
Temperaturkoeffizient von
peak
(typ.)
Temperature coefficient of
peak
I
F
= 20 mA; 10C
T
100C
TC
peak
0.04
0.03
0.04
nm/K
Temperaturkoeffizient von
dom
(typ.)
Temperature coefficient of
dom
I
F
= 20 mA; 10C
T
100C
TC
dom
0.03
0.04
0.04
nm/K
Temperaturkoeffizient von
V
F
(typ.)
Temperature coefficient of
V
F
I
F
= 20 mA; 10C
T
100C
TC
V
4.5
3.6
3.6
mV/K
Optischer Wirkungsgrad
(typ.)
Optical efficiency
I
F
= 20 mA
opt
2
6
8
lm/W
1)
Wellenlngengruppen werden mit einer Stromeinprgedauer von 25 ms und einer Genauigkeit von 1 nm ermittelt.
Wavelength groups are tested at a current pulse duration of 25 ms and a tolerance of 1 nm.
2)
Durchlassspannungsgruppen werden mit einer Stromeinprgedauer von 1 ms und einer Genauigkeit von 0,05 V
ermittelt.
Forward voltage groups are tested at a current pulse duration of 1 ms and a tolerance of 0.05 V.
LB 5433, LV 5433, LT 5433
2003-08-05
5
1)
Wellenlngengruppen / Wavelength groups
Helligkeitswerte werden mit einer Stromeinprgedauer von 25 ms und einer Genauigkeit von
11% ermittelt.
Luminous intensity is tested at a current pulse duration of 25 ms and a tolerance of
11%.
Gruppe
Group
blue
verde
true green
Einheit
Unit
min.
max. min.
max. min.
max.
3
464
468
498
503
519
525
nm
4
468
472
503
507
525
531
nm
5
472
476
507
512
531
537
nm
Helligkeits-Gruppierungsschema
Luminous Intensity Groups
Lichtgruppe
Luminous Intensity Group
Lichtstrke
Luminous Intensity
I
V
(mcd)
Lichtstrom
Luminous Flux
V
(mlm)
Q
R
S
T
U
V
AW
BW
71 ... 112
112 ... 180
180 ... 280
280 ... 450
450 ... 710
710 ... 1120
1120 ... 1800
1800 ... 2800
60 (typ.)
90 (typ.)
150 (typ.)
240 (typ.)
380 (typ.)
590 (typ.)
940 (typ.)
1500 (typ.)
Gruppenbezeichnung auf Etikett
Group Name on Label
Beispiel: T-1
Example: T-1
Lichtgruppe
Luminous Intensity Group
Wellenlnge
Wavelength
T
1
2003-08-05
6
LB 5433, LV 5433, LT 5433
Relative spektrale Emission
I
rel
=
f
(
),
T
A
= 25 C,
I
F
= 20 mA
Relative Spectral Emission
V(
) = spektrale Augenempfindlichkeit
Standard eye response curve
Abstrahlcharakteristik
I
rel
=
f
(
)
Radiation Characteristic
0
400
true green
550
450
500
600
650
nm
700
OHL00492
I
20
40
60
80
%
100
rel
verde
blue
V
OHL01089
0
20
40
60
80
100
120
0.4
0.6
0.8
1.0
100
90
80
70
60
50
0
10
20
30
40
0
0.2
0.4
0.6
0.8
1.0
LB 5433, LV 5433, LT 5433
2003-08-05
7
Durchlassstrom
I
F
=
f
(
V
F
)
Forward Current
T
A
= 25 C
Maximal zulssiger Durchlassstrom
I
F
=
f
(
T
)
Max. Permissible Forward Current
Relative Lichtstrke
I
V
/
I
V(20 mA)
=
f
(
I
F
)
Relative Luminous Intensity
T
A
= 25 C
Maximal zulssiger Durchlassstrom
I
F
=
f
(
T
)
Max. Permissible Forward Current
OHL00495
10
-1
2.5
3
3.5
4
4.5 V 5
0
10
1
10
10
2
5
5
mA
5
2
true green
verde,
blue
I
F
V
F
OHL01398
0
0
C
mA
F
I
T
5
10
15
20
25
30
20
40
60
80
100
temp. ambient
A
T
OHL00494
10
-2
-1
10
0
10
10
1
5
5
-1
10
10
0
10
1
10
mA
2
I
F
V
V (20 mA)
I
I
OHL01399
0
0
20
40
60
80 C 100
T
I
F
5
10
15
20
25
30
mA
temp. solder point
S
T
LB 5433, LV 5433, LT 5433
2003-08-05
8
Relative Lichtstrke
I
V
/
I
V(25 C)
=
f
(
T
A
)
Relative Luminous Intensity
I
F
= 20 mA
Dominante Wellenlnge
dom
=
f
(
I
F
)
Dominant Wavelength
LV
, T
A
= 25 C
Dominante Wellenlnge
dom
=
f
(
I
F
)
Dominant Wavelength
LB
, T
A
= 25 C
Dominante Wellenlnge
dom
=
f
(
I
F
)
Dominant Wavelength
LT
, T
A
= 25 C
OHL03637
-60
0
T
C
V (25 C)
I
I
V
-40 -20
0
20 40 60
100
0.2
0.4
0.6
0.8
1.0
1.2
1.4
true green
blue
verde
I
OHL10500
496
dom
0
mA
nm
20
40
60
80
120
f
498
500
502
504
506
508
510
512
516
verde
I
OHL10503
467
dom
0
mA
nm
20
40
60
80
120
468
469
470
471
472
473
474
blue
f
I
OHL00882
510
dom
0
mA
nm
20
40
60
80
120
515
520
525
530
535
540
550
f
true green
LB 5433, LV 5433, LT 5433
2003-08-05
9
Zulssige Impulsbelastbarkeit
I
F
=
f
(
t
p
)
Permissible Pulse Handling Capability
Duty cycle
D
= parameter,
T
A
= 25 C
LB
Zulssige Impulsbelastbarkeit
I
F
=
f
(
t
p
)
Permissible Pulse Handling Capability
Duty cycle
D
= parameter,
T
A
= 25 C
LV, LT
Zulssige Impulsbelastbarkeit
I
F
=
f
(
t
p
)
Permissible Pulse Handling Capability
Duty cycle
D
= parameter,
T
A
= 85 C
LB
Zulssige Impulsbelastbarkeit
I
F
=
f
(
t
p
)
Permissible Pulse Handling Capability
Duty cycle
D
= parameter,
T
A
= 85 C
LV, LT
OHL01409
0
F
I
10
10
-5
-4
-3
10
10
-2
10
-1
10
0
s
10
1
10
2
p
t
0.05
0.10
0.15
0.20
0.25
0.30
0.05
0.5
0.2
0.1
D
0.02
0.01
0.005
=
A
D
T
t
=
P
t
T
P
I
F
OHL01411
0
F
I
10
10
-5
-4
-3
10
10
-2
10
-1
10
0
s
10
1
10
2
p
t
0.05
0.5
0.2
0.1
D
0.02
0.01
0.005
=
0.05
0.15
0.10
0.25
0.20
A
0.35
0.30
D
T
t
=
P
t
T
P
I
F
OHL01410
0
F
I
10
10
-5
-4
-3
10
10
-2
10
-1
10
0
s
10
1
10
2
p
t
0.05
0.10
0.15
0.20
0.25
0.30
0.05
0.5
0.2
0.1
D
0.02
0.01
0.005
=
A
D
T
t
=
P
t
T
P
I
F
OHL01412
0
F
I
10
10
-5
-4
-3
10
10
-2
10
-1
10
0
s
10
1
10
2
p
t
0.05
0.10
0.15
0.20
0.25
0.30
0.05
0.5
0.2
0.1
D
0.02
0.01
0.005
=
A
D
T
t
=
P
t
T
P
I
F
2003-08-05
10
LB 5433, LV 5433, LT 5433
Mazeichnung
Package Outlines
Mae werden wie folgt angegeben: mm (inch) / Dimensions are specified as follows: mm (inch).
Kathodenkennung:
krzerer Ltspie
Cathode mark:
short solder lead
Gewicht / Approx. weight: 0.35 g
0.4 (0.016)
0.6 (0.024)
5.5 (0.217)
5.9 (0.232)
Area not flat
8.2 (0.323)
9.0 (0.354)
4.8 (0.189)
5.1 (0.201)
7.8 (0.307)
7.5 (0.295)
27.0 (1.063)
29.0 (1.142)
spacing
2.54 (0.100)
0.8 (0.031)
0.4 (0.016)
0.4 (0.016)
0.6 (0.024)
1.2 (0.047)
1.8 (0.071)
Cathode
GEXY6713
LB 5433, LV 5433, LT 5433
2003-08-05
11
Ltbedingungen
Soldering Conditions
Wellenlten (TTW)(nach CECC 00802)
TTW Soldering(acc. to CECC 00802)
Empfohlenes Ltpaddesign
Wellenlten (TTW)
Recommended Solder Pad
TTW Soldering
Mae werden wie folgt angegeben: mm (inch) / Dimensions are specified as follows: mm (inch).
OHLY0598
0
0
50
100
150
200
250
50
100
150
200
250
300
T
t
C
s
235 C
10 s
C
... 260
1. Welle
1. wave
2. Welle
2. wave
5 K/s
2 K/s
ca 200 K/s
C
C
... 130
100
2 K/s
Zwangskhlung
forced cooling
Normalkurve
standard curve
Grenzkurven
limit curves
4 (0.157)
OHLPY985
4.8 (1.890)
2003-08-05
12
LB 5433, LV 5433, LT 5433
Published by OSRAM Opto Semiconductors GmbH
Wernerwerkstrasse 2, D-93049 Regensburg
All Rights Reserved.
Attention please!
The information describes the type of component and shall not be considered as assured characteristics.
All typical data and graphs are basing on representative samples, but don't represent the production range. If requested,
e.g. because of technical improvements, these typ. data will be changed without any further notice.
Terms of delivery and rights to change design reserved. Due to technical requirements components may contain
dangerous substances. For information on the types in question please contact our Sales Organization.
If printed or downloaded, please find the latest version in the Internet.
Packing
Please use the recycling operators known to you. We can also help you get in touch with your nearest sales office.
By agreement we will take packing material back, if it is sorted. You must bear the costs of transport. For packing
material that is returned to us unsorted or which we are not obliged to accept, we shall have to invoice you for any costs
incurred.
Components used in life-support devices or systems must be expressly authorized for such purpose! Critical
components
1
may only be used in life-support devices or systems
2
with the express written approval of OSRAM OS.
1
A critical component is a component used in a life-support device or system whose failure can reasonably be expected
to cause the failure of that life-support device or system, or to affect its safety or the effectiveness of that device or
system.
2
Life support devices or systems are intended (a) to be implanted in the human body, or (b) to support and/or maintain
and sustain human life. If they fail, it is reasonable to assume that the health of the user may be endangered.
Revision History: 2003-08-05
Date of change
Previous Version:
2003-04-14
Page
Subjects (major changes since last revision)
3
thermal resistance (footnote)
4
value (forward voltage)
3
power consumption from 85 mW to 80 mW
2
verde not for new designs
12
annotations
2002-07-23
3
reverse voltage (footnote)
2002-08-21
all
verde: not for new designs
2002-11-18
4
values (temperature coefficient of
dom
and V
F
)
2003-04-14
1, 2
verde: obsolete
2003-08-05
PDF
ZIP
