99/8

Discharge Characteristics

External Dimensions (mm)

Specifications

2001/11

CGA533048

Lightweight prismatic model

Cycle Life Characteristics

Charge Characteristics

Nominal Voltage

3.6V

Standard Capacity

750mAh

Dimensions

Thickness

5.35+0/-0.6mm

Width

30.0+0/-0.6mm

Height

48.1+0/-1.0mm

Weight

Approx.16.5g

*1 After a fresh battery has been charged at constant voltage/constant current(4.2V, Max.700mA,

2hrs, 20癈), the average of the capacity (ending voltage of 3V at 20癈) that is discharged at a
standard current (140mA).

*2 Dimensions of a fresh battery

30.0+0/-0.6

48.1+0/-1.0

5.35+0/-0.6
