E L E C T R O N I C S I N C .
4 Line Common Mode Choke
TEL: (818) 892-0761
FAX: (818) 894-5791
http://www.pca.com
PCA ELECTRONICS, INC.
16799 SCHOENBORN ST.
NORTH HILLS, CA 91343
IEEE 802.3 and IEEE 802.5 compatible
Robust construction allows IR/VP reflow processes
Operating Temperature : 0C to +70C
500 Vrms Hipot
EPA2165
Product performance is limited to specified parameters. Data is subject to change without prior notice.
Package
Electrical Parameters @ 25 C
Unless Otherwise Specified Dimensions are in Inches /mm .010 /.25
CSA2165 Rev. Orig 6/30/03
Schematic
1
2
3
4
8
7
6
5
Interwinding Capacitance
(pF Max.)
100 KHz, 0.1 Vrms
15
Line to Line
DCR
(
Max.)
0.2
Each Line
OCL
(H 20%)
100 KHz, 0.1 Vrms
Leakage Inductance
(H Max.)
0.25
100 KHz, 0.1 Vrms
Insulation Resistance
(G
Min.)
@ 500 Vdc
10
Line to Line
ET Product
(V-uS)
2.5
85
Typical Impedance
0
1600
1400
1200
1000
800
600
400
200
1 10
100
Frequency (MHz)
20
30
40
50
60
70
80
90
Impedance (
)
.365 Max.
(9.27)
.500 Max.
(12.70)
.280
Max.
(7.11)
.150 Min. (3.81)
.015
Min.
(.381)
.230 Max.
(5.84)
.020 x .010
(.508 x .254)
Pin 1
I.D.
.100
(2.54)
PCA
EPA2165
D.C.
