Common Mode Choke
TEL: (818) 892-0761
FAX: (818) 894-5791
http://www.pca.com
PCA ELECTRONICS, INC.
16799 SCHOENBORN ST.
NORTH HILLS, CA 91343
250 Vrms Isolation
100 mA Rated Current
EPZ3018
Product performance is limited to specified parameters. Data is subject to change without prior notice.
Package
Unless Otherwise Specified Dimensions are in Inches /mm .010 /.25
CSZ3018 Rev. 3 3/19/03
Electrical Parameters @ 25C
Inductance
(mH 25%)
@ 10 KHz, 0.1 Vrms
4.0
Pins 1-2, 4-3
Turns Ratio
1:1
1-2:4-3
8.0
Pins 1-2, 4-3
DCR
(
Typ.)
1.0
SRF
(MHz Typ.)
Schematic
1
4
3
2
.500
(12.70)
Pin 1
I.D.
.256
(6.50)
.256
(6.50)
.187
(4.75)
.187
(4.75)
.150 (3.81)
.384
(9.75)
Marking :
PCA
EPZ3018
D.C.
140K
140K
120K
100K
80K
60K
40K
20K
0.1
MHz
1
MHz
10
MHz
50
MHz
0
Frequency
Impedance Graph
.025
(.660)
.020
(.510)
Bottom View
3
4
2
1
