E L E C T R O N I C S I N C .
Power Choke
TEL: (818) 892-0761
FAX: (818) 894-5791
http://www.pca.com
PCA ELECTRONICS, INC.
16799 SCHOENBORN ST.
NORTH HILLS, CA 91343
Used in DC/DC Converter
UL94V-0 Recognized Materials
UL1446 Clas B Insulating System
Operating Temperature : -40C to +85C
Noise suppression Choke
1.5 A Rated Current
250 Vrms Isolation
EPZ3035G
Product performance is limited to specified parameters. Data is subject to change without prior notice.
Electrical Parameters @ 25 C
Unless Otherwise Specified Dimensions are in Inches /mm .010 /.25
Schematic
1
4
2
3
Package
.340
(8.64)
PCA
EPZ3035G
D.C.
1
4
.560 Max.
(14.22)
.645
Max.
(16.38)
.350 Max.
(8.89)
.530
(13.46)
.060
(1.52)
.175
(4.45)
.520
(13.21)
2
3
1
4
2
3
Impedance Curve
Turns Ratio
1 : 1
Pins 1-2 : 3-4
SRF
(MHz Typ. )
2.0
1.0
Pins 1-2, 3-4
Inductance
(mH 30%)
@10 KHz, 0.1 Vrms
60
DCR
(m
Max.)
Pins 1-2, 3-4
Matched with 5%
CSZ3035G Rev. 1 10/28/03
Frequency
4K
6K
8K
10K
2K
0.1 MHz
1 MHz
20 MHz
10 MHz
0
1K
3K
5K
7K
9K
11K
