VTB Process Photodiodes
VTB9412B, 9413B
PRODUCT DESCRIPTION
Small area planar silicon photodiode in a
recessed ceramic package. The package
incorporates an infrared rejection filter. These
diodes have very high shunt resistance and
have good blue response.
PACKAGE DIMENSIONS
inch (mm)
CASE 20F 6 mm CERAMIC
CHIP ACTIVE AREA: .0025 in
2
(1.60 mm
2
)
ABSOLUTE MAXIMUM RATINGS
Storage Temperature:
-20C to 75C
Operating Temperature:
-20C to 75C
ELECTRO-OPTICAL CHARACTERISTICS @ 25C
(See also VTB curves, pages 21-22)
SYMBOL
CHARACTERISTIC
TEST CONDITIONS
VTB9412B
VTB9413B
UNITS
Min.
Typ.
Max.
Min.
Typ.
Max.
I
SC
Short Circuit Current
H = 100 fc, 2850 K
.8
1.3
.8
1.3
A
TC I
SC
I
SC
Temperature Coefficient
2850 K
.02
.08
.02
.08
%/C
V
OC
Open Circuit Voltage
H = 100 fc, 2850 K
420
420
mV
TC V
OC
V
OC
Temperature Coefficient
2850 K
-2.0
-2.0
mV/C
I
D
Dark Current
H = 0, VR = 2.0 V
100
20
pA
R
SH
Shunt Resistance
H = 0, V = 10 mV
.25
7.0
G
TC R
SH
R
SH
Temperature Coefficient
H = 0, V = 10 mV
-8.0
-8.0
%/C
C
J
Junction Capacitance
H = 0, V = 0
.31
.31
nF
range
Spectral Application Range
330
720
330
720
nm
p
Spectral Response - Peak
580
580
nm
V
BR
Breakdown Voltage
2
40
2
40
V
1/2
Angular Resp. - 50% Resp. Pt.
50
50
Degrees
NEP
Noise Equivalent Power
5.3 x 10
-14
(Typ.)
1.1 x 10
-14
(Typ.)
D*
Specific Detectivity
2.4 x 10
12
(Typ.)
1.2 x 10
13
(Typ.)
/ W
W
Hz
/
cm Hz
PerkinElmer Optoelectronics, 10900 Page Ave., St. Louis, MO 63132 USA Phone: 314-423-4900 Fax: 314-423-3956 Web: www.perkinelmer.com/opto
