DATA SHEET
Product specification
File under Integrated Circuits, IC06
September 1993
INTEGRATED CIRCUITS
74HC/HCT04
Hex inverter
For a complete data sheet, please also download:
The IC06 74HC/HCT/HCU/HCMOS Logic Family Specifications
The IC06 74HC/HCT/HCU/HCMOS Logic Package Information
The IC06 74HC/HCT/HCU/HCMOS Logic Package Outlines
September 1993
2
Philips Semiconductors
Product specification
Hex inverter
74HC/HCT04
FEATURES
Output capability: standard
I
CC
category: SSI
GENERAL DESCRIPTION
The 74HC/HCT04 are high-speed Si-gate CMOS devices and are pin compatible with low power Schottky TTL (LSTTL).
They are specified in compliance with JEDEC standard no. 7A. The 74HC/HCT04 provide six inverting buffers.
QUICK REFERENCE DATA
GND = 0 V; T
amb
= 25
C; t
r
= t
f
= 6 ns
Notes
1. C
PD
is used to determine the dynamic power dissipation (P
D
in
W):
P
D
= C
PD
V
CC
2
f
i
+
(C
L
V
CC
2
f
o
) where:
f
i
= input frequency in MHz
f
o
= output frequency in MHz
(C
L
V
CC
2
f
o
) = sum of outputs
C
L
= output load capacitance in pF
V
CC
= supply voltage in V
2. For HC the condition is V
I
= GND to V
CC
For HCT the condition is V
I
= GND to V
CC
-
1.5 V
ORDERING INFORMATION
See
"74HC/HCT/HCU/HCMOS Logic Package Information"
.
SYMBOL
PARAMETER
CONDITIONS
TYPICAL
UNIT
HC
HCT
t
PHL
/ t
PLH
propagation delay nA to nY
C
L
= 15 pF; V
CC
= 5 V
7
8
ns
C
I
input capacitance
3.5
3.5
pF
C
PD
power dissipation capacitance per gate notes 1 and 2
21
24
pF
September 1993
3
Philips Semiconductors
Product specification
Hex inverter
74HC/HCT04
PIN DESCRIPTION
PIN NO.
SYMBOL
NAME AND FUNCTION
1, 3, 5, 9, 11, 13
1A to 6A
data inputs
2, 4, 6, 8, 10, 12
1Y to 6Y
data outputs
7
GND
ground (0 V)
14
V
CC
positive supply voltage
Fig.1 Pin configuration.
Fig.2 Logic symbol.
Fig.3 IEC logic symbol.
Fig.4 Functional diagram.
Fig.5
Logic diagram
(one inverter).
FUNCTION TABLE
Notes
1. H = HIGH voltage level
L = LOW voltage level
INPUT
OUTPUT
nA
nY
L
H
H
L
September 1993
4
Philips Semiconductors
Product specification
Hex inverter
74HC/HCT04
DC CHARACTERISTICS FOR 74HC
For the DC characteristics see
"74HC/HCT/HCU/HCMOS Logic Family Specifications"
.
Output capability: standard
I
CC
category: SSI
AC CHARACTERISTICS FOR 74HC
GND = 0 V; t
r
= t
f
= 6 ns; C
L
= 50 pF
SYMBOL
PARAMETER
T
amb
(
C)
UNIT
TEST CONDITIONS
74HC
V
CC
(V)
WAVEFORMS
+25
-
40 to +85
-
40 to +125
min.
typ.
max.
min.
max.
min.
max.
t
PHL
/ t
PLH
propagation delay
nA to nY
25
9
7
85
17
14
105
21
18
130
26
22
ns
2.0
4.5
6.0
Fig.6
t
THL
/ t
TLH
output transition
time
19
7
6
75
15
13
95
19
16
110
22
19
ns
2.0
4.5
6.0
Fig.6
September 1993
5
Philips Semiconductors
Product specification
Hex inverter
74HC/HCT04
DC CHARACTERISTICS FOR 74HCT
For the DC characteristics see
"74HC/HCT/HCU/HCMOS Logic Family Specifications"
.
Output capability: standard
I
CC
category: SSI
Note to HCT types
The value of additional quiescent supply current (
I
CC
) for a unit load of 1 is given in the family specifications.
To determine
I
CC
per unit, multiply this value by the unit load coefficient shown in the table below.
AC CHARACTERISTICS FOR 74HC
GND = 0 V; t
r
= t
f
= 6 ns; C
L
= 50 pF
AC WAVEFORMS
PACKAGE OUTLINES
See
"74HC/HCT/HCU/HCMOS Logic Package Outlines"
.
INPUT
UNIT LOAD COEFFICIENT
nA
1.20
SYMBOL
PARAMETER
T
amb
(
C)
UNIT
TEST CONDITIONS
74HCT
V
CC
(V)
WAVEFORMS
+25
-
40 to +85
-
40 to +125
min.
typ.
max.
min.
max.
min.
max.
t
PHL
/ t
PLH
propagation delay
nA to nY
10
19
24
29
ns
4.5
Fig.6
t
THL
/ t
TLH
output transition
time
7
15
19
22
ns
4.5
Fig.6
Fig.6
Waveforms showing the data input (nA) to data output (nY) propagation delays and the output transition
times.
(1) HC : V
M
= 50%; V
I
= GND to V
CC
HCT: V
M
= 1.3 V; V
I
= GND to 3 V
