DATA SHEET
Product specification
File under Integrated Circuits, IC04
January 1995
INTEGRATED CIRCUITS
HEF4050B
buffers
HEX non-inverting buffers
For a complete data sheet, please also download:
The IC04 LOCMOS HE4000B Logic
Family Specifications HEF, HEC
The IC04 LOCMOS HE4000B Logic
Package Outlines/Information HEF, HEC
January 1995
2
Philips Semiconductors
Product specification
HEX non-inverting buffers
HEF4050B
buffers
DESCRIPTION
The HEF4050B provides six non-inverting buffers with
high current output capability suitable for driving TTL or
high capacitive loads. Since input voltages in excess of the
buffers' supply voltage are permitted, the buffers may also
be used to convert logic levels of up to 15 V to standard
TTL levels. Their guaranteed fan-out into common bipolar
logic elements is shown in the table below.
Fig.1 Functional diagram.
HEF4050BP(N): 16-lead DIL; plastic
(SOT38-1)
HEF4050BD(F): 16-lead DIL; ceramic (cerdip)
(SOT74)
HEF4050BT(D): 16-lead SO; plastic
(SOT109-1)
( ): Package Designator North America
Fig.2 Pinning diagram.
Guaranteed fan-out in common logic families
DRIVEN ELEMENT
GUARANTEED
FAN-OUT
standard TTL
2
74 LS
9
74 L
16
Fig.3 Logic diagram (one gate).
APPLICATION INFORMATION
Some examples of applications for the HEF4050B are:
LOCMOS to DTL/TTL converter
HIGH sink current for driving 2 TTL loads
HIGH-to-LOW level logic conversion
Input protection
FAMILY DATA, I
DD
LIMITS category BUFFERS
See Family Specifications
Fig.4
Input protection circuit that allows input
voltages in excess of V
DD
.
January 1995
3
Philips Semiconductors
Product specification
HEX non-inverting buffers
HEF4050B
buffers
DC CHARACTERISTICS
V
SS
= 0 V; V
I
= V
SS
or V
DD
HEF
V
DD
V
V
O
V
SYMBOL
T
amb
(
C)
-
40
+
25
+
85
MIN.
MAX.
MIN.
MAX.
MIN.
MAX.
Output (sink)
4,75
0,4
3,5
-
2,9
-
2,3
-
mA
current LOW
10
0,5
I
OL
12,0
-
10,0
-
8,0
-
mA
15
1,5
24,0
-
20,0
-
16,0
-
mA
Output (source)
5
4,6
0,52
-
0,44
-
0,36
-
mA
current HIGH
10
9,5
I
OH
1,3
-
1,1
-
0,9
-
mA
15
13,5
3,6
-
3,0
-
2,4
-
mA
Output (source)
current HIGH
5
2,5
I
OH
1,7
-
1,4
-
1,1
-
mA
HEC
V
DD
V
V
O
V
SYMBOL
T
amb
(
C)
-
55
+
25
+
125
MIN.
MAX.
MIN.
MAX.
MIN.
MAX.
Output (sink)
4,75
0,4
3,6
-
2,9
-
1,9
-
mA
current LOW
10
0,5
I
OL
12,5
-
10,0
-
6,7
-
mA
15
1,5
25,0
-
20,0
-
13,0
-
mA
Output (source)
5
4,6
0,52
-
0,44
-
0,36
-
mA
current HIGH
10
9,5
I
OH
1,3
-
1,1
-
0,9
-
mA
15
13,5
3,6
-
3,0
-
2,4
-
mA
January 1995
4
Philips Semiconductors
Product specification
HEX non-inverting buffers
HEF4050B
buffers
AC CHARACTERISTICS
V
SS
= 0 V; T
amb
= 25
C; C
L
= 50 pF; input transition times
20 ns
V
DD
V
SYMBOL
TYP.
MAX.
TYPICAL EXTRAPOLATION
FORMULA
Propagation delays
5
35
70
ns
26 ns
+
(0,18 ns/pF) C
L
I
n
O
n
10
t
PHL
20
35
ns
16 ns
+
(0,08 ns/pF) C
L
HIGH to LOW
15
15
30
ns
12 ns
+
(0,05 ns/pF) C
L
5
55
110
ns
28 ns
+
(0,55 ns/pF) C
L
LOW to HIGH
10
t
PLH
25
55
ns
14 ns
+
(0,23 ns/pF) C
L
15
20
40
ns
12 ns
+
(0,16 ns/pF) C
L
Output transition
5
25
50
ns
7 ns
+
(0,35 ns/pF) C
L
times
10
t
THL
10
20
ns
3 ns
+
(0,14 ns/pF) C
L
HIGH to LOW
15
7
14
ns
2 ns
+
(0,09 ns/pF) C
L
5
60
120
ns
10 ns
+
(1,0 ns/pF) C
L
LOW to HIGH
10
t
TLH
30
60
ns
9 ns
+
(0,42 ns/pF) C
L
15
20
40
ns
6 ns
+
(0,28 ns/pF) C
L
V
DD
V
TYPICAL FORMULA FOR P (
W)
Dynamic power
5
3 800 f
i
+
(f
o
C
L
)
V
DD
2
where
dissipation per
10
11 600 f
i
+
(f
o
C
L
)
V
DD
2
f
i
= input freq. (MHz)
package (P)
15
65 900 f
i
+
(f
o
C
L
)
V
DD
2
f
o
= output freq. (MHz)
C
L
= load capacitance (pF)
(f
o
C
L
) = sum of outputs
V
DD
= supply voltage (V)
