DATA SHEET
Product specification
File under Integrated Circuits, IC04
January 1995
INTEGRATED CIRCUITS
HEF4534B
LSI
Real time 5-decade counter
For a complete data sheet, please also download:
The IC04 LOCMOS HE4000B Logic
Family Specifications HEF, HEC
The IC04 LOCMOS HE4000B Logic
Package Outlines/Information HEF, HEC
January 1995
2
Philips Semiconductors
Product specification
Real time 5-decade counter
HEF4534B
LSI
DESCRIPTION
The HEF4534B is a 5-decade ripple counter. The binary
outputs of the decade counters are time-multiplexed by an
internal scanner on four BCD outputs (O
0
to O
3
). The
selected decade is indicated by a logic HIGH on the
appropriate digit select output (OS
0
: units, 1; OS
1
: tens,
10; OS
2
: hundreds, 10
2
; OS
3
: thousands, 10
3
; OS
4
: ten
thousands, 10
4
).
The binary outputs (O
0
to O
3
) and the select outputs
(OS
0
to OS
4
) are 3-state controlled via enable inputs
EO and EOS respectively, allowing interface with other
bus orientated devices. Cascading may be accomplished
by using the carry out (TC). The counter is triggered by a
LOW to HIGH transition on the decade clock (CPA) and is
reset by a HIGH level on the master reset (MR). The
scanner is triggered by a LOW to HIGH transition on the
scanner clock (CPS) and is reset (select ten thousand
counter) by a HIGH level on the scanner reset (MR
sc
).
The counter can operate in four modes depending on the
state of the mode select inputs (S
A
, S
B
). The error detector
will detect an error when a positive edge on CPA is not
accompanied by a negative edge on the error detector
clock CPE or vice versa, within time limits adjusted by
external capacitors connected to C
ext 1
and C
ext 2.
Three or
more detected errors result in a HIGH level on the error
output (OER). The error detector is reset by a HIGH level
on MR.
Schmitt-trigger action in the clock inputs makes the circuit
highly tolerant to slower clock rise and fall times.
Fig.1 Pinning diagram.
HEF4534BP(N):
24-lead DIL; plastic (SOT101-1)
HEF4534BD(F):
24-lead DIL; ceramic (cerdip) (SOT94)
HEF4534BT(D):
24-lead SO; plastic (SOT137-1)
( ): Package Designator North America
PINNING
FAMILY DATA, I
DD
LIMITS category LSI
See Family Specifications
O
1
to O
3
BCD outputs
OS
0
to OS
3
digit select outputs
OER
error output
CPA
decade clock input
CPS
scanner clock input
CPE
error detector clock input
S
A
, S
B
mode select inputs
MR
master reset input
MR
sc
scanner reset input
TC
carry out
January 1995
3
Philips Semiconductors
Product specification
Real time 5-decade counter
HEF4534B
LSI
Fig.2 Functional block diagram.
January 1995
4
Philips Semiconductors
Product specification
Real time 5-decade counter
HEF4534B
LSI
MODE CONTROL FUNCTION TABLE
SELECT INPUTS
1ST DECADE
OUTPUT
CARRY TO 2ND STAGE CARRY TO 4TH STAGE
MODE
S
A
S
B
L
L
normal count
at 9 to 0 transition
at 9 to 0 transition
5-decade
and display
of the 1st decade
of the 3rd decade
counter
L
H
inhibited
input clock
input clock
test purposes:
clock directly into
stages 1, 2 and 4
H
H
inhibited
at 4 to 5 transition
of the 1st decade
at 9 to 0 transition
of the 3rd decade
4-decade counter
with
10 and round-
off at front end
H
L
display counts:
at 7 to 8 transition
of the 1st decade
at 9 to 0 transition
of the 3rd decade
4-decade counter;
1
/
2
-pence capability
3, 4, 5, 6, 7 = 5
8, 9, 0, 1, 2 = 0
Fig.3 Error detection timing diagram.
The skew time is the time difference between the LOW to
HIGH transition of CPA and the HIGH to LOW transition of
CPE or vice versa (see Fig.4). The skew time is typically
proportional to the external capacitor (C
ext
) connected
from C
ext1
and C
ext2
(pins 1 and 22) to V
SS
. The error
detector will count an error when a positive edge on the
counter clock CPA is not succeeded by a negative edge on
the error detector clock CPE within a skew time
t
SK1
(adjustable by C
ext1
at pin 1). The same holds for a
negative edge at CPE succeeded by a positive on CPA
within a skew time t
SK2
(adjustable by C
ext2
at pin 22). If
error detection is not needed, CPE must be either HIGH or
LOW and no C
ext
is applied. For further information see
Fig.5.
Fig.4
Skew times
timing diagram;
t
WCPA
>
t
SK1
;
t
WCPE
>
t
SK2
.
January 1995
5
Philips Semiconductors
Product specification
Real time 5-decade counter
HEF4534B
LSI
Fig.5
Typical clock skew as a function of the supply voltage. This graph is accurate for C
ext
100 pF and
T
amb
= 25
C.
Note 1: Skew in this area results in counted error.
Note 2: Skew in the area between max. and min. curves may or may not result in counted error.
Note 3: Skew in this area results in no error counted.
Fig.6 Carry timing diagram.
January 1995
6
Philips Semiconductors
Product specification
Real time 5-decade counter
HEF4534B
LSI
Fig.7 Scanner timing diagram.
Note: If S
B
= H, the 1st decade is inhibited and the cycle will be shortened to four stages (see dotted lines).
Fig.8 Counter timing diagram.
January 1995
7
Philips Semiconductors
Product specification
Real time 5-decade counter
HEF4534B
LSI
AC CHARACTERISTICS
V
SS
= 0 V; T
amb
= 25
C; C
L
= 50 pF; input transition times
20 ns
V
DD
V
SYMBOL
MIN.
TYP.
MAX.
TYPICAL EXTRAPOLATION
FORMULA
Propagation delays
CPA
O
n
5
300
600
ns
283 ns
+
(0,55 ns/pF) C
L
D1 selected
10
t
PHL
130
260
ns
119 ns
+
(0,23 ns/pF) C
L
HIGH to LOW
15
95
190
ns
87 ns
+
(0,16 ns/pF) C
L
5
240
480
ns
213 ns
+
(0,55 ns/pF) C
L
LOW to HIGH
10
t
PLH
100
200
ns
89 ns
+
(0,23 ns/pF) C
L
15
75
150
ns
67 ns
+
(0,16 ns/pF) C
L
CPA
O
n
5
550
1100
ns
523 ns
+
(0,55 ns/pF) C
L
D5 selected
10
t
PHL
230
460
ns
219 ns
+
(0,23 ns/pF) C
L
HIGH to LOW
15
170
340
ns
162 ns
+
(0,16 ns/pF) C
L
5
550
1100
ns
523 ns
+
(0,55 ns/pF) C
L
LOW to HIGH
10
t
PLH
230
460
ns
219 ns
+
(0,23 ns/pF) C
L
15
170
340
ns
162 ns
+
(0,16 ns/pF) C
L
CPA
TC
5
420
840
ns
393 ns
+
(0,55 ns/pF) C
L
LOW to HIGH
10
t
PLH
190
380
ns
179 ns
+
(0,23 ns/pF) C
L
15
140
280
ns
132 ns
+
(0,16 ns/pF) C
L
MR
O
n
5
200
400
ns
173 ns
+
(0,55 ns/pF) C
L
HIGH to LOW
10
t
PHL
85
170
ns
74 ns
+
(0,23 ns/pF) C
L
15
60
120
ns
52 ns
+
(0,16 ns/pF) C
L
MR
OER
5
140
280
ns
113 ns
+
(0,55 ns/pF) C
L
HIGH to LOW
10
t
PHL
65
130
ns
54 ns
+
(0,23 ns/pF) C
L
15
50
100
ns
42 ns
+
(0,16 ns/pF) C
L
CPS
O
n
5
225
450
ns
198 ns
+
(0,55 ns/pF) C
L
HIGH to LOW
10
t
PHL
95
190
ns
84 ns
+
(0,23 ns/pF) C
L
15
70
140
ns
62 ns
+
(0,16 ns/pF) C
L
5
225
450
ns
198 ns
+
(0,55 ns/pF) C
L
LOW to HIGH
10
t
PLH
95
190
ns
84 ns
+
(0,23 ns/pF) C
L
15
70
140
ns
62 ns
+
(0,16 ns/pF) C
L
CPS
OS
n
5
170
340
ns
143 ns
+
(0,55 ns/pF) C
L
HIGH to LOW
10
t
PHL
70
140
ns
59 ns
+
(0,23 ns/pF) C
L
15
50
100
ns
42 ns
+
(0,16 ns/pF) C
L
CPS
OS
n
5
170
340
ns
143 ns
+
(0,55 ns/pF) C
L
LOW to HIGH
10
t
PLH
70
140
ns
59 ns
+
(0,23 ns/pF) C
L
15
50
100
ns
42 ns
+
(0,16 ns/pF) C
L
January 1995
8
Philips Semiconductors
Product specification
Real time 5-decade counter
HEF4534B
LSI
AC CHARACTERISTICS
V
SS
= 0 V; T
amb
= 25
C; C
L
= 50 pF; input transition times
20 ns
Output transition times
5
60
120
ns
10 ns
+
(1,0 ns/pF) C
L
HIGH to LOW
10
t
THL
30
60
ns
9 ns
+
(0,42 ns/pF) C
L
15
20
40
ns
6 ns
+
(0,28 ns/pF) C
L
5
60
120
ns
10 ns
+
(1,0 ns/pF) C
L
LOW to HIGH
10
t
TLH
30
60
ns
9 ns
+
(0,42 ns/pF) C
L
15
20
40
ns
6 ns
+
(0,28 ns/pF) C
L
V
DD
V
SYMBOL
MIN.
TYP.
MAX.
3-state propagation delays
Output disable times
EO
O
n
;
5
30
60
ns
EOS
OS
n
10
t
PHZ
25
50
ns
HIGH
15
20
40
ns
5
40
80
ns
LOW
10
t
PLZ
25
50
ns
15
20
40
ns
Output enable times
EO
O
n
;
5
35
70
ns
EOS
OS
n
10
t
PZH
20
40
ns
HIGH
15
15
30
ns
5
50
100
ns
LOW
10
t
PZL
25
50
ns
15
15
30
ns
Minimum clock pulse
5
70
35
ns
width; CPA, CPS
10
t
WCPH
40
20
ns
HIGH
15
30
15
ns
Minimum reset pulse
5
90
45
ns
width; MR, MR
sc
10
t
WMRH
60
30
ns
HIGH
15
40
20
ns
Recovery time
5
120
60
ns
for MR
10
t
RMR
60
30
ns
15
50
25
ns
Recovery time
5
60
30
ns
for MR
sc
10
t
RMR
40
20
ns
15
30
15
ns
V
DD
V
SYMBOL
MIN.
TYP.
MAX.
TYPICAL EXTRAPOLATION
FORMULA
January 1995
9
Philips Semiconductors
Product specification
Real time 5-decade counter
HEF4534B
LSI
Note
1. C
ext
= 0.
Maximum clock
5
2,5
5
MHz
pulse frequency
10
f
max
6
12
MHz
CPA and CPS
15
8
16
MHz
V
DD
V
TYPICAL FORMULA FOR P (
W)
Dynamic power
5
1 100 f
i
+
(f
o
C
L
)
V
DD
2
where
dissipation per
10
4 800 f
i
+
(f
o
C
L
)
V
DD
2
f
i
= input freq. (MHz)
package (P)
(1)
15
12 000 f
i
+
(f
o
C
L
)
V
DD
2
f
o
= output freq. (MHz)
C
L
= load cap. (pF)
(f
o
C
L
) = sum of outputs
V
DD
= supply voltage (V)
V
DD
V
SYMBOL
MIN.
TYP.
MAX.
January 1995
10
Philips Semiconductors
Product specification
Real time 5-decade counter
HEF4534B
LSI
APPLICATION INFORMATION
Fig.9
Two HEF4534B ICs connected for cascade operation. TC is HIGH for a single clock period when all five
BCD decades go to zero. TC also goes HIGH when MR is applied.
Fig.10 Forcing a decade to the O
n
outputs. When the O
n
outputs of a given decade are required, this
configuration will lock-up the selected decade within four clock cycles. The select line feed back may be
hardwired or switched.
Document Outline
- DESCRIPTION
- PINNING
- FAMILY DATA, IDD LIMITS category LSI
- MODE CONTROL FUNCTION TABLE
- AC CHARACTERISTICS
- APPLICATION INFORMATION
PDF
ZIP
