Philips Semiconductors FAST Products
Product specification
74F350
4-bit shifter
1
March 20, 1989
8530368 96093
FEATURES
Shifts 4 bits of data to 0, 1, 2, 3 places under control of two
select lines
3-State outputs for bus organized systems
DESCRIPTION
The 74F350 is a combination logic circuit that shifts a 4-bit word
from 0 to 3 places. No clocking is required as with shift registers.
The 74F350 can be used to shift any number of bits any number of
places up or down by suitable interconnection. Shifting can be:
1. Logical -- with logic zeros filled in at either end of the shifting
field.
2. Arithmetic -- where the sign bit is extended during a shift down.
3. End around -- where the data word forms a continuous loop.
The 3-State outputs are useful for bus interface applications or
expansion to a larger number of shift positions in end around
shifting. The active Low Output Enable (OE) controls the state of the
outputs. The outputs are in the high impedance "off" state when OE
is High, and they are active when OE is Low.
PIN CONFIGURATION
16
15
14
13
12
11
10
7
6
5
4
3
2
1
I3
V
CC
Y2
Y3
S0
OE
Y0
Y1
I3
I2
I2
I1
I0
I1
9
8
GND
S1
SF00205
ORDERING INFORMATION
DESCRIPTION
COMMERCIAL RANGE
V
CC
= 5V
10%, T
amb
= 0
C to +70
C
16-pin plastic DIP
N74F350N
16-pin plastic SO
N74F350D
TYPE
TYPICAL PROPAGATION DELAY
TYPICAL SUPPLY CURRENT (TOTAL)
74F350
5.2ns
24mA
INPUT AND OUTPUT LOADING AND FAN-OUT TABLE
PINS
DESCRIPTION
74F (U.L.) HIGH/LOW
LOAD VALUE HIGH/LOW
In, In
Data inputs
1.0/2.0
20
A/1.2mA
S0, S1
Select inputs (active Low)
1.0/2.0
20
A/1.2mA
OE
Output Enable input (active Low)
1.0/2.0
20
A/1.2mA
Y0 Y3
Data outputs
150/40
3.0mA/24mA
NOTE: One (1.0) FAST unit load is defined as: 20
A in the High state and 0.6mA in the Low state.
LOGIC SYMBOL
V
CC
= Pin 16
GND = Pin 8
SF00206
9
10
13
S1
S0
OE
1
2
3
4
5
6
7
I3
I2
I1
I0
I1
I2
I3
Y0
Y1
Y2
Y3
15
14
12
11
IEC/IEEE SYMBOL
SF00207
0
9
10
D MUX
13
G
0
3
[SHIFTER]
1
EN
1
15
10
3
11
2
12
1
13
0
1
14
11
3
12
2
13
1
14
0
1
12
12
3
13
2
14
1
15
0
1
11
13
3
14
2
15
1
16
0
Z10
1
Z11
2
Z12
3
Z13
4
Z14
5
Z15
6
Z16
7
Philips Semiconductors FAST Products
Product specification
74F350
4-bit shifter
March 20, 1989
2
LOGIC DIAGRAM
13
9
10
V
CC
= Pin 16
GND = Pin 8
OE
S1
S0
SF00208
1
I3
Y0
15
2
I2
Y1
14
3
I1
Y2
12
4
I0
Y3
11
5
I1
6
I2
7
I3
FUNCTION TABLE
INPUTS
OUTPUTS
OE
S1
S0
I3
I2
I1
I0
I1
I2
I3
Y3
Y2
Y1
Y0
H
X
X
X
X
X
X
X
X
X
Z
Z
Z
Z
L
L
L
D3
D2
D1
D0
X
X
X
D3
D2
D1
D0
L
L
H
X
D2
D1
D0
D1
X
X
D2
D1
D0
D1
L
H
L
X
X
D1
D0
D1
D2
X
D1
D0
D1
D2
L
H
H
X
X
X
D0
D1
D2
D3
D0
D1
D2
D3
H = High voltage level
L
= Low voltage level
X = Don't care
Z = High impedance "off" state
Dn = High or Low state of referenced In input
Philips Semiconductors FAST Products
Product specification
74F350
4-bit shifter
March 20, 1989
3
APPLICATION FOR 16-BIT SHIFT UP 0, 1, 2, OR 3 PLACES
GND
S0
S1
OE
S0
S1
OE
I-3 I-2 I-1 I0 I1 I2 I3
Y0 Y1 Y2 Y3
S0
S1
OE
I-3 I-2 I-1 I0 I1 I2 I3
Y0 Y1 Y2 Y3
S0
S1
OE
I-3 I-2 I-1 I0 I1 I2 I3
Y0 Y1 Y2 Y3
S0
S1
OE
I-3 I-2 I-1 I0 I1 I2 I3
Y0 Y1 Y2 Y3
0
1
2
3
4
5
6
7
8
9 10 11
12 13 14 15
0
1
2
3
4
5
6
7
8
9 10 11
12 13 14 15
S0
S1
MODE
L
L
No shift
H
L
Shift 1 place
L
H
Shift 2 places
H
H
Shift 3 places
SF00209
APPLICATION FOR 8-BIT END AROUND SHIFT 0, 1, 2, 3, 4, 5, 6, OR 7 PLACES
S0
S1
S2
S0
S1
OE
I-3 I-2 I-1 I0 I1 I2 I3
Y0 Y1 Y2 Y3
S0
S1
OE
I-3 I-2 I-1 I0 I1 I2 I3
Y0 Y1 Y2 Y3
S0
S1
OE
I-3 I-2 I-1 I0 I1 I2 I3
Y0 Y1 Y2 Y3
S0
S1
OE
I-3 I-2 I-1 I0 I1 I2 I3
Y0 Y1 Y2 Y3
0
1
2
3
4
5
6
7
S2
S1
S0
MODE
L
L
L
No shift
L
L
H
Shift end around 1
L
H
L
Shift end around 2
L
H
H
Shift end around 3
H
L
L
Shift end around 4
H
L
H
Shift end around 5
H
H
L
Shift end around 6
H
H
H
Shift end around 7
SF00210
S3
0
1
2
3
4
5
6
7
Philips Semiconductors FAST Products
Product specification
74F350
4-bit shifter
March 20, 1989
4
APPLICATION FOR 13-BIT TWO'S COMPLEMENT SCALER
S0
S1
S0
S1
OE
I-3 I-2 I-1 I0 I1 I2 I3
Y0 Y1 Y2 Y3
S0
S1
OE
I-3 I-2 I-1 I0 I1 I2 I3
Y0 Y1 Y2 Y3
S0
S1
OE
I-3 I-2 I-1 I0 I1 I2 I3
Y0 Y1 Y2 Y3
9
5
1
12 11 10 9
8
7
6
5
4
3
2
1
S1
S0
SCALE
L
L
8
1/8
L
H
4
1/4
H
L
2
1/2
H
H
No change
1
SF00211
12 11 10
0
2
3
4
8
7
6
0
ABSOLUTE MAXIMUM RATINGS
(Operation beyond the limits set forth in this table may impair the useful life of the device.
Unless otherwise noted these limits are over the operating free-air temperature range.)
SYMBOL
PARAMETER
RATING
UNIT
V
CC
Supply voltage
0.5 to +7.0
V
V
IN
Input voltage
0.5 to +7.0
V
I
IN
Input current
30 to +5
mA
V
OUT
Voltage applied to output in High output state
0.5 to V
CC
V
I
OUT
Current applied to output in Low output state
48
mA
T
amb
Operating free-air temperature range
0 to +70
C
T
stg
Storage temperature range
65 to +150
C
RECOMMENDED OPERATING CONDITIONS
SYMBOL
PARAMETER
LIMITS
UNIT
SYMBOL
PARAMETER
MIN
NOM
MAX
UNIT
V
CC
Supply voltage
4.5
5.0
5.5
V
V
IH
High-level input voltage
2.0
V
V
IL
Low-level input voltage
0.8
V
I
IK
Input clamp current
18
mA
I
OH
High-level output current
3
mA
I
OL
Low-level output current
24
mA
T
amb
Operating free-air temperature range
0
+70
C
Philips Semiconductors FAST Products
Product specification
74F350
4-bit shifter
March 20, 1989
5
DC ELECTRICAL CHARACTERISTICS
(Over recommended operating free-air temperature range unless otherwise noted.)
SYMBOL
PARAMETER
TEST CONDITIONS
1
LIMITS
UNIT
SYMBOL
PARAMETER
TEST CONDITIONS
1
MIN
TYP
2
MAX
UNIT
V
OH
High-level output voltage
V
CC
= MIN, V
IL
= MAX
10%V
CC
2.4
V
V
OH
High-level output voltage
V
IH
= MIN, I
OH
= MAX
5%V
CC
2.7
3.4
V
V
OL
Low-level output voltage
V
CC
= MIN, V
IL
= MAX
10%V
CC
0.35
0.50
V
V
OL
Low-level output voltage
V
IH
= MIN, I
OL
= MAX
5%V
CC
0.35
0.50
V
V
IK
Input clamp voltage
V
CC
= MIN, I
I
= I
IK
0.73
1.2
V
I
I
Input current at maximum input voltage
V
CC
= MAX, V
I
= 7.0V
100
A
I
IH
High-level input current
V
CC
= MAX, V
I
= 2.7V
20
A
I
IL
Low-level input current
V
CC
= MAX, V
I
= 0.5V
1.2
mA
I
OZH
Off-state output current,
High-level voltage applied
V
CC
= MAX, V
O
= 2.7V
50
A
I
OZL
Off-state output current,
Low-level voltage applied
V
CC
= MAX, V
O
= 0.5V
50
A
I
OS
Short-circuit output current
3
V
CC
= MAX
60
150
mA
I
CC
Supply current (total)
I
CCH
V
CC
= MAX
22
35
mA
I
CC
Supply current (total)
I
CCL
V
CC
= MAX
26
41
mA
I
CCZ
26
42
mA
NOTES:
1. For conditions shown as MIN or MAX, use the appropriate value specified under recommended operating conditions for the applicable type.
2. All typical values are at V
CC
= 5V, T
amb
= 25
C.
3. Not more than one output should be shorted at a time. For testing I
OS
, the use of high-speed test apparatus and/or sample-and-hold
techniques are preferable in order to minimize internal heating and more accurately reflect operational values. Otherwise, prolonged shorting
of a High output may raise the chip temperature well above normal and thereby cause invalid readings in other parameter tests. In any
sequence of parameter tests, I
OS
tests should be performed last.
AC ELECTRICAL CHARACTERISTICS
SYMBOL
PARAMETER
TEST
CONDITION
LIMITS
UNIT
SYMBOL
PARAMETER
TEST
CONDITION
V
CC
= +5.0V
T
amb
= +25
C
C
L
= 50pF, R
L
= 500
V
CC
= +5.0V
10%
T
amb
= 0
C to +70
C
C
L
= 50pF, R
L
= 500
UNIT
MIN
TYP
MAX
MIN
MAX
t
PLH
t
PHL
Propagation delay
In to Yn
Waveform 1
3.0
2.5
4.5
4.0
6.0
5.5
3.0
2.5
7.0
6.5
ns
t
PLH
t
PHL
Propagation delay
Sn to Yn
Waveform 1
4.0
3.0
7.8
6.5
10.0
8.5
4.0
3.0
11.0
9.5
ns
t
PZH
t
PZL
Output Enable time to
High or Low level
Waveform 2
Waveform 3
2.5
4.0
5.0
7.0
7.0
9.0
2.5
4.0
8.0
10.0
ns
t
PHZ
t
PLZ
Output Disable time to
High or Low level
Waveform 2
Waveform 3
2.0
2.0
3.9
4.0
5.5
5.5
2.0
2.0
6.5
6.5
ns
Philips Semiconductors FAST Products
Product specification
74F350
4-bit shifter
March 20, 1989
6
AC WAVEFORMS
For all waveforms, V
M
= 1.5V.
VM
VM
VM
VM
Yn
In, In, Sn
tPLH
tPHL
SF00212
Waveform 1.
Propagation Delay Data and Select to Output
VOH0.3V
VM
VM
VM
Yn
tPZH
tPHZ
SF00213
OE
0V
Waveform 2.
3-State Output Enable Time to High Level
and Output Disable Time from High Level
VOL+0.3V
VM
VM
VM
Yn
tPZL
tPLZ
SF00214
OE
Waveform 3.
3-State Output Enable Time to Low Level
and Output Disable Time from Low Level
TEST CIRCUIT AND WAVEFORMS
tw
90%
VM
10%
90%
VM
10%
90%
VM
10%
90%
VM
10%
NEGATIVE
PULSE
POSITIVE
PULSE
tw
AMP (V)
0V
0V
tTHL (tf
)
INPUT PULSE REQUIREMENTS
rep. rate
t
w
t
TLH
t
THL
1MHz
500ns
2.5ns
2.5ns
Input Pulse Definition
VCC
family
74F
D.U.T.
PULSE
GENERATOR
RL
CL
RT
VIN
VOUT
Test Circuit for Open Collector Outputs
DEFINITIONS:
R
L
= Load resistor;
see AC electrical characteristics for value.
C
L
= Load capacitance includes jig and probe capacitance;
see AC electrical characteristics for value.
R
T
= Termination resistance should be equal to Z
OUT
of
pulse generators.
tTHL (tf
)
tTLH (tr
)
tTLH (tr
)
AMP (V)
amplitude
3.0V
1.5V
V
M
RL
7.0V
SF00128
TEST
SWITCH
t
PLZ
closed
t
PZL
closed
All other
open
SWITCH POSITION
PDF
ZIP
