Pixim D1000 Video Imaging System
for CCTV Cameras
The Pixim D1000 is a highly integrated two chip set utilizing Pixim's innovative new
Digital Pixel System
TM
(DPS) technology that provides the image sensor and the
necessary intelligence to develop high quality, cost-effective color CCTV cameras. The
D1000 is designed to deliver superior quality video, providing up to 95 dB dynamic
range in normal operation while providing excellent resolution, sensitivity and color
fidelity. The D1000 includes configurable software which allows camera manufacturers
to get to market quickly and offer a number of camera products from the same base
hardware design, including an option to select PAL / NTSC operation via a jumper or
switch. Composite and S-Video outputs are available.
The chip set is manufactured in a high volume commercial 0.18 micron CMOS process,
utilizing 1.8V operation for low power dissipation.
Highlights
High resolution color for crisp,
clear video
Horizontal resolution: >480 TV
Vertical resolution: >400 TV Lines
High sensitivity for low-light images
Wide dynamic range provides excellent
quality in high-contrast environments
95 dB (14-bit) typical
120 dB max.
Single design supports NTSC and
PAL
Analog: Composite, S-Video
Automatic Exposure Mode for best
pictures
Numerous Control Options
Automatic White Balance
Backlight compensation
AC line lock, internal or external sync
Automatic Gain Control
On-screen display
Electronic Iris
Auto-Iris control (DC, video)
PRODUCT BRIEF
D1010
Digital Image Sensor
D1020
Digital Image Processor
CVBS
Y/C
Auto-iris
Lens
Serial
EEPROM
GPIO
SPI
PixBus
27MHz
XTAL
AC Line Input
Power Supply
Ref Clk
3.3V
1.8V
D1010
Digital Image Sensor
D1020
Digital Image
Processor
Iris Control, DC or Video
Power
Standard 1.8V (core) and 3.3V (I/O) supply
Typical power: 1.5 W for D1000 chip set
Max. power: <2 W for D1000 chip set
Package
D1010: 17mm x 17mm; 181 PBGA, 1mm ball pitch
D1020: 15mm x 15mm; 144 PBGA, 1mm ball pitch
Temperature Range
Operation: -10 to 60 degrees C ambient
System Tools
Camera Development Kit (CDK)
Specifications
D1010 Digital Image Sensor
Pixel type: DPSTM technology
Silicon process: 0.18
m
CMOS
Image size: diagonal 6.3 mm (Type 1/3")
Sensor array size: 5.04mm (H) x 3.78 mm (V)
Pixel size: 7
m
x 7
m
Picture elements: total: 742 (H) x 554 (V); effective: 720 (H) x 540 (V)
Color filter array: complementary (CMY)
Dynamic range: 95 dB typical, 120 dB max
Resolution: >480 horizontal TV lines
Minimal blooming
Zero smear
D1020 Digital Image Processor
Silicon process: 0.18
m
CMOS
ARMTM processor core
Custom image pipeline
Built-in NTSC/PAL video encoder
Extensive programmability
DIP switch / push-button menu support
Camera ID
White balance: auto tracking, manual, and presets
Gamma correction options
Electronic shutter
Wide dynamic range
Automatic gain control mode
Backlight compensation control
B/W mode
Image flip: horizontal
Iris selection: DC type, video type, fixed Iris type
Exposure control: electronic Iris; DC/Video auto iris lens support
Auto iris output: Video or DC drive using internal PWM DAC
System Interfaces
Boot EPROM: serial SPI
Iris Control: control Video Iris lenses or DC Iris output
CVBS: Composite video signal (75 output)
Y/C: standard S-video output (75 output)
GPIO: 8 general input/output pins for camera modes via DIP switches
or push buttons
About DPS
Pixim's patented Digital Pixel System
TM
(DPS)
technology marks a fundamental breakthrough in
imaging technology. Building upon technology
developed at Stanford University in the 1990s,
Pixim has created an image capture and
processing system that provides high-quality
pictures with enhanced dynamic range. Greater
dynamic range significantly improves image
quality in scenes consisting of both bright and
dark areas.
The core invention in DPS is the inclusion of an
analog-to-digital converter (ADC) within each pixel
of the image sensor. The ADC translates the light
signal into a digital value at the immediate point of
capture, thus minimizing signal degradation and
cross-talk in the array and allowing for greater
noise reduction methods. Once the data is
captured in a digital format, a variety of digital
signal processing techniques are used for optimal
image reproduction.
As imaging technology continues to migrate
toward totally digital systems, Pixim's Digital Pixel
System technology will provide the foundation for
image capture and image processing for the
highest quality video and still cameras.
Pixim, Inc.
915 Linda Vista Ave.
Mountain View, CA 94043
USA
650-934-0550
PB-D1000-2003-10
www.pixim.com
