Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925 7272
Rectifier Diode
1800 Amperes/Up to 3200 Volts
Ordering Information
Select the complete 10 digit device part number from the table below.
Description:
Powerex General Purpose Rectifiers are
designed with high blocking voltage capability
with low forward on-state voltage to minimize
conduction losses. These are all-diffused,
hermetic Pow-R-Disc devices which can be
mounted using commercially available clamps
and heatsinks..
Features:
n
Low On-State Voltage
n
Low Thermal Impedance
n
Hermetic Packaging
n
Excellent Surge and I
2
t Ratings
Applications:
n
Power Supplies
n
Motor Control
n
Free Wheeling Diode
R9G0
1800A
Type
Voltage
V
RRM
Current
I
T(av)
Recovery
Time
t
rr
R9G0
12
through
32
16
XX
1200 V
through
3200 V
1600 A
25
s
typical
11-09-1999
Powerex, Inc., Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925 7272
R9G0
Rectifier Diode
1800 Amperes / Up to 3200 Volts
Absolute Maximum Ratings
Conditions
Symbol
Units
Repetitive Peak Reverse Blocking Voltage
V
RRM
up to 3200
V
Non-Repetitive Peak Reverse Blocking Voltage
V
RSM
V
RRM
+ 100
V
RMS Forward Current
I
F(RMS)
2825
A
Average Forward Current
180
Conduction, T
C
=110
C
I
F(AV)
1800
A
Peak Half Cycle Non-Repetitive Surge Current
t = 8.3mS, 100%V
RRM
reapplied
I
FSM
21,500
A
Peak Half Cycle Non-Repetitive Surge Current
t = 10mS, 100%V
RRM
reapplied
I
FSM
19,600
A
I
2
t for Fusing for One Cycle
I
2
t
1.925x10
6
A
2
-sec
I
2
t of Package
t = 8.3mS
I
2
t
90x10
6
A
2
-sec
Operating Junction Temperature
T
J
-40 to +175
C
Storage Temperature
T
stg
-40 to +190
C
Mounting Force
- -
- -
5000 to 6000
2270 to 2700
lb.
kg
Module Weight, Typical
- -
- -
454
1.0
g
lbs
R9G0
1800A
11-09-1999
Powerex, Inc., Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925 7272
R9G0
Rectifier Diode
1800 Amperes / Up to 3200 Volts
Electrical and Thermal Characteristics, T
J
=25
C unless otherwise specified
Characteristics
Symbol
Test Conditions
Min.
Typ.
Max
Units
Peak Reverse Leakage Current
I
RRM
T
J
=175
C, Rated V
RRM
150
mA
Peak On-State Voltage
V
FM
T
J
=25
C, I
FM
=1500A
1.20
V
Threshold Voltage, Low-level
Slope Resistance, Low-level
V
(TO)1
r
T1
T
J
= 175
C, I = 15%I
F(AV)
to
p
I
F(AV)
.814
.224
V
m
O
Threshold Voltage, High-level
Slope Resistance, High-level
V
(TO)2
r
T2
T
J
= 175
C, I =
p
I
F(AV)
to I
FSM
1.03
.198
V
m
O
V
FM
Coefficients, Full Range
T
J
= 175
C, I = 15%I
F(AV)
to I
FSM
V
FM
=A + B Ln (I
FM
)+ C I
FM
+ D v(I
FM
)
A = 2.06
B = -0.232
C = 0.000130
D = 0.0179
Maximum Reverse Recovery Current
I
R(Rec)
T
J
= 175
C, di/dt = -1 A/s
T
J
= 175
C, di/dt = -10A/s
70
250
A
A
Typical Reverse Recovery Time
t
rr
T
C
= 25
C, I
FM
= 1500 A
di
R
/dt = 25 A/
sec, t
p
= 190
sec
25
sec
Thermal Characteristics
Characteristics
Symbol
Min.
Typ.
Max.
Units
Thermal Resistance, Junction to Case
R
T
JC
------
------
0.02
C/W
Thermal Resistance, Case to Sink Lubricated
R
T
CS
------
------
0.0075
C/W
Maximum Transient Thermal Impedance
0
0.005
0.01
0.015
0.02
0.025
0.0001
0.001
0.01
0.1
1
10
100
Time - t - Seconds
Thermal Impedance - Zjc - C/W
(Junction to Case)
Maximum On-State Forw ard Voltage Drop
0
1
2
3
4
5
10
100
1000
10000
100000
Instantaneous On-State Current - Ifm - Amperes
On-State Voltage - Vfm - Volts
( Tj = 175 C )
R9G0
1800A
11-09-1999
Powerex, Inc., Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925 7272
Maximum On-State Power Dissipation
30
90
180
0
500
1000
1500
2000
2500
3000
3500
0
200
400
600
800
1000 1200 1400 1600 1800 2000
Average On-State Current - If(av) - Amperes
Maximum Power Dissipation - Watts
(Sinusoidal Waveform)
Maximum Allowable Case Temperature
180
90
30
100
110
120
130
140
150
160
170
180
0
200 400 600 800 1000 1200 1400 1600 1800 2000
Average On-State Current - If(av) - Amperes
Max. Case Temperature - Tcase - C
(Sinusoidal Waveform)
Maximum On-State Power Dissipation
120
60
180
360
0
500
1000
1500
2000
2500
3000
3500
4000
4500
0
400
800
1200
1600
2000
2400
2800
3200
Average On-State Current - If(av) - Amperes
Maximum Power Dissipation - Watts
(Rectangular Waveform)
Maximum Allowable Case Temperature
360
180
120
60
90
100
110
120
130
140
150
160
170
180
0
500
1000
1500
2000
2500
3000
Average On-State Current If(av) Amperes
Max. Case Temperature Tcase C
(Rectangular Waveform)
R9G0
1800A
11-09-1999
