USB004
1
05140.R4 8/03
www.protekdevices.com
STEERING DIODE ARRAY
Only One Name Means ProTek'TionTM
APPLICATIONS
USB Interface Ports
Cellular Phones
Video
Handheld Electronics
Personal Computers
IEC COMPATIBILITY (EN61000-4)
61000-4-2 (ESD): Air - 15kV, Contact - 8kV
61000-4-4 (EFT): 40A - 5/50ns
FEATURES
ESD Protection > 40 kilovolts
225 Milliwatt Continuous Power Dissipation
Provides Two (2) Lines of Protection
LOW LEAKAGE CURRENT < 1.0A
ULTRA LOW CAPACITANCE: 3pF Typical
MECHANICAL CHARACTERISTICS
Molded JEDEC SO-143
Weight 35 milligrams (Approximate)
Flammability rating UL 94V-0
8mm Tape and Reel Per EIA Standard 481
Marking: Marking Code
05140
PIN CONFIGURATION
SOT-143
3
4
1
2
V
N
I/O 1
V
P
I/O 2
2
www.protekdevices.com
05140.R4 8/03
USB004
DEVICE CHARACTERISTICS
MAXIMUM RATINGS @ 25C Unless Otherwise Specified
Operating Temperature
SYMBOL
VALUE
-55
C to 150
C
C
C
-55
C to 150
C
UNITS
T
J
T
STG
PARAMETER
Storage Temperature
Continuous Power Dissipation
P
PC
225
mW
Repetitive Peak Forward Current @ t
p
=5s, F=50kHz (Pin 2 - 3)
I
FRM
700
mA
Note 1:
V
P
- V
N
= 20V.
Note 2:
V
P
- V
N
= 5.5V.
Note 3:
V
P
= 5V, f = 1MHz, V
I/O
= 2.5V, V
N
= 0V
ELECTRICAL CHARACTERISTICS PER LINE @ 25C Unless Otherwise Specified
PART
NUMBER
DEVICE
MARKING
CODE
REPETITIVE
PEAK
REVERSE
VOLTAGE
(See Note 1)
@ 10A
V
RRM
VOLTS
MAXIMUM
REVERSE
LEAKAGE
CURRENT
(See Note 2)
V
RRM
@ 5V
I
R
A
MAXIMUM
DIODE
FORWARD
VOLTAGE
@ 20mA
V
F
VOLTS
MAXIMUM
CAPACITANCE
(See Note 3 )
(Between Line and Ground)
C
j
pF
USB004
PSA
20
1
0.95
6
0 1 2 3 4 5 6 7 8 9
10
800 840 880 920 960
1000
V
F
- Forward Voltage - V
FIGURE 1
PEAK FORWARD CURRENT VS FORWARD VOLTAGE
10
8
6
4
2
0
I
F
- Forward Current - A
V
F
- Forward Voltage - mV
I
F
- Forward Current - mA
FIGURE 2
LOW FORWARD CURRENT VS FORWARD VOLTAGE
110
90
70
50
30
10
3
www.protekdevices.com
05140.R4 8/03
USB004
COPYRIGHT ProTek Devices 2003
SPECIFICATIONS: ProTek reserves the right to change the electrical and or mechanical
characteristics described herein without notice (except JEDEC).
DESIGN CHANGES: ProTek reserves the right to discontinue product lines without notice, and that
the final judgement concerning selection and specifications is the buyer's and that in furnishing
engineering and technical assistance, ProTek assumes no responsibility with respect to the
selection or specifications of such products.
PACKAGE OUTLINE & DIMENSIONS
ProTek Devices
2929 South Fair Lane, Tempe, AZ 85282
Tel: 602-431-8101 Fax: 602-431-2288
E-Mail:
sales@protekdevices.com
Web Site:
www.protekdevices.com
TAPE & REEL ORDERING NOMENCLATURE
1. Surface mount product is taped and reeled in accordance
with EIA-481.
2. Suffix-T7 = 7 Inch Reel - 3,000 pieces per 8mm tape,
i.e.,
USB004-T7.
3. Suffix-T13 = 13 Inch Reel - 10,000 pieces per 8mm tape,
i.e.,
USB004-T13.
Outline & Dimensions: Rev 1 - 11/01, 06011
A
B
C
D
F
G
H
J
K
L
R
S
2.80
1.20
0.84
0.39
0.79
1.78
0.013
0.08
0.46
0.445
0.72
2.11
3.04
1.39
1.14
0.50
0.93
2.03
0.10
0.15
0.60
0.60
0.83
2.48
0.110
0.047
0.033
0.015
0.031
0.070
0.0005
0.003
0.018
0.0175
0.028
0.083
0.0120
0.055
0.045
0.020
0.037
0.080
0.004
0.006
0.024
0.024
0.033
0.098
DIM
MIN
MAX
MIN
MAX
MILLIMETERS
INCHES
PACKAGE DIMENSIONS
NOTES
1. Dimensioning and tolerances per ANSI Y14.5M, 1985.
2. Controlling Dimension: Inches
3. Dimensions are exclusive of mold flash and metal burrs.
PACKAGE OUTLINE
SOT-143
MOUNTING PAD
A
G
B
L
F
R
H
D
K
C
S
J
0.112
0.079
0.071
0.075
0.041
0.108
0.047
0.031
0.033
0.033
0.033
1
2
3
4
5
6
7
8
9
10
11
2.85
2.00
1.80
1.90
1.05
2.75
1.20
0.80
0.85
0.85
0.85
DIM Millimeters
Inches
TYPICAL
1
2
4
3
5
6
7
9
8
10
11
