2SC5907
Rev.0, Oct. 2002, page 2 of 19
Absolute Maximum Ratings
(Ta = 25
C)
Item Symbol
Ratings
Unit
Collector to base voltage
V
CBO
15
V
Collector to emitter voltage
V
CEO
4.0
V
Emitter to base voltage
V
EBO
1.5
V
Collector current
I
C
80
mA
Collector power dissipation
P
C
80
mW
Junction temperature
Tj
150
C
Storage temperature
Tstg
55 to 150
C
Electrical Characteristics
(Ta = 25
C)
Item
Symbol
Min Typ Max Unit Test
conditions
Collector to base breakdown
voltage
V
(BR)CBO
15
V
I
C
= 10
A, I
E
= 0
Collector cutoff current
I
CBO
0.1 A V
CB
= 15 V, I
E
= 0
Collector cutoff current
I
CEO
1.0 A V
CE
= 3.5 V, R
BE
= Infinite
Emitter cutoff current
I
EBO
0.5 A V
EB
= 0.8 V, I
C
= 0
DC current transfer ratio
h
FE
120
140
170
V
CE
= 1 V, I
C
= 5 mA
Reverse transfer capacitance C
re
0.45
pF V
CB
= 1 V, Emitter ground,
f = 1 MHz
Collector output capacitance
C
ob
0.85
1.0 PF V
CB
= 1 V, I
E
= 0, f = 1 MHz
Gain bandwidth product
f
T
(1) 5.0 7.5
GHz
V
CE
= 1 V, I
C
= 5 mA
f = 1 GHz
Gain bandwidth product
f
T
(2)
15.0
GHz
V
CE
= 1 V, I
C
= 40 mA
f = 1 GHz
Power gain
PG
11.0
14.0
dB
V
CE
= 1 V, I
C
= 5 mA,
f = 900 MHz
Noise figure
NF
1.2 1.8
dB
V
CE
= 1 V, I
C
= 5 mA,
f = 900 MHz
2SC5907
Rev.0, Oct. 2002, page 3 of 19
100
80
60
40
20
0
50
100
150
200
250
Collector Power Dissipation P
C
(mW)
Ambient Temperature Ta (
C)
Collector Power Dissipation Curve
50
40
30
20
10
1
2
3
4
Collector to Emitter Voltage V
CE
(V)
Collector Current I
C
(mA)
Typical Output Characteristics
50
40
30
20
10
0
0.2
0.4
0.6
0.8
1.0
Base to Emitter Voltage V
BE
(V)
Collector Current I
C
(mA)
Typical Transfer Characteristics
200
100
0
0.1
1.0
10
100
Collector Current I
C
(mA)
DC Current Transfer Ratio h
FE
DC Current Transfer Ratio vs.
Collector Current
I
B
= 10
A
110
A
210 A
310 A
V
CE
= 1 V
VCE = 1 V
