Printheads
Near edge thin film thermal
printhead (8 dots / mm)
NE2004-VA10A
The NE2004VA10A is a near edge thinfilm thermal printhead, where the printing medium passes straight through at
printing speeds up to 10 inch / second. It is suited for highspeed label printers.
F
Applications
Bar code printers
Card printers
Ticket printers
General purpose compact printers
F
Features
1) Inclined toward the printing surface to provide excellent printing quality even
for cards and thick paper.
2) Prints directly on printing medium that cannot be bent.
3) Using a hard conductive film as a protective film on the heating element of-
fers excellent resistance to electrostatic damage.
4) Being lowprofile when installed enables smaller printers.
5) Compatible with the NE3004-VA10A ( 300 dpi ) in mechanical specifications,
to facilitate the making of a series of printers.
F
External dimensions (Units: mm)
