Printheads
High speed thermal printhead
(8 dots / mm)
NF2002-VA10A
The NF2002-VA10A is a flat thin-film thermal printhead capable of printing speeds up to 12 inch / second, and suited
for general purpose compact printers as well as label printers.
F
Applications
Bar code label printers
Ticket printers
General purpose compact printers
F
Features
1) Special glazed components for high speed, high quality printing.
2) High speed clock to facilitate external heat history control.
3) Using a hard conductive film as a protective film on the heating element of-
fers excellent resistance to electrostatic damage.
4) Compatible with the NF3002-VA10A (300 dpi) in mechanical specifications,
to facilitate the making of a series of printers.
F
External dimensions (Units: mm)
