NF3004-RE10A
Printheads
Under
development
1/4
For Color Photo Printers
(300DPI ; dots / inch)
NF3004-RE10A
The NF3004-RE10 Series are suitable for small photo printers which can make direct print out from digital still cameras
and mobile phones. ROHM's technology based on "Step-free" structure enables battery drive, and high resolution printing
quality.
Applications
Home printers
Mobile Photo printers
Photo kiosk terminals
"Print club" (color photo printer) terminals
Features
1) NF3004-VC20 is drivable with batteries, thanks to it's low energy consumption.
2) NF3004-VC20 enables full color printing by keeping the adjacent resistance variation less than
1.5%.
3) Employing of the driver IC capable of high-speed data transfer at 3.3 circuit supply voltage makes the gradation
printing control easier.
4) High dot reproducibility with step-free structure.
External dimensions (Unit : mm)
Dot #1
114.2
0.2
108.16
(3.02)
10
(5.835)
Max.14
Dot #1280
CL
Note: No heat control function inside the thermal printhead. External heat history control is required for high speed
printing.
