NPN Epitaxial Planar Silicon Transistor
High-Frequency
Low-Noise Amplifier Applications
Ordering number:ENN5910
2SC5414
SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
30300TS (KOTO) TA-1023 No.59101/6
Specifications
Absolute Maximum Ratings
at Ta = 25C
Package Dimensions
unit:mm
2004B
[2SC5414]
Features
High gain :
S21e
2
=9.5dB typ (f=1GHz).
High cutoff frequency : f
T
=6.7GHz typ.
C
C
Electrical Characteristics
at Ta = 25C
1 : Base
2 : Emitter
3 : Collector
SANYO : NP
* The 2SC5414 is classified by 30mA h
FE
as follows :
