2SC5900
No.7539-1/3
No.
2SC5900
VCBO=1700V
HVP
MBIT
Absolute Maximum Ratings / Ta=25
unit
VCBO
1700
V
VCEO
800
V
VEBO
5
V
IC
8
A
ICP
16
A
PC
3.0
W
Tc=25
80
W
Tj
150
Tstg
- 55 150
Electrical Characteristics / Ta=25
min
typ
max
unit
ICBO
VCB=800V, IE=0
10
A
ICES
VCE=1700V, RBE=0
1.0
mA
VCEO(sus) IC=100mA, IB=0
800
V
IEBO
VEB=4V, IC=0
40
130
mA
hFE1
VCE=5V, IC=1A
10
hFE2
VCE=5V, IC=4.5A
4
7
N 7 5 3 9
No. N 7 5 3 9
NPN
CRT
31504
31504KD TS IM TA-100535
(
)
370-0596 11
1 : Base
2 : Collector
3 : Emitter
SANYO : TO-3PMLH
2174A
(unit : mm)
21.0
5.0
22.0
0.8
20.4
4.0
16.0
3.4
2.0
2.8
2.1
5.45
5.45
0.7
0.9
3.5
8.0
5.6
3.1
1
2
3
2SC5900
No.7539-2/3
0
0
1
2
3
4
6
8
5
7
, VCE -- V
IC -- VCE
, I
C
--
A
IT06273
IT06275
IT06274
IT06276
1
2
5
6
3
4
7
8
9
10
0
, VBE -- V
IC -- VBE
, I
C
-
- A
0
0.2
0.4
0.6
0.8
1.0
1.2
1
2
3
4
5
6
7
9
8
1.0
, IC -- A
hFE -- IC
, h
FE
2
3
5
7
2
3
5
7
0.1
1.0
10
10
2
3
5
100
7
2
3
5
7
, IC -- A
VCE(sat) -- IC
, V
CE
(sat) -
- V
2
3
5
7
2
3
5
7
1.0
10
0.1
0.01
0.1
1.0
2
3
5
7
2
3
5
7
10
2
3
5
7
IB=0
0.1A
0.2A
0.4A
0.6A
0.8A
1.2A
1.6A
2.0A
1.0A
1.4A
Ta=120
C
25
C
--40
C
Ta=
--40
C
25
C
25C
Ta= -
-40
C
VCE=5V
IC / IB=5
120C
120
C
VCE=5V
Ta=120
C
25
C
--40
C
1.8A
min
typ
max
unit
VCE(sat)
IC=4A, IB=1A
3
V
VBE(sat)
IC=4A, IB=1A
1.5
V
tstg
IC=3A, IB1=0.5A, IB2= - 1.5A
3.0
s
tf
IC=3A, IB1=0.5A, IB2= - 1.5A
0.2
s
VF
IEC=6.5A
2
V
VR
RB
VCC=200V
VBE= --5V
+
+
50
INPUT
OUTPUT
RL=66.7
100
F
470
F
PW=20
s
IB1
D.C.
1%
IB2
