2SC5932
No.7416-1/3
No.
2SC5932
VCBO=1600V
HVP
MBIT
Absolute Maximum Ratings / Ta=25
unit
VCBO
1600
V
VCEO
800
V
VEBO
5
V
IC
20
A
ICP
40
A
PC
3.5
W
Tc=25
140
W
Tj
150
Tstg
- 55 150
Electrical Characteristics / Ta=25
min
typ
max
unit
ICBO
VCB=800V, IE=0
10
A
ICES
VCE=1600V, RBE=0
1.0
mA
V(BR)CEO IC=10mA, RBE=
800
V
IEBO
VEB=4V, IC=0
1.0
mA
hFE1
VCE=5V, IC=1A
10
hFE2
VCE=5V, IC=15A
4
7
N 7 4 1 6
No. N 7 4 1 6
NPN
CRT
O1003
O1003 TS IM TA-100354
(
)
370-0596 11
1 : Base
2 : Collector
3 : Emitter
SANYO : TO-3PBL
2048B
(unit : mm)
20.0
1.2
2.0
3.4
3.3
0.6
5.0
1.0
2.0
20.7
26.0
1
2
3
5.45
5.45
2.8
6.0
2SC5932
No.7416-2/3
min
typ
max
unit
VCE(sat)
IC=13.5A, IB=3.4A
3
V
VBE(sat)
IC=13.5A, IB=3.4A
1.5
V
tstg
IC=10A, IB1=1.6A, IB2= - 5A
3.0
s
tf
IC=10A, IB1=1.6A, IB2= - 5A
0.2
s
VR
RB
VCC=200V
VBE= --2V
+
+
50
INPUT
OUTPUT
RL=
20
100
F
470
F
PW=20
s
IB1
D.C.
1%
IB2
0
0
2
4
6
8
10
12
14
16
, VCE -- V
IC -- VCE
, I
C
--
A
IT03573
IT03575
IT03574
IT03576
1
2
5
6
3
4
7
8
9
10
0
, VBE -- V
IC -- VBE
, I
C
-
- A
0
0.2
0.4
0.6
0.8
1.0
1.2
2
4
6
8
10
12
14
16
18
20
1.0
, IC -- A
hFE -- IC
, h
FE
2
3
5
7
2
2
3
5
3
5
7
0.1
1.0
10
10
2
3
5
100
7
2
3
5
7
, IC -- A
VCE(sat) -- IC
, V
CE
(sat) -
- V
2
3
5
7
1.0
10
2
3
5
7
0.1
2
3
5
0.01
0.1
1.0
2
3
5
7
2
3
5
7
10
2
3
5
7
IB=0
0.1A
0.2A
0.4A
0.6A
0.8A
1.2A
1.6A
2.0A
1.0A
1.8A
1.4A
Ta=120
C
25
C
-
-40
C
Ta=120C
25C
--40C
Ta= --40C
25
C
25C
Ta= -
-40
C
VCE=5V
VCE=5V
IC / IB=5
120C
120
C
