Typical Characteristics
Specifications
Cell Type N-150NS
Dimensions
of
Bare Cell
H
28.5
0.3
mm
1.122
0.012
inch
D
11.5
0.2
mm
0.453
0.008
inch
d
5.5
mm
0.217
inch
D
d
H
Nominal Capacity
135mAh
Nominal Voltage
1.2V
Standard Charging Current
4.5mA
Charging Time
above 48Hrs.
Ambient
Temperature
Charge
0C to +70C [+32F to 158F]
Discharge
-20C to +70C [ -4F to 158F]
Storage
-30C to +70C [ -22F to 158F]
Internal Impedance (Av.)
(at 50% discharge)
50.0m
(at 1000Hz)
Weight
9g/0.32oz
Dimensions(D)
(H)
(with tube)
Charge
1.6
1.5
1.4
1.3
0
6
12
18
24
30
36
42
48
Charge : 4.5mA
0C/32F
20C/68F
40C/104F
60C/140F
Cell Voltage (V)
Charge Time (Hrs.)
Cell Capacity (at various discharge rate)
100
80
60
40
90
70
50
0
0.2
0.4
0.6
0.8
1
Available Capacity (%)
Discharge Rate (C)
Charge : 4.5mA
48Hrs.
Discharge : End Volt 1.0V
at 20C/68F
Discharge (at low rate)
1.4
1.2
1.0
0.8
0
2
4
6
8
10
12
14
16
Charge : 4.5mA
48Hrs.
at 20C/68F
(0.1C)
(0.2C)
(0.5C)
Cell Voltage (V)
Discharge Time (Hrs.)
Discharge (at very low rate)
10000
7000
6000
5000
4000
3000
2000
1000
800
700
100
0
32
10
20
30
40
50
60
70
80C
50
68
86
104
122
140
158
176F
Discharge Time (Hrs.)
Operating Temperature
Charge : 4.5mA
48Hrs.
Discharge : End Volt 1.0V
10
A
50
A
100
A
Discharge (at various temperature)
1.4
1.2
1.0
0.8
0
20
40
60
80
100
120
140
160
60C/140F
80C/176F
0C/32F
Cell Voltage (V)
Discharge Time (Days)
Charge : 4.5mA
48Hrs.
Discharge : 50
A
20C/68F
40C/104F
Temperature (Charge & Discharge)
100
80
60
40
-20
-10
0
10
20
30
40
50
80C
-4
14
32
50
68
86
104
122
60
140
70
158
176F
Available Capacity (%)
Operating Temperature
90
70
50
Charge Characteristics
Discharge Characteristics
Condition Charge : 4.5mA
48Hrs.
Discharge : 27mA
(End Volt 1.0V)
12.0
0
29.3
0
mm
-0.5
-1
0.47
0
1.15
0
inch
-0.02
-0.04
