Copyright & Copy;2000 Shindengen Electric Mfg.Co.Ltd
RATINGS
SHINDENGEN
LSV Series
Switching Power Transistor
OUTLINE DIMENSIONS
Unit : mm
-5A PNP
2SA1795
(TE5T4)
Case : E-pack
Absolute Maximum Ratings
Item
Symbol
Conditions
Ratings
Unit
Storage Temperature
Tstg
-55150
Junction Temperature
Tj
150
Collector to Base Voltage
V
CBO
-60
V
Collector to Emitter Voltage
V
CEO
-40
V
Emitter to Base Voltage
V
EBO
-7
V
Collector Current DC
I
C
-5
A
Collector Current Peak
I
CP
-10
A
Base Current DC
I
B
-1.5
A
Base Current Peak
I
BP
-2
A
Total Transistor Dissipation
P
T
Tc = 25
10
W
Electrical Characteristics (Tc=25)
Item
Symbol
Conditions
Ratings
Unit
Collector to Emitter Sustaining Voltage
V
CEO
(sus)
I
C
= -0.05A
Min -40
V
Collector Cutoff Current
I
CBO
At rated Voltage
Max -0.1
mA
I
CEO
Max -0.1
Emitter Cutoff Current
I
EBO
At rated Voltage
Max -0.1
mA
DC Current Gain
h
FE
V
CE
= -2V, I
C
= -2.5A
Min 70
Collector to Emitter Saturation Voltage
V
CE
(sat)
I
C
= -2.5A
Max -0.3
V
Base to Emitter Saturation Voltage
V
BE
(sat)
I
B
= -0.13A
Max -1.2
V
Thermal Resistance
jc
Junction to case
Max 12.5
/W
Transition Frequency
f
T
V
CE
= -10V, I
C
= -0.5A
TYP 50
MHz
Turn on Time
ton
Max 0.3
I
C
= -2.5A
Storage Time
ts
I
B1
= -0.25A, I
B2
= -0.25A
Max 1.5
s
R
L
= 12, V
BB2
= -4V
Fall Time
tf
Max 0.5
