Copyright & Copy;2000 Shindengen Electric Mfg.Co.Ltd
RATINGS
SHINDENGEN
OUTLINE DIMENSIONS
Unit : mm
Case : MTO-3P
Darlington Transistor
15A NPN
2SD1027
(T15L20)
Absolute Maximum Ratings
Item
Symbol
Conditions
Ratings
Unit
Storage Temperature
Tstg
-55+150
Junction Temperature
Tj
+150
Collector to Base Voltage
V
CBO
200
V
Collector to Emitter Voltage
V
CEO
200
V
Emitter to Base Voltage
V
EBO
7
V
Collector Current DC
I
C
15
A
Collector Current Peak
I
CP
22
A
Base Current DC
I
B
1
A
Base Current Peak
I
BP
2
A
Total Transistor Dissipation
P
T
Tc = 25
100
W
Mounting Torque
TOR
(Recommended torque : 0.5Nm
0.8
Nm
Electrical Characteristics (Tc=25)
Item
Symbol
Conditions
Ratings
Unit
Collector Cutoff Current
I
CBO
V
CB
= 200V
Max 0.1
mA
I
CEO
V
CE
= 200V
Max 0.1
Emitter Cutoff Current
I
EBO
V
EB
= 7V
Max 5
mA
DC Current Gain
h
FE
V
CE
= 3V, I
C
= 10A
Min 1,500
Max 30,000
Collector to Emitter Saturation Voltage
V
CE
(sat)
I
C
= 10A
Max 1.5
V
Base to Emitter Saturation Voltage
V
BE
(sat)
I
B
= 30mA
Max 2.0
V
Thermal Resistance
jc
Junction to case
Max 1.25
/W
Transition Frequency
f
T
V
CE
= 10V, I
C
= 1.5A
TYP 20
MHz
Turn on Time
ton
Max 2
I
C
= 10A
Storage Time
ts
I
B1
= I
B2
= 30mA
Max 8
s
R
L
= 3
Fall Time
tf
V
BB2
= 4V
Max 5
